4.3 Terminal Functions
Section 4.3.1 and Section 4.3.2 identify the external signal names, the associated pin/ball numbers along
with the mechanical package designator, the pin/ball type (Input, Output, IO, Power or Ground), whether
the pin/ball has any internal pullup/pulldown, whether the pin/ball can be configured as a GPIO, and a
functional pin/ball description. The first signal name listed is the primary function for that terminal. The
signal name in Bold is the function being described. Refer to the I/O Multiplexing Module (IOMM) chapter
of the RM46x Technical Reference Manual (SPNU514).
NOTE
In the Terminal Functions table below, the "Reset Pull State" is the state of the pull applied to
the terminal while nPORRST is low and immediately after nPORRST goes High. The default
pull direction may change when software configures the pin for an alternate function. The
"Pull Type" is the type of pull asserted when the signal name in bold is enabled for the given
terminal by the IOMM control registers.
All I/O signals except nRST are configured as inputs while nPORRST is low and
immediately after nPORRST goes High. While nPORRST is low, the input buffers
are disabled, and the output buffers are disabled with the default pulls enabled.
All output-only signals have the output buffer disabled and the default pull enabled
while nPORRST is low, and are configured as outputs with the pulls disabled
immediately after nPORRST goes High.
4.3.1 PGE Package
4.3.1.1 Multibuffered Analog-to-Digital Converters (MibADC)
Table 4-1. PGE Multibuffered Analog-to-Digital Converters (MibADC1, MibADC2)
Terminal Signal Reset Pull Pull Type Description
Type State
Signal Name 144
PGE
ADREFHI
(1)
66 Power N/A None ADC high reference
supply
ADREFLO
(1)
67 Power ADC low reference supply
VCCAD
(1)
69 Power Operating supply for ADC
VSSAD
(1)
68 Ground
AD1EVT/MII_RX_ER/RMII_RX_ER 86 I/O Pulldown Programmable, ADC1 event trigger input,
20 µA or GPIO
MIBSPI3NCS[0]/AD2EVT/GIOB[2]/ 55 I/O Pullup Programmable, ADC2 event trigger input,
EQEP1I/N2HET2_PIN_nDIS 20 µA or GPIO
AD1IN[0] 60 Input N/A None ADC1 analog input
AD1IN[1] 71
AD1IN[2] 73
AD1IN[3] 74
AD1IN[4] 76
AD1IN[5] 78
AD1IN[6] 80
AD1IN[7] 61
(1) The ADREFHI, ADREFLO, VCCAD and VSSAD connections are common for both ADC cores.
