TEW-432BRP 54Mbps 802.11g Wireless Router Quick Installation Guide Routeur sans file 802,11g 54Mbps Guide d'installation rapide Drahtloser 54 MBit/s 802.11g Router Kurzanleitung zur Installation Enrutador inalámbrico 802.11g a 54Mbps Guía de instalación rápida Маршрутизатор 54 Мбит/сек 802.11g Wireless Руководство по быстрой установ Version 07.15.05 TRENDnet TRENDware, USA What's Next in Networking Copyright ©2005. All Rights Reserved. TRENDware International, Inc.
Table of Contents English ................................................................................................................... 1. Prepare for Installation ................................................................................... 2. Install Hardware ............................................................................................. 3. Configure your AP/Router .............................................................................. 4.
English QIG 1. Prepare for Installation Thank you for purchasing the TEW-432BRP. This Wireless AP/Router will allow you to securely share your Internet connection, files, and other resources with multiple users. This guide will help you set up and configure your AP/Router. Following the installation instructions should be quick and easy. If you run into problems, please refer to the Troubleshooting section or the more detailed installation procedures on the User's Guide CD-ROM.
Collect Account Information from Internet Service Provider (ISP) During the installation of your AP/Router, the configuration utility will ask you to specify your ISP connection type. Therefore, please verify your Cable or DSL Internet broadband connection with your ISP and ensure you have all the information for one of the following connection types: Dynamic IP Cable Connection Nothing is required. The IP address will be automatically assigned by your ISP.
2. Install Hardware 1. Connect one RJ-45 network cable from the Cable/DSL Modem's Ethernet port to the WAN port on the AP/Router. 2. Connect a different RJ-45 network cable from one of the AP/Router's LAN ports to your computer's network port. 3. Turn on your Cable/DSL modem. 4. Connect the included Power Adapter from your AP/Router to a power outlet; your AP/Router should turn on. 5.
3. Configure your AP/Router The following section will help you configure your AP/Router to connect to the Internet and your PCs. The setup differs and is dependent on the type of Internet connection you have. If you are not sure what type of connection you have, please contact your ISP to obtain the required information, which is listed in the Prepare for Installation section at the beginning of this Quick Installation Guide. 1. Open your web browser, type http://192.168.1.
4. The “Wireless Router Setup Wizard” will appear. Click Next. 5. If you want to change your password for your router, then type the new password in the Password and Verify Password fields. Click Next. 6. Choose the appropriate Time Zone from the pull down menu, and click Next.
7. If you want to assign your router to a different network segment, then change the LAN IP Address and Subnet Mask. Make sure that the Range Start and Range End IP addresses match your network segment. Otherwise, click Next. 8. Select your Connection Type from the pull down menu, (Obtain IP automatically, Fixed IP address, PPPoE, or PPTP) and proceed to the appropriate subset of instructions below. Obtain IP automatically (DHCP client) 9.
Fixed IP Address 11. Select Fixed IP address and click Next. 12. Enter the WAN IP Address, WAN Subnet Mask, WAN Gateway Address and DNS Server provided by your ISP and click Next. 13. Go to step 19. PPPoE to obtain IP automatically 14. Select PPPoE to obtain IP automatically as the Connection Type and click Next.
15. Enter your username and password. Click Next. 16. Go to step 19. PPTP 17. Select PPTP as the Connection Type and click Next. 18. Enter the IP Address, Subnet Mask, Gateway, Server IP, PPTP Account, and PPTP Password. Click Next.
19. The recommended settings will be automatically selected for you. You may, however, choose to select a different channel and/or network name (SSID). Click Next. 20. Click Restart. 21. Click Close. Congratulations! Installation is now complete.
4. Connect your Wireless Adapter to the Router In this example, the TEW-441PC Wireless Utility will connect to the TEW-432BRP. 1. Double-click the Wireless Icon in your system tray. 2. Uncheck Use Windows to configure my wireless network settings and click OK. 3. Double-click the Wireless Icon in your system tray, click Site Survey, select the SSID assigned to the TEW-432BRP, and click Connect.
4. Click Apply. 5. Verify that your wireless adapter connects to the TEW-432BRP successfully.
5. Test your Connection Windows 2000/XP NOTE: You should disconnect the RJ-45 Ethernet cable from your computer's LAN port if you wish to test your wireless connection. 1. Click the Start button; click Run, type “cmd” in the text-field, and press the Enter key. 2. At the command prompt, type “ipconfig” and press the Enter key. 3. If the application displays an IP address of “192.168.1.x,” your computer is connected to your access point. 4. Open your web browser, type www.trendnet.
Windows 95/98/98SE/98ME NOTE: You should disconnect the RJ-45 Ethernet cable from your computer's LAN port if you wish to test your wireless connection. 1. Click the Start button; click Run, type “winipcfg” in the text-field, and press the Enter key. 2. Select your Wireless Network Adapter from the dropdown menu, and the utility will display your computer's current IP Address information. If the application displays an IP address of “192.168.1.x,” your computer is connecting to your access point. 3.
Troubleshooting For help with the TEW-432BRP's configuration and advanced settings, please refer to the User's Guide CD-ROM. Q1. I specified the IP address “192.168.1.1” in my web browser, but an error message says "The page cannot be displayed." How can I get into the TEW-432BRP web configuration page? A1.
TRENDnet TRENDware, USA What's Next in Networking @ Product Warranty Registration Please take a moment to register your product online. Go to TRENDware’s website at http://www.TRENDNET.com TRENDnet Technical Support US/Canada Support Center Contact Telephone: 1(310) 626-6252 Fax: 1(310) 626-6267 Email: support@trendnet.
