LM2675
SNVS129E –MAY 2004–REVISED JUNE 2005 www.ti.com
Table 1. Inductor Manufacturers' Part Numbers (continued)
Schott Renco Pulse Engineering Coilcraft
Ind.
Inductance Current
Ref. Through Surface Through Surface Through Surface Surface
(μH) (A)
Desg.
Hole Mount Hole Mount Hole Mount Mount
L23 33 1.40 67144090 67144470 RL-5471-7 — PE-53823 PE-53823-S DO3316-333
L24 22 1.70 67148370 67148480 RL-1283-22-43 — PE-53824 PE-53824-S DO3316-223
L27 220 1.00 67144110 67144490 RL-5471-2 — PE-53827 PE-53827-S DO5022P-224
L28 150 1.20 67144120 67144500 RL-5471-3 — PE-53828 PE-53828-S DO5022P-154
L29 100 1.47 67144130 67144510 RL-5471-4 — PE-53829 PE-53829-S DO5022P-104
L30 68 1.78 67144140 67144520 RL-5471-5 — PE-53830 PE-53830-S DO5022P-683
Table 2. Inductor Manufacturers' Phone Numbers
Coilcraft Inc. Phone [phone]
FAX [phone]
Coilcraft Inc., Europe Phone [phone]
FAX [phone]
Pulse Engineering Inc. Phone [phone]
FAX [phone]
Pulse Engineering Inc., Europe Phone [phone]
FAX [phone]
Renco Electronics Inc. Phone [phone]
FAX [phone]
Schott Corp. Phone [phone]
FAX [phone]
Table 3. Output Capacitor Table
Output Capacitor
Surface Mount Through Hole
Output
Inductance
Voltage Sprague AVX TPS Sanyo OS-CON Sanyo MV-GX Nichicon Panasonic
(μH)
(V)
594D Series Series SA Series Series PL Series HFQ Series
(μF/V) (μF/V) (μF/V) (μF/V) (μF/V) (μF/V)
22 120/6.3 100/10 100/10 330/35 330/35 330/35
33 120/6.3 100/10 68/10 220/35 220/35 220/35
47 68/10 100/10 68/10 150/35 150/35 150/35
3.3
68 120/6.3 100/10 100/10 120/35 120/35 120/35
100 120/6.3 100/10 100/10 120/35 120/35 120/35
150 120/6.3 100/10 100/10 120/35 120/35 120/35
22 100/16 100/10 100/10 330/35 330/35 330/35
33 68/10 10010 68/10 220/35 220/35 220/35
47 68/10 100/10 68/10 150/35 150/35 150/35
5.0
68 100/16 100/10 100/10 120/35 120/35 120/35
100 100/16 100/10 100/10 120/35 120/35 120/35
150 100/16 100/10 100/10 120/35 120/35 120/35
