RM46L852
www.ti.com
SPNS185C –SEPTEMBER 2012–REVISED JUNE 2015
Table 4-36. ZWT Multibuffered Serial Peripheral Interface Modules (MibSPI) (continued)
Terminal Signal Reset Pull Pull Type Description
Type State
Signal Name 337
ZWT
MIBSPI5CLK/MII_TXEN/RMII_TXEN H19 I/O Pullup Programmable, MibSPI5 clock, or GPIO
20 µA
MIBSPI5NCS[0]/EPWM4A E19 MibSPI5 chip select, or
GPIO
MIBSPI5NCS[1] B6
MIBSPI5NCS[2] W6
MIBSPI5NCS[3] T12
MIBSPI5NENA/MII_RXD[3]/ H18 MibSPI5 enable, or GPIO
USB1.VM/MIBSPI5SOMI[1]/ECAP5
MIBSPI5SIMO[0]/MIBSPI5SOMI[2]/MII_TXD[1]/RMII_TXD[1] J19 MibSPI5 slave-in master-
out, or GPIO
MIBSPI5SIMO[1] E16
MIBSPI5SIMO[2] H17
MIBSPI5SIMO[3] G17
MIBSPI5SOMI[0]/MII_TXD[0]/RMII_TXD[0] J18 MibSPI5 slave-out master-
in, or GPIO
MIBSPI5SOMI[1] E17
MIBSPI5NENA/MII_RXD[3]/ H18
USB1.VM/MIBSPI5SOMI[1]/ECAP5
MIBSPI5SOMI[2] H16
MIBSPI5SIMO[0]/MIBSPI5SOMI[2]/MII_TXD[1]/RMII_TXD[1] J19
MIBSPI5SOMI[3] G16
