COMPACT COMPONENT SYSEM FS-H35 FS-H30 — Consists of CA-FSH35 and SP-UXH35 — Consists of CA-FSH30 and SP-UXH30 COMPACT COMPONENT SYSTEM INSTRUCTIONS For Customer Use: Enter below the Model No. and Serial No. which are located either on the rear, bottom or side of the cabinet. Retain this information for future reference. Model No. Serial No. GVT0101-001B [J] COVER_FS-H30[J]ff.pm6 1 03.3.
Warnings, Cautions and Others Mises en garde, précautions et indications diverses CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Section 820-40 of the NEC which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. For Canada/pour le Canada CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Introduction We would like to thank you for purchasing one of our JVC products. Before operating this unit, read this manual carefully and thoroughly to obtain the best possible performance from your unit, and retain this manual for future reference. About This Manual Power sources This manual is organized as follows: • The manual mainly explains operations using the buttons on the remote control.
Contents Location of the Buttons ............................................... 3 Main Unit .......................................................................... 3 Remote Control ................................................................. 5 Getting Started ............................................................. 6 Supplied Accessories ......................................................... 6 Connecting Antennas ........................................................
Location of the Buttons Become familiar with the buttons on your unit. Main Unit Top view PHONES 1 2 7 8 COMPACT DIGITAL AUDIO 3 TIMER/SNOOZE 4 9 OPEN MULTI CONTROL ONE TOUCH REC 4 7 ¢ VOLUME BAND 5 AUX TAPE TUNER AHB PRO p CD 6 Front view q w STANDBY COMPACT COMPONENT SYSTEM r e t 3 EN01-13_FS-H30[J]f.pm6 3 03.2.
Continued Display window 1 2 3 4 5 6 7 8 BASS SLEEP SNOOZE REC ON OFF CLOCK MONO STEREO REC 9 p 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 PROGRAM RANDOM ALL OVER w e r q t See the pages in parentheses for details.
Remote Control See the pages in parentheses for details. STANDBY/ON 1 2 3 4 5 6 DISPLAY 7 8 9 CLOCK /TIMER 10 SLEEP 8 1 9 p 10 q UP BASS TREBLE w 2 3 SET DOWN CANCEL e 4 5 CD TUNER TAPE AUX REV.
Getting Started Supplied Accessories Continued To connect an outdoor FM antenna Make sure that you have all the following items. The number in parentheses indicates the quantity of each piece supplied. • AM loop antenna (1) • FM antenna (1) • AC power cord (1) • Remote control (1) • Batteries (2) Before connecting the antenna, disconnect the supplied FM antenna. Outdoor FM antenna (not supplied) Coaxial cable (not supplied) If anything is missing, consult your dealer immediately.
Connecting Speakers AM antenna 1 1 Vinyl-covered wire (not supplied) 2 Speaker cord Speaker cord 2 AM loop antenna (supplied) Right speaker 1 Connect the AM loop antenna to the AM LOOP terminals as illustrated. 2 Turn the AM loop antenna until you have the best reception. Left speaker 1 Press and hold the clamp of the speaker terminal on the rear of the unit. 2 Insert the end of the speaker cord into the terminal.
Continued To remove the speaker grilles NOW you are ready to plug in the unit and any other connected equipment. The speaker grilles are removable. IMPORTANT: Be sure to check all connections to be done before plugging the power cord. Projections Holes This unit can be supplied with power through the AC IN connector (at home) or the DC IN connector (in a car). • Do not connect the unit using the AC IN connector and the DC IN connector at the same time for safe and correct use.
When using the unit in your car To car’s cigarette lighter socket (12 V) Putting the Batteries into the Remote Control Insert the batteries—R6(SUM-3)/AA(15F)—into the remote control, by matching the polarity (+ and –) on the batteries with the + and – markings on the battery compartment. When the remote control can no longer operate the unit, replace both batteries at the same time.
