Data Sheet

X-2017, www.findernet.com
H
94.74
Approvals
(according to type):
94.82
Approvals
(according to type):
Screw terminal (Plate clamp) socket
panel or 35mm rail (EN60715) mount
94.72
Blue
94.72.0
Black
94.73
Blue
94.73.0
Black
94.74
Blue
94.74.0
Black
For timer type 85.02 85.03 85.02, 85.04
Accessories
Metal retaining clip (supplied with timer) 094.81
Screw terminal socket
panel or 35mm rail (EN60715) mount
94.82
Blue
94.82.0
Black
For timer type 85.02 85.02
Accessories
Metal retaining clip (supplied with timer) 094.81
Technical data
Rated values 10A - 250V
Dielectric strength 2kVAC
Protection category IP 20
Ambient temperature °C –40…+70
Screw torque Nm 0.5
Wire strip length mm 8 (94.72, 94.73, 94.74) 9 (94.82)
Max. wire size for 94.72, 94.73, 94.74 and 94.82 sockets solid wire stranded wire
mm
2
1x2.5 / 2x1.5 1x2.5 / 2x1.5
AWG 1x14 / 2x16 1x14 / 2x16
94.72 94.73 94.74
94.82
Please see general technical information
10
94 SERIES
Sockets and accessories for 85 series timers
85
SERIES
