DAC8562, DAC8563
DAC8162, DAC8163
DAC7562, DAC7563
www.ti.com
SLAS719D –AUGUST 2010–REVISED AUGUST 2012
REVISION HISTORY
Changes from Revision C (June 2011, first official release) to Revision D Page
• Replaced text "QFN" with "SON" (name change only, package/orderable did not change) ................................................ 1
• Typical power-down current consumption changed from 10 nA to 550 nA. ......................................................................... 1
• Changed power requirements specifications ........................................................................................................................ 5
• Power-down current vs Temperature typical characteristic plot updated, AV
DD
= 5.5 V .................................................... 15
• Power-down current vs Power-supply voltage typical characteristic plot updated ............................................................. 15
• Power-down current vs Temperature typical characteristic plot updated, AV
DD
= 2.7 V .................................................... 23
• Added Power-On Reset (POR) Levels section ................................................................................................................... 30
