DIGITAL PHOTO FRAME User Manual 1
Catalog Remote Control ............................................................................................................................ 3 Body button and interfaces ....................................................................................................... 4 Machine start up .......................................................................................................................... 5 Browse pictures ...............................................................
Remote Control Power on/off Loudspeaker mute Photo slides with BGM One key into the calendar interface One-click play pictures One-click play music One-click play video Up/down/left/right cursor Confirm selection Volume addition and subtraction Fast forward and fast back in music or video playing Play the previous or the latter video or track Play or pause One-click access to the system settings interface Return to the previous interface 3
Body button and interfaces 4
Machine start up The boot screen will be displayed after 2-3 seconds of power-on.
the inserted U disk,inserted SD card or built-in TF card. If the boot-up auto-play video is preset,the video files in the corresponding memory will be automatically played at this time,and the default is to play the file name in order;if the boot-up auto-play picture is preset,the system will automatically play the picture. [Tip:For specific boot-up playback settings,please refer to the description of the system settings module below.
bright, it indicates that the memory card has been inserted into the machine. If it is grey, it means that it is not available and cannot be specified.] Browse pictures Press the button in the remote control directly (or int he main interface of the system, select the image icon,press the button), and automatically play the picture in memory in the form of slides. During the period, you can manually switch between the last and the next picture by remote control and button.
to suspend the slide playing (if it is suspended, press this button to restore the slide mode to play), then press support x10), and press button to enlarge the picture (maximum to rotate the picture 360 degrees. If you need other settings of the picture, you can press long , then enter the brief settings of the picture, as shown in the following figure, press to exit the settings interface.
slide auto-play mode, enter the following picture file browsing, press to quickly browse the pictures, press to view the pictures, and enter the slide auto-play mode at the same time. When the picture slide mode plays automatically, if there are audio files in memory, the system will play pictures automatically with background music, and also can quickly enter the playing of music pictures according to in the remote control. Picture support formats: JPEG、BMP、PNG、GIF(less than 2000*2000 pixels).
the system,select the music icon,press the button) to browse the audio file and play the first audio file automatically by default. During the period, you can select audio files by remote control then press always press to play, then press and , again to pause.
you can press for a long time, enter the simple music settings, press to exit the settings interface. Select EQ Choosing the Equilibrium Effect of Music Playing Play Mode Setting up the Circulating Play Mode of Music EQ Settings The specific values of EQ can also be adjusted separately Tip: The picture slide mentioned above will play automatically. After the above music playing settings are successful, the background music playing will take effect.
backward video; also press volume, press and or and sum to adjust the can be immediately muted. If you need to set the video cycle mode, you can press for a long time in the video playback interface, enter the simple settings of music, press to exit the settings interface.
captions in the video Information You can view the name, resolution, frame rate, size and other information of the video Video Support Format：RM、RMV、RMVB、AVI、MOV、MPG、MPEG、FLV、 F4V、VOB、MP4、M4V、MKV、WMV...etc. Clock calendar Press the button in the remote control directly (or in the main interface of the system, select the calendar icon, press ), and enter the display interface of the calendar. can be used to view the year, month and day.
Tip: If you need to set the current time and alarm clock, you can set it in the Calendar Settings section of the system settings. See the system settings instructions below. File manage In the main interface of the system, select the icon of file management and press to view the list of files in current memory. You can quickly browse and find information about a file and its size according to the button . You can choose to copy or delete the file according to press .
System Settings Press the button in the remote controller directly (or in the main interface of the system, select the icon set, press interface, then press ), then enter the system settings to select different settings module, select the corresponding module, and press to enter the settings of the module.
Photo Setup：Detailed settings can be made for display ratio, whether to play background music, time interval of slides and special effects, repetition mode, etc. Calendar Setup：You can adjust the date, time, time format and alarm clock settings. Video Setup：Video display ratio and cycle mode can be set. Music Setup：Mainly set up the cycle mode of music.
be carried out through the power supply frequency; 4、You can adjust the boot mode to set the default boot play module.; 5、Finally, if there is a human motion sensing module, it can automatically enter sleep by turning on the motion sensor, and then setting the sleep time, that is, how long does the human motion system not feel it. Tip: Press to the main interface to save the settings of the above modules.