Common Operations 3 Setting the Clock Before operating the unit any further, first set the unit’s clock. When you plug in the power cord, the CLOCK indicator and “AM 12:00” start flashing on the display. You can set the clock whether the unit is on or off. • There is a time limit in doing the following steps. If the setting is canceled before you finish, start over from step 1. On the remote control: 1 Continued Press CLOCK/TIMER. Press ¢ or 4 to adjust the minute, then press TIMER/SNOOZE.
Turning On the Power Adjusting the Tone (Bass/Treble) STANDBY/ON To turn on the unit, press STANDBY/ON (or on the unit). The STANDBY lamp on the unit goes off. • When you press the source button —3/8 CD, 2 3 TAPE, TUNER (or BAND TUNER on the unit) and AUX, the unit automatically turns on and starts playback if the source is ready. You can adjust the bass level (low frequency range) and the treble level (high frequency range) within a range of –5 to +5.
Listening to FM and AM Broadcasts Tuning in to a Station 1 Presetting Stations Press TUNER (or BAND TUNER on the unit) to select the band. The unit automatically turns on and tunes in to the previously received station—either FM or AM. • Each time you press the button, the band alternates between FM and AM. Continued TUNER BAND You can preset 30 FM and 15 AM stations—using either automatic presetting or manual presetting.
To preset stations manually—Manual presetting You need to preset stations separately for the FM and AM bands. • There is a time limit in doing the following steps. If the setting is canceled before you finish, start over from step 2. On the remote control ONLY: 1 Tune in to the station you want to preset. • See “Tuning in to a Station” on page 12. 2 Press SET. 3 Press UP or DOWN to select a preset number.
Playing Back Discs This unit has been designed to play back the following discs—CD, CD-R, and CD-RW. When playing a CD-R or CD-RW User-edited CD-Rs (CD-Recordable) and CD-RWs (CD-ReWritable) can be played only if they are already “finalized.” • Usually you can play back your original CD-Rs or CD-RWs recorded in music CD format. However, sometimes they may not play depending on their characteristics or recording conditions. • Before playing CD-Rs or CD-RWs, read their instructions or cautions carefully.
Basic Disc Operations Programming the Playing Order of the Tracks—Program Play While playing a disc, you can do the following operations. You can arrange the order in which tracks play before you start playing. You can program up to 20 tracks. To stop playing for a moment During play, press 3/8 CD. While pausing, the elapsed playing time flashes on the display. On the remote control ONLY: CD 1 Load a disc.
To check the program contents You can check the program contents by pressing ¢ or 4 before or after playback. • ¢ : To check the contents in the programmed order. • 4 : To check the contents in the reverse order. To modify the program On the remote control ONLY: Before or after playing, you can erase the last programed track by pressing CANCEL. • Each time you press the button, the last programed track is erased from the program. CANCEL To erase the program, press 7 before or after playing.
Playing Back Tapes You can play back type I tapes. If no cassette is inserted when you press 2 3 TAPE “NO TAPE” appears on the display. Playing Back a Tape 1 Press ) for cassette deck on the unit. To stop playing, press 7. The cassette holder opens. To fast-wind to the left or to the right, press ¢ or 4 while the tape is not running. The tape direction indicator (3 or 2) starts flashing rapidly on the display. To remove the cassette, press ) on the unit.
Recording Continued IMPORTANT: • It should be noted that it may be unlawful to rerecord pre-recorded tapes, records, or discs without the consent of the owner of copyright in the sound or video recording, broadcast or cable program and in any literary, dramatic, musical, or artistic embodied therein. • The recording level is automatically set correctly, so it is not affected by the other sound settings.
Disc Direct Recording To record on both sides—Reverse Mode On the remote control ONLY: Everything on the disc goes onto the tape in the order it is on the disc, or according to the order you have set in Program Play. On the unit ONLY: 1 Put a recordable cassette in with the exposed part of the tape down. 2 Load a disc. • If the current playing source is not the CD player, press 3/8 CD, then 7 before going to the next step.
