RM46L852
SPNS185C –SEPTEMBER 2012 –REVISED JUNE 2015
www.ti.com
4.3.2.23 Supply for I/O Cells: 3.3V nominal
Table 4-50. ZWT Supply for I/O Cells: 3.3V nominal
Terminal Signal Reset Pull Pull Type Description
Type State
Signal Name 337
ZWT
VCCIO F6 3.3V N/A None Operating supply for I/Os
Power
VCCIO F7
VCCIO F11
VCCIO F12
VCCIO F13
VCCIO F14
VCCIO G6
VCCIO G14
VCCIO H6
VCCIO H14
VCCIO J6
VCCIO L14
VCCIO M6
VCCIO M14
VCCIO N6
VCCIO N14
VCCIO P6
VCCIO P7
VCCIO P8
VCCIO P9
VCCIO P12
VCCIO P13
VCCIO P14
50 Terminal Configuration and Functions Copyright © 2012–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: RM46L852
