Specification
Options / Modifications
Append appropriate -sux to model number
-IPS
1/2 inch female IPS connections on
Symmons Temptrol
®
mixing valve
-X
Symmons Temptrol
®
mixing valve, includes
integral service stops to allow water shut-o
for service, p/n S-4001-X-BODY. (Option
only applies when ordering model S-5301)
-REV
Reverse coring in valve for back to back
installations; hot on right, cold on le,
(available with -X integral stops only)
-L/HD
Showerhead not included. (Includes
showerhead arm and ange only)
-2.0
2.0 (7.6 L/min) ow rate restrictor
-1.5
1.5 (5.7 L/min) ow rate restrictor
Standards / Certifications
ASME A112.18.1-2005/CSA B125.1-05
Warranty
Limited Lifetime ■ - to the original end purchaser in
consumer installations
5 years ■ - for commercial installations
Location:
Feature Highlights
Symmons Shower System with lever handles ■
Symmons Temptrol ■
®
pressure-balancing mixing valve with
adjustable stop screw to limit handle turn
Secondary integral volume control handle ■
Showerhead, single mode #532SH ■
Showerhead arm and ange ■
Standard ow rate is 2.5 gpm (9.5 L/min) ■
Optional lower ow rate restrictor available
Polished chrome nish ■
Model Numbers
S-5301
Shower System with Symmons Temptrol
®
pressure-
balancing mixing valve p/n S-4001-BODY
S-5301-TRM
Trim only, mixing valve ordered separately
S-4001-BODY
Symmons Temptrol
®
mixing valve without trim
S-4001-X-BODY
Symmons Temptrol
®
mixing valve without trim.
Valve includes integral service stops to allow water
shut-o for service
Finish Options / Modifications
Append appropriate -sux to model number
-STN
Satin nickel
-BLK
Polished graphite
-
Polished chrome (standard nish)
Shower System S-5301
Specification Submittal
