Datasheet
Table Of Contents
- FEATURES
- Applications
- DESCRIPTION
- Absolute Maximum Ratings
- Operating Ratings
- 5.0V DC Electrical Characteristics
- 5.0V AC Electrical Characteristics
- 2.7V DC Electrical Characteristics
- 2.7V AC Electrical Characteristics
- 24V DC Electrical Characteristics
- 24V AC Electrical Characteristics
- Typical Performance Characteristics
- Application Information
- Revision History
*All dimensions are nominal
Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm)
LM6152ACMX SOIC D 8 2500 367.0 367.0 35.0
LM6152ACMX/NOPB SOIC D 8 2500 367.0 367.0 35.0
LM6152BCMX SOIC D 8 2500 367.0 367.0 35.0
LM6152BCMX/NOPB SOIC D 8 2500 367.0 367.0 35.0
LM6154BCMX/NOPB SOIC D 14 2500 367.0 367.0 35.0
PACKAGE MATERIALS INFORMATION
www.ti.com 23-Sep-2013
Pack Materials-Page 2
