User Guide

9 | P a g e
INSTALLATION INSTRUCTIONS
Location
The air conditioner should be placed on a hard and level surface strong enough to support the
unit. The unit has casters and it should only be rolled on smooth, flat surfaces. Use caution
when rolling on carpet surfaces. Do not attempt to roll the unit over objects.
Never place any obstacles around the air inlet or outlet and allow at least 20 inch of clearance
for efficient air-conditioning.
Intake and Exhaust hose Installation
When you use this air conditioner unit, hot air must be exhausted out of the room to complete
the air exchange of the condenser. When the unit is operating in DEHUMIDIFYING or FAN only
mode, no exhaust is required.
1. Pull out about 6” of one end of the hoses.
2. Attach the hose connectors to the hoses by turning clockwise.
3. Align the slots on the hose connector to the tabs on the air intake / outlet and snap the
hose to the unit.
4. Only extend the exhaust hoses to the necessary length. We do not recommend
extending the exhaust hose more than 9' long. Additional 4’ exhaust hose sold
separately.
* If you are interested in purchasing optional accessories, please contact [e-mail]
for retail sales information.
EXHAUST
INTAKE
