Quick Start Guide

Quick Use Guide Page 5
Product Overview
WorkCentre Overview
WorkCentre Options
The following options are available for the WorkCentre copier/printer/scanner:
Document
Handler
Feeds 75 or 100 single or double sided documents depending on model speed. Documents
from A5 to A3 (5.5"x8.5" to 11"x17") can be fed. Fitted instead of the document cover.
Paper Trays 3
& 4
Both trays have a larger capacity than trays 1 and 2, therefore reducing the number of times
you need to replace paper in the machine.
Paper Tray 5 Has a larger capacity than trays 3 and 4, further reducing the number of times you need to
replace paper in the machine.
Paper Tray 6
(Inserter)
Optional inserter tray available with the High Volume Finisher and High Volume Finisher with
Booklet Maker. Designed to hold special stock, for example covers, that is inserted into a job
Offset Catch
Tray
Delivers output either face up or face down, collated or uncollated. Each set or stack will be
offset from the previous to enable easy separation. Fitted instead of a finisher.
Document Handler
Document Glass
(under the Document
Handler)
Control Panel
(Touch Screen and
Numeric Keypad)
Offset Catch Tray
Paper Tray 5
Bypass Tray
(folds up when not in use)
Paper Trays 3 & 4
Paper Trays 1 & 2
