INSTRUCTION GUIDE iUVC1 | UVC Smart Lamp Please carefully read this instruction guide before using the product
1. Overview Thank you for choosing the ARCHIPELAGO iUVC1 UVC Smart Lamp. Before using iUVC1, please read the instruction carefully in order to use this product in a safe and sound manner. If you have further questions and should problems persist, please email our after-sale service: iuvc1@archipelagolighting.com We welcome your valuable suggestions and feedback on this product. Special Statement: 1. The pictures in this manual are for reference only, please refer to the actual product. 2.
2. Product Specification Product Name Model Input Wattage Germicidal Factor Wavelength Size WiFi Mobile App OS iUVC1 UVC Smart Lamp iUVC1 100-240Vac | ~50/60Hz 36W UVC 254nm 18.5 x 7.7 x 7.7 inches WiFi 802.11B/G/N 2.4GHz Android 4.4 / iphoneOS 9.
3. Turning ON the Device 1. Manual Mode: Short press function button for fast, full, and custom time modes. The indicator of the corresponding mode flashes slowly during the switching process. After 10 seconds, UVC Smart Lamp starts, and the corresponding mode indicator will always be on. During the process, if the radar detects people or pets, it will stop operating. Short press again to continue. 2.
. Wireless Settings 1. Connect to WiFi router. Must be 2.4GHz band — this device will not connect to 5.0GHz network. 2. After the device is powered on, press and hold the switch button for 5 seconds to enter the network distribution mode, you can choose "Add Manually and "Auto-Scan" distribution network. 3.
. Key Light Indicator 1. After the device is powered on, the button indicator light is blue, and if connected to WIFI, it will turn to green. 2. Short press to switch between fast, fulI, and custom time modes. The indicator of the corresponding mode flashes slowly during the switching process. After 10 seconds, UVC Smart Lamp starts, the corresponding mode indicator will always be on.
. Power Failure Acknowledgements Status Fault Description UVC bulb is not ON Operation Fault Operation is terminated Buttons cannot be controlled WiFi Connection Fault The network connection is normal, but the APP cannot control the device
. Safety Precautions 1. Please do not touch the lamp when working, to avoid being burnt by the lamp. 2. During the process, humans, animals and plants should not be in the premises. 3. NOTE: UVC Smart Lamp works similar to the sun in that prolonged exposure can fade colors, including paintings and hardwood floors. 4. Do not bend of pull the AC cable. Damage to the cable may easily lead to accidents such as fire and electric shock. 5. Do not disassemble the product. 6.
. Limited Liability Warranty 1. “12 Month Limited Liability Warranty” – See https://archipelagolighting.com/support/warranty-statement/ for full details. 2. During the applicable Warranty Period set forth above relating to any Product, Seller warrants that the Products will be free from defects in material and workmanship (the “Limited Warranty”). This Limited Warranty extends only to the end‐user of the Products (the “Buyer”).
. Warnings Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This device complies with Part 18 of the FCC Rules. This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30 MHz. This equipment has been tested and found to comply with Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
