Royal Series Water Temperature Control Units Page 11
Figure 2
Typical Royal Upright Series Water Temperature Control Unit and Specifications
48"
3 3/4"
28"
13"
Model Dimensions Shipping
number Pump H W D weight
460 230 letter hp
kW
gpm
lpm
psig
kPa
in.
cm
in.
cm
in.
cm
lbs.
Kg
C ¾
0.56
30
113.6
25
172.4
D 1
0.75
35
132.5
30
206.9
F 2
1.50
50
189.3
30
206.9
G 3
2.24
60
227.1
35
241.3
210
96
H 5
3.73
75
283.9
54
372.3
J 7½
5.60
90
340.7
63
434.4
240
109
2012,
9 kW heater
K 10
7.46
120
454.2
55
379.2
48
122
13
33
28
71.1
270
123
Figure 3
Royal Series Unit Full-Load Amps
Model Full-load amps at 460 volts
hp kW 9 kW heater 12 kW heater 18 kW heater 24 kW heater 36 kW heater 48 kW heater
0.75 hp
0.56 kW
12.7 amps 16.5 amps 24.0 amps 31.6 amps 47.4 amps 62.4 amps
1.00 hp
0.75 kW
13.1 amps 16.9 amps 24.4 amps 32.0 amps 47.8 amps 62.8 amps
2.00 hp
1.50 kW
14.7 amps 18.5 amps 26.0 amps 33.6 amps 49.4 amps 64.4 amps
3.00 hp
2.24 kW
16.1 amps 19.9 amps 27.4 amps 35.0 amps 50.8 amps 65.8 amps
5.00 hp
3.73 kW
18.9 amps 22.7 amps 30.2 amps 37.8 amps 56.6 amps 71.6 amps
7.50 hp
5.60 kW
22.3 amps 26.1 amps 33.6 amps 41.2 amps 57.0 amps 72.0 amps
10.00 hp
7.46 kW
26.0 amps 30.0 amps 37.0 amps 45.0 amps 60.0 amps 75.0 amps
49
7
/8”
