User Guide

Table of Contents
IMPORTANT:
• Installer: In the interest of safety and to minimize problems, read these installation instructions completely and carefully before you
begin the installation process. Leave these installation instructions with the customer.
• Customer: Keep these installation instructions for future reference and the local building inspector’s use.
All specifications subject to change without notice.
Dacor
®
assumes no liability for changes to specifications.
© 2010 Dacor, all rights reserved.
Important Safety Instructions .....................................................1
About Safety Instructions ............................................................1
Safety Symbols in this Manual ...................................................1
General Safety Precautions ........................................................2
Planning the Installation ..............................................................3
Electrical Requirements .............................................................. 3
Gas Supply Requirements ..........................................................4
Electrical and Gas Supply Connections .....................................4
Product Dimensions ....................................................................5
Cabinet Layout ............................................................................6
Self-Rimming Installation Without Raised Vent ..........................7
Self-Rimming Installation With Raised Vent ...............................8
Installation Instructions ............................................................. 10
Preparing for Installation ...........................................................10
Electrical Connection ................................................................14
Gas Connection ........................................................................18
Final Installation ........................................................................ 18
Cooktop Assembly ....................................................................19
Verifying Proper Operation .......................................................20
Installation Checklist .................................................................20
Customer Service Information
If you have questions or problems with installation, contact your
Dacor dealer or the Dacor Customer Service Team. For repairs
to Dacor appliances under warranty call the Dacor Distinctive
Service line. Whenever you call, have the model and serial
number of the appliance ready. The product model number and
serial number label can be seen through the grill below the control
panel, on the right side.
Dacor Customer Service
Phone: [phone] ex. 2813 (U.S.A. and Canada)
Monday — Friday 6:00
a.m. to 5:00 p.m. Pacific Time
Web site: www.dacor.com
Dacor Distinctive Service (for repairs under warranty only)
Phone: [phone] ex. 2822 (U.S.A. and Canada)
Monday — Friday 6:00
a.m. to 5:00 p.m. Pacific Time
Model Identification
Product Model/Serial Label
and Rating Label Locations
Model/serial number label
located inside unit, behind grill
Electrical and gas rating label,
view through space between
door and oven opening
DR30DIH-C/NG/H
SIZE (inches)
COUNTRY CODE
HANDLE TYPE
TRIM STYLE
GAS TYPE
ALTITUDE
C = Equipped for use in Canada
No Character = Equipped for use in U.S.A.
H = External Handle
No Character = Integral handle
I = Self-rimming
(3 1/4 inch side panels)
No Character = Freestanding
(full size side panels)
NG = Natural Gas
LP = Liquid Petroleum (Propane)
H = Equipped for high altitude operation,
4000 ft. (1219 m) and up
No Character = Equipped for low altitude operation
