WARNINGS! INSTALLATION • Read the instructions closely before installing and/or using the hood. • The manufacturer will not be held liable for damage caused by installation that is incorrect or not up to standard. • We recommend that all installation and adjustment procedures are carried out by trained personnel. • When the hood is taken out of its packaging inspect it to ensure that it is intact. If the product is damaged, do not use it and contact the Smeg assistance service.
been given instructions on safe use of the appliance and are familiar with the dangers it entails. • Children must be supervised to ensure that they do not play with the appliance • “ATTENTION: The accessible parts can become very hot if they are used with cooking equipment." MAINTENANCE • Before carrying out any maintenance procedure or cleaning, disconnect the appliance from the electricity supply.
INSTALLATION INSTRUCTIONS: The hood is supplied with all the accessories necessary for its installation. The minimum distance between the lower surface of the hood and the hob must be at least 750 mm for gas hobs and 650mm for electric hobs (Fig. 1 ). If the motor inlet is equipped with a non-return valve for fumes, make sure it can open and close freely. For easy installation it is recommended to follow the procedures described below: 1) The hood must be centred with respect to the hob surface.
FILTER version: Leave the motor inlet free. Install the active carbon filters as shown on page 8. If the hood is not supplied with an active carbon filter you must buy it separately at your nearest authorised Smeg dealer. For some models there is a standard set of fittings (fig.5) to be fixed to the wall by expansion plugs at a suitable height in order to channel the airflow in correspondence with the flue slits. Insert laterally the extensions R2 on the fitting R1.
USER INSTRUCTIONS: • CONTROLS UNIT For an optimal and efficient use of the product it is advisable to start the hood a few minutes before you start cooking and to keep it on for at least 15min after you have finished cooking or until steam and odours have completely disappeared. To start the hood, identify the command type of the hood and then follow the relative indications: SLIDER: - Slider (A) lighting ON/OFF - Slider (B) with four positions: Pos.
speed timer has expired it returns to the third speed by default. 2-DIGIT 10-KEY CAPACITIVE PUSHBUTTON BOARD: Control panel Key A B C D E F G H 1 L EN Function Turns the suction motor on / off. Decreases the operation speed. Increases the operation speed. Activates the Intensive speed from any speed even with the motor off, this speed is timed. At the end, the system returns to the speed previously set. Suitable for dealing with the maximum emissions of cooking fumes.
Keyboard lock command: you can lock the keyboard, for example, to clean the glass surface, when the Hood has the motor and lights switched off. By pressing key D for about 5 seconds, you can enable or disable the keyboard lock which is always confirmed with: “- -” Keyboard lock On. 1-DIGIT CAPACITIVE PUSHBUTTON BOARD: CONTROL PANEL KEY FUNCTION DISPLAY A SWITCH THE SUCTION MOTOR ON / OFF.
the intensive speed timer has expired it returns to the third speed by default. OPTIONAL FUNCTIONS: - TIMED AUTO POWER OFF: By pressing one of the motor speed keys (2-3), twice, you will activate the function "Timed Auto Power Off" which turns off both lights and hood motor after 10 mins. Activating this function is demonstrated by the LED immediately above the pressed button flashing.
METAL FILTER CLEANING: Particular attention should be paid to the metal grease filter panels. The accumulation of grease inside the filter panels as well as affecting the performance of the extractor, can also create a fire hazard. In order to minimise the risk of fire, the filters must be cleaned regularly, at least once a month or with greater frequency in the case of a particularly intensive use of the appliance. After identifying your hood model, remove one filter at a time as shown in the next figure.
In the case of a cartridge filter blocked with a bracket and threaded knob, (fig. C), unscrew the knob, remove the locking bracket and then remove the active carbon filter.
WEEE DISPOSAL: Pursuant to art. 26 of the Italian Legislative Decree dated 14 March 2014, no. 49 "Implementation of directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE)" The crossed out wheeled bin symbol on the equipment or its packaging indicates that the product at the end of its useful life must be collected separately from other waste.
WARRANTY AND TECHNICAL ASSISTANCE SERVICE: The Smeg Warranty Booklet is provided in the hood packaging as well as in the Instructions for Use and Maintneance. We invite you to read the Smeg Warranty Booklet for complete and comprehensive information on the warranty. In case of failure, call the dedicated Customer Service number 199.135.135.* or look under Smeg in the phone book for the capital of your province, and always provide: • • • • the model, provided inside the hood (fig.
