User Manual of WBS-502AC
-24-
20MHz
• Extension Channel
Select upper or lower channel. Your selection may affect the Auto
channel function.
• Channel
Select the appropriate channel and frequency.
Select Auto to enable auto-channel selection.
• Transmit Power
The transmission power of the device (value: auto).
To meet the regional regulation, this option is not allowed to be
configured through the user interface.
• Data Rate
Select a data rate from the drop-down list. The data rate affects
throughput. If you select a low data rate value, for example, the
throughput is reduced but the transmission distance increases. The
default is “Auto”.
• RTS/CTS Threshold (1-2346)
When the length of a data packet exceeds this value, the device will
send an RTS frame to the destination wireless node, and the latter will
reply with a CTS frame, and thus they are ready to communicate. The
default value is 2346. A small number causes RTS/CTS packets to be
sent more often and consumes more bandwidth.
• Client Limit
Specify the maximum clients allowed to connect to the radio interface.
• AP Detection
AP Detection can select the best channel to use by scanning nearby
areas for Access Points.
• Distance (1-30km)
Specify the distance between the master AP and slave AP. Longer
distances may drop high-speed connections.
• Save
Click Save to save changes.
