SIR-CL3 CLARION COMPATIBLE SIRIUS SATELLITE RADIO TUNER Ce-NET TO HEADUNIT PASS-THRU SIR-CL3 CLARION COMPATIBLE SIRIUS SATELLITE RADIO TUNER Installation Guide
Congratulations on your purchase of the SIR-CL3 ClarionCompatible SIRIUS Satellite Radio Tuner! Your new SIRIUS Tuner is designed to work with all Clarion headunits that are designated to be “SIRIUS-READY”. Contact Clarion or SIRIUS for model compatibility. What is SIRIUS Satellite Radio? Over 120 channels of the best entertainment and completely commercial-free music for your car, home or office.
Table of Contents Package Contents .............................................................................................. 3 Warnings and Cautions ..................................................................................... 4 Installation .......................................................................................................... 6 Mounting the Tuner ............................................................................................ 6 Installing the Antenna ...........
WARNING This symbol means important instructions. Failure to heed them can result in serious injury or death. DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE. Any function that requires your prolonged attention should only be performed after coming to a complete stop. Always stop the vehicle in a safe location before performing these functions. Failure to do so may result in an accident. DO NOT OPEN, DISASSEMBLE OR ALTER THE UNIT IN ANY WAY.
CAUTION This symbol means important instructions. Failure to heed them can result in injury or material property damage. HALT USE IMMEDIATELY IF A PROBLEM APPEARS. Failure to do so may cause personal injury or damage to the product. Return the unit to your authorized retailer or nearest service center for repairing. INSTALL THE WIRING SO THAT IT IS NOT CRIMPED OR PINCHED BY SCREWS OR SHARP METAL EDGES. Route the cables away from moving parts or sharp pointed edges.
Installation It is recommended that prior to starting the installation, you thoroughly read this manual and follow the guidelines listed below: Consider the mounting location carefully. You should make sure that you avoid the following: • Any location where the tuner is exposed to moisture. • Any location where the unit is exposed to extreme heat. • Any location that would interfere with moving parts on the vehicle or hamper driving.
3) Remove the remaining protective tape from the adhesive, carefully position the antenna with cover/tail and apply pressure to secure to the vehicle. Cable Cover/ Tail • For SUVs, minivans and five-door vehicles, bring the cable into the vehicle under the rubber molding for the tailgate, and continue under the interior trim. • From the trunk, carefully route the cable to the location of the SIR-CL3 and plug the SMB connector onto the unit.
Wiring and Cable Connections ! Antenna Input Connect the right-angle SMB connector from the antenna. Push firmly to attach. ANTENNA CeNET Headunit Connector Use the supplied CeNET cable to connect to the Clarion Headunit – See “System Connection Examples” for more specific details.
Right-angle SMB Connector Antenna (21’ cable) - Mount on Roof of Vehicle $17(11$ SIR-CL3 SIR-CL3 CLARION COMP ATIBLE SIRIUS SA TELLITE RADIOTUNER CeNET 72 +($'81,7 PASS-THRU Right-angle CeNET Connector 2.
System Connection Examples System 1: Clarion Headunit and SIR-CL3 ANTENNA Clarion SIRIUS-Ready Headunit SIR-CL3 SIR-CL3 CLARION COMP ATIBLE SIRIUS SA TELLITE RADIOTUNER CeNET TO HEADUNIT 10 PASS-THRU SIR-CL3 Installation Guide
System 2: Clarion Headunit, CD/DVD Player and SIR-CL3 ANTENNA Clarion SIRIUS-Ready Headunit SIR-CL3 SIR-CL3 CLARION COMP ATIBLE SIRIUS SATELLITE RADIOTUNER CeNET TO HEADUNIT PASS-THRU Clarion Ce-NET Compatible CD changer or other audio device SIR-CL3 Operation Installationand Guide Installation Guide 11 11
Activating Your SIRIUS Subscription You must activate SIR-CL3 before you can start to receive the SIRIUS Satellite Radio broadcast. 1. Make sure that the SIR-CL3 is properly connected and that its antenna is oriented to receive the SIRIUS satellite signal. 2. Turn on the Clarion headunit. 3. Press and release the SOURCE button on the head unit to select SIRIUS as the source. (Each press of the SOURCE button will change to a different audio source.) 4.
Specifications Operational Frequencies Satellite ......................................................................... 2322.293/2330.207 MHz Terrestrial ....................................................................................... 2326.250MHz Chassis Size ................................ 126.75mm x 125.75mm x 34.75mm (WxHxD) Antenna Type ................................................................................ Mini-Magnetic Antenna Cable Length ..........................................
SIRIUS Satellite Radio 1221 Avenue of the Americas New York, NY 10020 (888) 539-7474 www.sirius.com © 2005 SIRIUS Satellite Radio Inc. “SIRIUS” and the SIRIUS dog logo are registered trademarks of SIRIUS Satellite Radio Inc.
