- Title Page - SLWS106H
- IMPORTANT NOTICE
- Contents
- List of Illustrations
- 1 Introduction
- 2 Specifications
- 2.1 Absolute Maximum Ratings Over Operating Free-Air Temperature Range (unless otherwise noted)†
- 2.2 Recommended Operating Conditions
- 2.3 Electrical Characteristics Over Recommended Operating Conditions, AVDD, HPVDD, BVDD = 3.3 V, DVDD = 1.5 V, Slave Mode, XTI/ MCLK = 256fs, fs = 48 kHz ( unless otherwise stated)
- 2.4 Digital-Interface Timing
- 3 How to Use the TLV320AIC23B
- Appendix A: Mechanical Data
A−2
PW (R-PDSO-G**) PLASTIC SMALL-OUTLINE PACKAGE
14 PINS SHOWN
0,65
M
0,10
0,10
0,25
0,50
0,75
0,15 NOM
Gage Plane
28
9,80
9,60
24
7,90
7,70
2016
6,60
6,40
4040064/F 01/97
0,30
6,60
6,20
8
0,19
4,30
4,50
7
0,15
14
A
1
1,20 MAX
14
5,10
4,90
8
3,10
2,90
A MAX
A MIN
DIM
PINS **
0,05
4,90
5,10
Seating Plane
0°−ā 8°
NOTES: A. All linear dimensions are in millimeters.
B. This drawing is subject to change without notice.
C. Body dimensions do not include mold flash or protrusion not to exceed 0,15.
D. Falls within JEDEC MO-153
