LMV7235, LMV7239
SNOS532M –SEPTEMBER 2000–REVISED FEBRUARY 2013 www.ti.com
2.7V Electrical Characteristics (continued)
Unless otherwise specified, all limits guaranteed for T
A
= 25°C, V
CM
= V
+
/2, V
+
= 2.7V, V
−
= 0V
−
. Boldface limits apply at the
temperature extremes.
Symbol Parameter Conditions Min
(1)
Typ
(2)
Max
(1)
Units
0V < V
CM
< 2.7V
CMRR Common Mode Rejection Ratio 52 62 dB
(3)
PSRR Power Supply Rejection Ratio V
+
= 2.7V to 5V 65 85 dB
V
CM
Input Common-Mode Voltage Range CMRR > 50dB V
−
−0.1V
−
−0.2 to 2.9 V
+
+0.1V
+
V
I
L
= 4mA,
V
+
−0.35 V
+
−0.26 V
V
ID
= 500mV
Output Swing High
(LMV7239 only)
I
L
= 0.4mA,
V
+
−0.02 V
V
ID
= 500mV
V
O
I
L
= −4mA, 230 350
mV
V
ID
= −500mV 450
Output Swing Low
(LMV7235/LMV7239/LMV7239Q)
I
L
= −0.4mA,
15 mV
V
ID
= −500mV
Sourcing, V
O
= 0V
(LMV7239 only) 15 mA
(4)
I
SC
Output Short Circuit Current
Sinking, V
O
= 2.7V
(LMV7235, R
L
= 10k) 20 mA
(4)
52 85
I
S
Supply Current No load µA
100
Overdrive = 20mV
C
LOAD
= 15pF 96 ns
(5)
Overdrive = 50mV
t
PD
Propagation Delay C
LOAD
= 15pF 87 ns
(5)
Overdrive = 100mV
C
LOAD
= 15pF 85 ns
(5)
Propagation Delay Skew Overdrive = 20mV
t
SKEW
2 ns
(LMV7239 only)
(6)
LMV7239/LMV7239Q
1.7 ns
10% to 90%
t
r
Output Rise Time
LMV7235
10% to 90% 112 ns
(5)
t
f
Output Fall Time 90% to 10% 1.7 ns
Output Leakage Current
I
LEAKAGE
3 nA
(LMV7235 only)
(3) CMRR is not linear over the common mode range. Limits are guaranteed over the worst case from 0 to V
CC/2
or V
CC/2
to V
CC
.
(4) Applies to both single-supply and split-supply operation. Continuous short circuit operation at elevated ambient temperature can result in
exceeding the maximum allowed junction temperature of 150°C. Output currents in excess of ±30mA over long term may adversely
affect reliability.
(5) A 10k pull-up resistor was used when measuring the LMV7235. The rise time of the LMV7235 is a function of the R-C time constant.
(6) Propagation Delay Skew is defined as the absolute value of the difference between t
PDLH
and t
PDHL
.
4 Submit Documentation Feedback Copyright © 2000–2013, Texas Instruments Incorporated
Product Folder Links: LMV7235 LMV7239
