Data Sheet

ZPD2.7 ... ZPD75
Characteristics
(T
j
= 25°C unless otherwise specified)
Kennwerte
(T
j
= 25°C wenn nicht anders spezifiziert)
Type
Typ
Zener voltage
4
)
Zener-Spannung
4
)
I
Z
= 5 mA
Dynamic resistance
Diff. Widerstand
r
zj
[Ω] at f = 1 kHz
Temp. Coeffic.
of Z-voltage
…der Z-Spannung
Reverse volt.
Sperrspanng.
I
R
= 100 nA
Z-current
3
)
Z-Strom
3
)
T
A
= 25°C
V
zmin
[V] V
zmax
[V] I
Z
= 5 mA I
Z
= 1 mA α
VZ
[10
-4
/°C] V
R
[V] I
Zmax
[mA]
ZPD2.7 2.5 2.9 75 (< 83) < 500 –9…–4 – 172
ZPD3.0 2.8 3.2 80 (< 95) < 500 –9…–3 – 156
ZPD3.3 3.1 3.5 80 (< 95) < 500 –8…–3 – 143
ZPD3.6 3.4 3.8 80 (< 95) < 500 –8…–3 – 132
ZPD3.9 3.7 4.1 80 (< 95) < 500 –7…–3 – 122
ZPD4.3 4.0 4.6 70 (< 85) < 500 –6…–1 – 109
ZPD4.7 4.4 5.0 60 (< 78) < 500 –5…+2 – 100
ZPD5.1 4.8 5.4 30 (< 60) < 480 –3…+4 > 0.8 93
ZPD5.6 5.2 6.0 10 (< 40) < 400 –2…+6 > 1 83
ZPD6.2 5.8 6.6 5 (< 10) < 200 –1…+7 > 2 76
ZPD6.8 6.4 7.2 4.5 (< 8) < 150 +2…+7 > 3 69
ZPD7.5 7.0 7.9 4 (< 7) < 50 +3…+7 > 5 63
ZPD8.2 7.7 8.7 4.5 (< 7) < 50 +4…+7 > 6 57
ZPD9.1 8.5 9.6 5 (< 10) < 50 +5…+8 > 7 52
ZPD10 9.4 10.6 5.2 (< 15) < 70 +5…+8 > 7.5 47
ZPD11 10.4 11.6 6 (< 20) < 70 +5…+9 > 8.5 43
ZPD12 11.4 12.7 7 (< 20) < 90 +6…+9 > 9 39
ZPD13 12.4 14.1 9 (< 25) < 110 +7…+9 > 10 35
ZPD15 13.8 15.6 11 (< 30) < 110 +7…+9 > 11 32
ZPD16 15.3 17.1 13 (< 40) < 170 +8…+9.5 > 12 29
ZPD18 16.8 19.1 18 (< 50) < 170 +8…+9.5 > 14 26
ZPD20 18.8 21.2 20 (< 50) < 220 +8…+10 > 15 24
ZPD22 20.8 23.3 25 (< 55) < 220 +8…+10 > 17 21
ZPD24 22.8 25.6 28 (< 70) < 220 +8…+10 > 18 20
ZPD27 25.1 28.9 30 (< 80) < 250 +8…+10 > 20 17
ZPD30 28 32 35 (< 80) < 250 +8…+10 > 22 16
ZPD33 31 35 40 (< 80) < 250 +8…+10 > 24 14
ZPD36 34 38 40 (< 90) < 250 +8…+10 > 26 13
ZPD39 37 41 50 (< 90) < 300 +10…+12 > 28 12
ZPD43 40 46 60 (< 100) < 500 +10…+12 > 30 11
ZPD47 44 50 70 (< 110) < 700 +10…+12 > 33 10
ZPD51 48 54 80 (< 125) < 700 +10…+12 > 36 9
ZPD56 52 60 90 (< 135) < 750 +10…+12 > 39 8
ZPD62 58 66 100 (< 150) < 800 +10…+12 > 44 8
ZPD68 64 72 110 (< 200) < 850 +10…+12 > 48 7
ZPD75 70 79 120 (< 250) < 900 +10…+12 > 52 6
3,4
Disclaimer: See data book page 2 or website
Haftungssauschluss: Siehe Datenbuch Seite 2 oder Internet
3,4 Notes see previous page – Fußnoten siehe vorhergehende Seite
