BEVERAGE MERCHANDISER INSTRUCTION MANUAL Model Nos.: ALBV15 / SCR1536B / SCR1536BG / SCR2464 / SCR1005W / SCR1155W / SCR1400W / SCR1400WLH c F BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Write Model and Serial No. (on lower left corner of inside cabinet) here: Model: _______________________________________ Serial No.: _____________________________ Felix Storch, Inc. Summit Appliance Division ISO 9001:2015 registered 770 Garrison Avenue Bronx, NY10474 www.
TABLE OF CONTENTS Appliance Safety 3 Important Safeguards 3-4 Location of Parts 5-7 Installation Instructions 8-10 Before Using Your Appliance 8 Installation of Your Appliance 8 Electrical Connection 8-9 Extension Cord 9 Reversing the Door Swing of Your Appliance 9-10 Adjusting the Height of the Unit (Only for ALBV15) 10 Adjusting the Kick-plate (Only for ALBV15) 10 Installing the Stainless Steel Handle 10 Operating Your Appliance 10-13 Control Panel 11 Interior Light 11 Sabbat
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. All safety messages will follow the Safety Alert Symbol and either the words "DANGER" or "WARNING".
parts of the cooling system are damaged. Leaking coolant can ignite and may damage the eyes. In the event of any damage: - Avoid open flames and anything that creates a spark, - Disconnect from the electrical power line, - Air the room in which the appliance is located for several minutes and - Contact the Service Department for advice. The more coolant there is in an appliance, the larger the room it should be installed in.
LOCATION OF PARTS MODEL ALBV15 Digital Control Panel Door Glass Shelves (3) Handle Security Lock Ventilation Grille Adjustable Legs Cabinet MODELS SCR1536B/SCR1536BG Digital Control Panel Door Shelves (3) Handle Security Lock Ventilation Grille Adjustable Legs Cabinet 5
MODEL SCR2464 Digital Control Panel Door Shelves (3) Handle Security Lock Ventilation Grille Adjustable Legs Cabinet MODEL SCR1005W Condenser Digital Control Panel c F Door Shelves (4) Handle Security Lock Adjustable Legs Cabinet 6
MODEL SCR1155W Digital Control Panel Door Shelves (4) Handle Security Lock Ventilation Grille Adjustable Legs Cabinet MODELS SCR1400W / SCR1400WLH* Digital Control Panel Door Shelves (6) Handle Security Lock Ventilation Grille Adjustable Legs Cabinet * NOTE: Model SCR1400WLH opens from the right, so handle is on that side.
INSTALLATION INSTRUCTIONS BEFORE USING YOUR APPLIANCE Remove the exterior and interior packing. CAUTION: After unpacking you MUST allow this appliance to stand upright for at least 2 hours to allow the lubricant and refrigerant to drain back into the compressor and stabilize. Failure to do so may adversely affect performance and the lifetime of this unit. Clean the interior surface with lukewarm water using a soft cloth. Install the handle on the door. (See page 10.
When a standard 2-prong wall outlet is encountered, it is your responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet. To prevent accidental injury, the cord should be secured behind the appliance and not left exposed or dangling. The appliance should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating label on the appliance.
6. Relocate the door to the designated position. Then screw the bottom hinge assembly on the left designated position and tighten it after the door is leveled. (Fig. 1) 7. Remove the handle from the left side of the door and install it on the right side. (See below.) ADJUSTING THE HEIGHT OF THE UNIT (Only for ALBV15) The height of the ALBV15 can be increased by up to 3” by turning the adjustable legs.
CONTROL PANEL ON/OFF Power To turn the appliance ON or OFF, touch the symbol and hold for 5 seconds. NOTE: Touching the POWER key once can switch off the audible alarm when the alarm is on. LIGHT Turns the inner light ON and OFF. UP Used to increase (warm) the set temperature by 1°C/1ºF. DOWN Used to decrease (cool) the set temperature by 1°C/1ºF. ºF/ºCSelector Select the temperature display setting in Fahrenheit or Celsius degrees.
SABBATH MODE Sabbath mode is available for the observance of certain religious holidays. This mode turns off the displays, interior light and audible alarms and prevents them from turning on again. Normal cooling operations will still take place. To initiate Sabbath mode, touch the POWER and LIGHT keys at the same time for at least 5 seconds. The indicator light will flash four times and confirm the Sabbath mode is ON. Sabbath mode can be turned off by repeating the above process.
DEFROSTING The unit defrosts automatically in normal operating conditions. The evaporator behind the rear wall of the unit defrosts automatically. The condensate collects in the drainage channel behind the rear wall of the unit, and flows through the drainage hole into the drip tray by the compressor where it evaporates. However, frost may accumulate on the evaporator if the unit is repeatedly opened in a high heat or high humidity location.
CARE AND MAINTENANCE CLEANING YOUR BEVERAGE MERCHANDISER CAUTION: Failure to unplug the appliance during cleaning could result in electrical shock or other personal injury. Turn off the power, unplug the appliance, and remove all items, including shelves. Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking soda to a quart of water). Wash the shelves with a mild detergent solution.
TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. Troubleshooting Guide PROBLEM Appliance does not operate. POSSIBLE CAUSE Appliance is not connected to a power supply. The appliance is turned off. Tripped circuit breaker or a blown fuse. The temperature is not set correctly. The ambient temperature could require a lower set temperature setting.
Display “E0”, “E1”. “E2”, “E3”, “E4”, “E5”,“E6” or “E7”. The alarm sounds and the temperature display flashes. The icon “--” is lit up and flashing in the temperature display. The gasket is dirty. The shelves are out of position. “E0”indicates a communication error for 3-zone models. “E1” or “E2” indicates that the air temperature sensor has failed. “E3” or “E4”indicates that the defrost sensor in the evaporator has failed. “E5” indicates a defrost heater failure.
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company. Outside the 48 states, all parts are warranted for one year from manufacturing defects.
