53
Useful
Features
Setting the FUNCTION
Button Operation
You can assign one of the following functions
to the FUNCTION button on the remote con-
trol. The assigned function can be performed
by just pressing FUNCTION.
Selectable items Description
Input Search Automatically searches for and
switches to the appropriate Input
mode.
Audio Mute For temporarily turning off the
sound. Press FUNCTION again
to turn on the sound
Image Shift For moving the projected image
vertically. (See page
47.)
Signal Info Input signal information is
displayed.
STANDBY Mode
When set to “Eco”, power consumption is
reduced in Standby mode.
Selectable
items
Description
Eco The monitor output, RS-232C and
Network functions are switched off in
Standby mode.
Quick Start The monitor output, RS-232C and
Network functions are activated even if
the projector is in Standby mode.
DLP
®
Link
TM
See the OPERATION MANUAL FOR
STEREOSCOPIC 3D PROJECTION provided
separately.
DLP
®
Link
TM
Invert
See the OPERATION MANUAL FOR
STEREOSCOPIC 3D PROJECTION provided
separately.
Menu operation n Page
40
Returning to the Default
Settings
This function allows you to initialize the
settings you have made in the projector.
The following items or menu cannot be
initialized.
- Resolution
- Language
- Lamp Timer (Life)
- System Lock
- COMPUTER2 Select
•
Note
Checking the Lamp
Life Status
You can confi rm the cumulative lamp usage
time and the remaining lamp life (percentage).
Lamp usage condition Remaining lamp life
“Life” 100% 5%
Operated exclusively
with “Eco+Quiet”
set to “On”
Approx.
4,000 hours
Approx.
200 hours
Operated exclusively
with “Eco+Quiet”
set to “Off”
Approx.
2,000 hours
Approx.
100 hours
It is recommended that the lamp be changed
when the remaining lamp life becomes 5%.
The lamp life may vary depending on the
usage condition.
•
•
Note
