Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm)
TL4050A41QDBZR SOT-23 DBZ 3 3000 203.0 203.0 35.0
TL4050A41QDBZT SOT-23 DBZ 3 250 203.0 203.0 35.0
TL4050A41QDCKR SC70 DCK 5 3000 203.0 203.0 35.0
TL4050A41QDCKT SC70 DCK 5 250 203.0 203.0 35.0
TL4050A50IDBZR SOT-23 DBZ 3 3000 203.0 203.0 35.0
TL4050A50IDBZT SOT-23 DBZ 3 250 203.0 203.0 35.0
TL4050A50IDCKR SC70 DCK 5 3000 203.0 203.0 35.0
TL4050A50IDCKT SC70 DCK 5 250 203.0 203.0 35.0
TL4050A50QDBZR SOT-23 DBZ 3 3000 203.0 203.0 35.0
TL4050A50QDBZT SOT-23 DBZ 3 250 203.0 203.0 35.0
TL4050A50QDCKR SC70 DCK 5 3000 203.0 203.0 35.0
TL4050A50QDCKT SC70 DCK 5 250 203.0 203.0 35.0
TL4050B10IDBZR SOT-23 DBZ 3 3000 203.0 203.0 35.0
TL4050B10IDBZT SOT-23 DBZ 3 250 203.0 203.0 35.0
TL4050B10IDCKR SC70 DCK 5 3000 203.0 203.0 35.0
TL4050B10IDCKT SC70 DCK 5 250 203.0 203.0 35.0
TL4050B10QDBZR SOT-23 DBZ 3 3000 203.0 203.0 35.0
TL4050B10QDBZT SOT-23 DBZ 3 250 203.0 203.0 35.0
TL4050B10QDCKR SC70 DCK 5 3000 203.0 203.0 35.0
TL4050B10QDCKT SC70 DCK 5 250 203.0 203.0 35.0
TL4050B25IDBZR SOT-23 DBZ 3 3000 203.0 203.0 35.0
TL4050B25IDBZT SOT-23 DBZ 3 250 203.0 203.0 35.0
TL4050B25IDCKR SC70 DCK 5 3000 203.0 203.0 35.0
TL4050B25IDCKT SC70 DCK 5 250 203.0 203.0 35.0
TL4050B25QDBZR SOT-23 DBZ 3 3000 195.0 200.0 45.0
TL4050B25QDBZT SOT-23 DBZ 3 250 203.0 203.0 35.0
TL4050B25QDCKR SC70 DCK 5 3000 203.0 203.0 35.0
TL4050B25QDCKT SC70 DCK 5 250 203.0 203.0 35.0
TL4050B41IDBZR SOT-23 DBZ 3 3000 203.0 203.0 35.0
TL4050B41IDBZT SOT-23 DBZ 3 250 203.0 203.0 35.0
TL4050B41IDCKR SC70 DCK 5 3000 203.0 203.0 35.0
TL4050B41IDCKT SC70 DCK 5 250 203.0 203.0 35.0
TL4050B41QDBZR SOT-23 DBZ 3 3000 203.0 203.0 35.0
TL4050B41QDBZT SOT-23 DBZ 3 250 203.0 203.0 35.0
TL4050B41QDCKR SC70 DCK 5 3000 203.0 203.0 35.0
TL4050B41QDCKT SC70 DCK 5 250 203.0 203.0 35.0
TL4050B50IDBZR SOT-23 DBZ 3 3000 203.0 203.0 35.0
TL4050B50IDBZT SOT-23 DBZ 3 250 195.0 200.0 45.0
TL4050B50IDCKR SC70 DCK 5 3000 203.0 203.0 35.0
TL4050B50IDCKT SC70 DCK 5 250 203.0 203.0 35.0
TL4050B50QDBZR SOT-23 DBZ 3 3000 203.0 203.0 35.0
TL4050B50QDBZT SOT-23 DBZ 3 250 195.0 200.0 45.0
TL4050B50QDCKR SC70 DCK 5 3000 203.0 203.0 35.0
TL4050B50QDCKT SC70 DCK 5 250 203.0 203.0 35.0
PACKAGE MATERIALS INFORMATION
www.ti.com 25-Sep-2013
Pack Materials-Page 5
