Installation Guide

Sika
®
AnchorFix-1 and -2
Anchoring Adhesives
How-To-Use
Materials:
• Safety glasses and gloves • Utility knife
• Standard caulk gun • Rotary hammer drill
• Cartridge of Sika AnchorFix-1 or 2 • Nylon brush
Procedure
1. Remember to always wear chemical resistant gloves and safety
glasses at all times.
2. Drill a hole to the correct diameter and depth using a rotary ham-
mer drill.
3. Clean the hole using a stiff nylon brush and blow pump, or oil free
compressed air. Make sure all particles, dust, and loose debris are
all completely removed to ensure a proper bond.
4. Unscrew the cap on the Sika AnchorFix cartridge. Pull the red
plug and cut the plastic behind the clip attached to the red plug.
Next, attach the mixing nozzle over the cut plastic and insert the
cartridge into a standard caulk gun.
5. Squeeze the gun a few times to dispense the material through
the nozzle. Discard the rst part of the dispensed material until a
uniform gray color is achieved. If the hole is in hollow masonry,
use a perforated sleeve/screen.
6. Insert the mixer nozzle into the rear of the hole and start to
squeeze the gun to dispense the material. Withdraw the nozzle as
the hole is lled.
7. Immediately insert the rod and/or bolt into the hole. This should be
done slowly with a slight twisting motion. Excess adhesive should
be removed from the mouth of the hole before it sets.
8. Leave the rod/bolt undisturbed until the cure time has past, then
attach the xture and tighten necessary hardware.
9. Clean tools immediately with a solvent such as acetone, follow-
ing the manufacturer’s precautions. Cured material can only be
removed mechanically.
AnchorFix-1 SKU # 293-834
AnchorFix-2 SKU # 677-733
www.sikausa.com
