Table Of Contents

NOW

LOW

MOUNT

ASS

EMBLY

Before You Start





 





IMPORTANT: 



 























732001150100 62" Snow Plow Kit, Blade, & Push Tube

732001150200 72" Snow Plow Kit, Blade, & Push Tube

732001150300 Snow Plow Mount Bracket, 450 ~ 1000 Utility Model

732001150400 Snow Plow Mount Bracke, ATV model

732001150500 Snow Plow Mount Bracket, 1000cc Spo Model





















 





 











Manual No. 80-20PLOW











 

2. 



 



 



   

**  **

 







  





2. 





 



 



 







 



7. 





!! ! OPERATION!!!







 

  







 

Summary of content (8 pages)

PAGE 1
SNOW PLOW & MOUNT ASSEMBLY Manual No. 80-20PLOW Before You Start When you see this symbol, the subsequent A instructions and warnings are serious - follow .. without exception. Your life and the lives of others depend on it! IMPORTANT: Before you begin, read these instructions and check to be sure all parts and tools are accounted for. Please retain these installation instructions for future reference and parts ordering information. Your Snow Plow is exclusively designed for your HISUN unit.
PAGE 2
Assembly Instructions Position Lever ahead and turn the blade to the desired position. The Lever will spring back when the blade is at the correct angle. The blade skids are adjustable so the blade can be lowered but still held a certain distance off the ground. The blade is designed to trip when it strikes an object or digs in too far. When pressure is released the blade springs back into position. Blade spring tension may be set stiffer by tightening the Locknuts on the bottom of the Eyebolts.
PAGE 3
PUSH TUBE TO BLADE BRACKET ASSEMBLY 17 10 16 9 15 8 14 7 13 6 12 5 19 4 18 3 2 1 11 S/N NAME PART NO. QTY 1 Main Push Tube 81200-1001 1 2 Mid Disc 81312-1001 1 3 Swivel Bracket 81311-1001 1 4 81321-1001 9310708025060 1 5 Top Locking Plate Bolt M8x25mm 6 Adjusting Handle 81313-1001 1 81332-1001 2 GB/T 800-1986 1 81331-1001 1 GB/T 800-1986 1 7 8 9 10 Pulley Plate Pin M10x25mm Pulley Pin M8x25mm 6 11 Lock Nut M8 B09M827 6 12 GB/T 70.
PAGE 4
BLADE TO BRACKET ASSEMBLY 30 20 29 28 27 26 25 21 S/N 22 23 NAME 24 PART NO. QTY 81100-1001 1 20 Snow Plow Blade 21 Bolt M12*30 GB/T 16674.1-2004 2 22 Washer 81316-1001 2 23 Mid Washer 81317-1001 2 24 Lock Nut M12 GB/T 6183.
PAGE 5
COMPLETED ASSEMBLY VEHICLE PLOW MOUNT BRACKETS SPORT MODEL - Strike 1000 1. 1000cc Sport Plow Mount Bracket 2. Hisun Part Number: 732001150500 UTILITY MODEL - 450cc ~ 1000cc 1. 450 ~ 1000 Utility Plow Mount Bracket 2. Hisun Part Number: 732001150300 ATV MODEL - 550cc ~ 1000cc 1. ATV Plow Mount Bracket 2.
PAGE 6
Sport Mount Bracket - Strike 1000 Fastener Components: Qty. Part Description 4................. Hex Bolt M10x1.25x30mm 4................. Lock Washer M10 4................. Flat Washers M10 PART # 732001150500 INSTALLATION INSTRUCTIONS: 1. Locate and remove the rear 10mm bolts (A) that secure the winch to the frame. Shown in Figure 1. A 2. Remove the 2 rectangle plastic caps from the frame tubing. B 3. Loosely tighten the 10mm bolts from #1 above. 4.
PAGE 7
Utility Mount Bracket - 450cc ~ 1000cc Fastener Components: Qty. Part Description 4................. M10x1.25x30mm Hex Bolt 4................. M10 Lock Washer 4................. M10 Flat Washers PART # 732001150300 INSTALLATION INSTRUCTIONS: 1. Locate and remove bolts (A) on the lower part of the front bumper. Shown in Figure 2. 2. Slide the plow mount between the bumper and the frame. Line it up and attach using the hardware provided in slots (B) underneath the frame shown in Figure 3.
PAGE 8
ATV Mount Bracket - 550cc ~ 1000cc Fastener Components: Qty. Part Description 4................. U Bolts 8................. M8 Hex Nuts 8................. M8 Flat Washers 8................. M8 Lock Washers PART # 732001150400 INSTALLATION INSTRUCTIONS: 1. Remove both front and middle protection cover from frame (A). Set protective covers to the side. Shown in Figure 1. A 2.
