Owner's Manual

7
PX4 Headset - Right View
1
2
3
4
Bluetooth
®
Volume: Press Chat (+) or Chat (–) to
adjust Bluetooth volume level. A tone will sound each
time the volume level changes.
Bluetooth Status LED:
Paired: Flashing Blue once per second
Unpaired: Flashing blue twice per second
Pairing Mode: Flashing blue and red alternating
Bluetooth Multi-Function Button (BT MFB):
Powers on the Bluetooth and performs several other
functions described in the “Bluetooth” section. (see
pg. 22)
NOTE: The Bluetooth feature is normally powered
on. If it is not paired to another device, it will
automatically turn off after 5 minutes to conserve
battery power.
Mic Mute Button: Press to turn on/off your
microphone. When the microphone is turned on you
will hear a high tone. When it has been muted you
will hear a low tone.
Headset Charging Port: The headset may be charged
by connecting this Mini USB input to a free USB port
on your gaming console using the included Headset
Charging Cable. (see pg. 24)
NOTE: The Headset Charging Cable included with
the PX4 can only be used to charge the headset and
cannot be used as a standard USB data cable.
Charging LED: Turns red when charging and turns off
when charged.
1
2
3
4
5
5
6
6