Using the Timers Continued There are four timers available—Daily Timer, Recording Timer, Snooze Timer, and Sleep Timer. Before using the timers, you need to set the unit’s clock (see page 10). 2 UP On the remote control: 1) Press UP or DOWN to set the hour, then press CLOCK/TIMER. UP or DOWN to set 2) Press the minute, then press CLOCK/TIMER. Using Daily Timer and Recording Timer You can set the timer whether the unit is on or off.
4 Select the timer (Daily Timer or Recording Timer) with the source to play. On the remote control: Press UP or DOWN to select the timer, then press CLOCK/TIMER. UP • See “Setting the Clock” on page 10. 7 On the unit: Press ¢ or 4 to select the timer, then press TIMER/SNOOZE. Press STANDBY/ON (or on the unit) to turn off the unit (standby) if you have set the timer with the unit turned on. STANDBY/ON • When the timer turns on the unit, the (timer) indicator starts flashing.
Using Snooze Timer Using Sleep Timer The Snooze Timer turns off the unit (standby) only for 5 minutes while the Daily Timer is in operation. • You can set the Snooze Timer only while the Daily Timer is in operation. With the Sleep Timer, you can fall asleep to music. You can set the Sleep Timer when the unit is turned on. Press TIMER/SNOOZE on the unit (or CLOCK/TIMER on the remote control) while the Daily Timer is in operation.
Maintenance To get the best performance from the unit, keep your discs, tapes, and mechanism clean. Cleaning the unit Handling discs • Stains on the unit Should be wiped off with a soft cloth. If the unit is heavily stained, wipe it with a cloth soaked in waterdiluted neutral detergent and wrung well, then wipe clean with a dry cloth. • Remove the disc from its case by holding it at the edge while pressing the center hole lightly. • Do not touch the shiny surface of the disc, or bend the disc.
Handling cassette tapes • If the tape is loose in its cassette, take up the slack by inserting a pencil in one of the reels and rotating. • If the tape is loose, it may get stretched, cut, or caught in the cassette. • Be careful not to touch the tape surface.
Troubleshooting If you are having a problem with your unit, check this list for a possible solution before calling for service. If you cannot solve the problem from the hints given here, or the unit has been physically damaged, call a qualified person, such as your dealer, for service. Symptom Cause Action No sound is heard. • Connections are incorrect or loose. • Headphones are connected. • Check all connections and make corrections. (See pages 6 – 9.) • Disconnect the headphones.
Specifications Amplifier General Output Power: 20 W (10 W + 10 W) at 4 Ω (10% THD) Power requirement: AC IN: 120 V , 60 Hz DC IN: 12 V, 4 A 12 W per channel, min. RMS, driven into 4 Ω at from 80 Hz to 15 kHz with no more than 10% total harmonic distortion. Audio input sensitivity/Impedance (at 1 kHz) AUX: 500 mV/48.75 kΩ Speakers/Impedance: 4Ω Power consumption: 35 W (at operation) 3.0 W (on standby) Dimensions (approx.): 412 mm x 208 mm x 275 mm (W/H/D) (16 1/4 in. x 8 1/4 in. x 10 7/8 in.
LIMITED WARRANTY AUDIO-1 JVC COMPANY OF AMERICA warrants this product and all parts thereof, except as set forth below ONLY TO THE ORIGINAL PURCHASER AT RETAIL to be FREE FROM DEFECTIVE MATERIALS AND WORKMANSHIP from the date of original retail purchase for the period as shown below. ("The Warranty Period") PARTS 1 LABOR YR 1 YR THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA AND IN COMMONWEALTH OF PUERTO RICO.
Authorized Service Centers ® QUALITY SERVICE HOW TO LOCATE YOUR JVC SERVICE CENTER TOLL FREE: 1 (800) 537-5722 http://www.jvc.com Dear Customer, In order to receive the most satisfaction from your purchase,please read the instruction booklet before operating the unit.In the event that repairs are necessary, please call 1 (800)537-5722 for your nearest authorized servicer or visit our website at www.JVC.com Remember to retain your Bill of Sale for Warranty Service.
