Specification Sheet

LOW
LEAD
COMPLIANT
5 11/16"
144mm
6 5/8"
169mm
16"
406mm
10 11/16"
271mm
1 1/4"
32mm
Maximum
Thickness
4 1/4"
108mm
One Year (Limited)
Variations Specified__________________________
Concealed Widespread Lavatory Faucet
Architect/Engineering Specifications:
08/28/17
Date:
Medical and Lavatory Faucets
Date______________________________________
Job Name__________________________________
Model Specified________________Quantity_______
Flow Rate: 1.4 GPM @ 60 psi •
Ph 800-476-4103
•
• ANSI A117.1 (ADA)
• NSF 372 (Low Lead Content)
• NSF 61 - Section 9
• ASME A112.18.1 / CSA B125.1
Product Compliance:
Fax [phone]
•
•
Simi Valley, CA www.tsbrass.com
B-2866-05-FC15
T&S BRASS AND BRONZE WORKS, INC.
Features & Benefits:
•
Ph 800-423-0150
•
Travelers Rest, SC 29690 • 2 Saddleback Cove
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 140 F•
Warranty:
TAG:
Push Button Metering
Quarter-Turn Eterna
Pivot Action Metering
Wrist Action Metering
4” wrist action handles w/ color coded indexes
Plain end outlet
•
•
1/2" NPSM male inlets w/ coupling nuts
Eterna compression cartridges
•
•
Material: Forged brass body, chrome plated metal handles,
1.4 GPM flow control (pre-installed in swivel center flange)
8" concealed deck mount mixing faucet, swivel gooseneck with plain end outlet, compression cartridges, 1.4 GPM flow control, 4” wrist action
•
tubular spout
& escutcheons and polished chrome plated brass
•
and NSF 372. Meets ADA ANSI/ICC A117.1 requirements.
handles, chrome plated escutcheons and 1/2" NPSM male inlets with coupling nuts. Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9
8" EasyInstall concealed deck mount faucet w/ forged •
brass body
5 11/16" swivel gooseneck w/ swivel-to-rigid washer to convert•
swivel gooseneck to rigid
Optional Cartridges
Quarter-Turn Cerama
Eterna (Standard)
Optional Handles
4" Wrist Action (Standard)
Lever
4-Arm
