RM46L852
www.ti.com
SPNS185C –SEPTEMBER 2012–REVISED JUNE 2015
Table 6-36. ESM Channel Assignments (continued)
ERROR Condition Group Channels
MibADC1 - RAM parity error Group1 19
Reserved Group1 20
DCAN1 - RAM parity error Group1 21
DCAN3 - RAM parity error Group1 22
DCAN2 - RAM parity error Group1 23
MibSPI5 - RAM parity error Group1 24
Reserved Group1 25
RAM even bank (B0TCM) - correctable ECC error Group1 26
CPU - self-test failed Group1 27
RAM odd bank (B1TCM) - correctable ECC error Group1 28
Reserved Group1 29
DCC1 - error Group1 30
CCM-R4 - self-test failed Group1 31
Reserved Group1 32
Reserved Group1 33
N2HET2 - RAM parity error Group1 34
FMC - correctable ECC error (Bank 7 access) Group1 35
FMC - uncorrectable ECC error (Bank 7 access) Group1 36
IOMM - Access to unimplemented location in IOMM frame, or write access Group1 37
detected in unprivileged mode
Power domain controller compare error Group1 38
Power domain controller self-test error Group1 39
eFuse Controller Error – this error signal is generated when any bit in the eFuse Group1 40
controller error status register is set. The application can choose to generate an
interrupt whenever this bit is set to service any eFuse controller error conditions.
eFuse Controller - Self Test Error. This error signal is generated only when a self Group1 41
test on the eFuse controller generates an error condition. When an ECC self test
error is detected, group 1 channel 40 error signal will also be set.
PLL#2 - Slip Group1 42
Ethernet Controller bus master access error Group1 43
USB Host Controller master interface Group1 44
Reserved Group1 45
Reserved Group1 46
Reserved Group1 47
Reserved Group1 48
Reserved Group1 49
Reserved Group1 50
Reserved Group1 51
Reserved Group1 52
Reserved Group1 53
Reserved Group1 54
Reserved Group1 55
Reserved Group1 56
Reserved Group1 57
Reserved Group1 58
Reserved Group1 59
Reserved Group1 60
Reserved Group1 61
DCC2 - error Group1 62
Copyright © 2012–2015, Texas Instruments Incorporated System Information and Electrical Specifications 113
Submit Documentation Feedback
Product Folder Links: RM46L852
