TECHNICAL MANUAL (Ver.2.0) MULTI PROJECTION SYSTEM RM-V1000NU Caution This symbol refers to a hazard or unsafe practice which can result in personal injury or property damage. Notes: • Pioneer will not be liable for any loss caused by defects of the parts supplied other than by Pioneer. • An damage during shipping will be compensated for only in the case where Pioneer's specific packing materials for shipping are used.
PIONEER RM-V1000NU MANUAL. This Acrobat (IE: a PDF file) version of the Pioneer RM-V1000NU manual was made from the original digital document and scanning an existing manual. Because of this, there are many less then perfect pages and hand written comments. As Pioneer is constantly working towards providing the best possible documentation for our products, there may be an improved version of this document available. Please contact your Pioneer representative for additional information.
CONTENTS CHAPTER 1. FEATURES OF RM-V1000NU ........................................................................... 4 1. FEATURES OF SYSTEM ...................................................................................................................... 4 CHAPTER 2 . GENERAL SPECIFICATIONS ........................................................................... 6 1. SPECIFICATIONS OF PRODUCT .........................................................................................................
CHAPTER 1. FEATURES OF RM-V1000NU 1. FEATURES OF SYSTEM ¶ Large screen with little reflection. The new tinted screen improves the screen contrast and vertical angle of view. Since reflection of external light has also been reduced, viewers feel no visual discomfort even in brightly lit event halls and showrooms. ¶ Use in bright places Realizing a high-luminance of 420ft-L for the screen brightness, it can be used adequately in lobbies and open spaces with external light. ¶ Ultra-thin mullion (approx.
FEATURES OF PROJECTION CUBE SYSTEM ¶ Convergence memory Apart from the standard values set at shipment, up to 3 kinds of data can be memorized for the adjusting value. ¶ Convenient “color mode selection switch” for camera-reexposure. A convenient “color mode selection switch” which can set two types of white balance data is provided. For example, when using the system as a monitor for reexposing in broadcast station studios, etc.
CHAPTER 2. GENERAL SPECIFICATIONS 1. SPECIFICATIONS OF PRODUCT (1) General Unit Specifications Coaxial cable with connector (no long discrimination tube) .......................... x 2 Coaxial cable with connector (with long discrimination tube (orange)) ........ x 2 Coaxial cable with connector (no short discrimination tube) ......................... x 2 Coaxial cable with connector (with long discrimination tube (orange)) ........ x 2 Cable clamp (For connecting coaxial cable with connector) .........
GENERAL SPECIFICATIONS Control Panel (Fig. 2-4) No. Name Type Function 1 ABL link switch Slide switch Used for switching the control level of the ABL link control voltage when ABL link is ON.
GENERAL SPECIFICATIONS (3) Multi Video Processor (Referred to MVP below) Input signal Output signal Input video signal (NTSC) Note 1 1-line ............................................. BNC terminal (One RGB input system can be added with addition of optional RGB board) 1 Composite video signal ...................... 1.0 V(p-p) (75ohm terminated) 2 Y/C separation signal Y (With sync) ................... 1.0 V(p-p) (75ohm) C burst level ................. 0.
GENERAL SPECIFICATIONS MVP Panel = 2 INPUT OUTPUT VOUT1 VOUT3 RESET 3 GEN LOCK VBS/G VBS/G NTSC RGB 4 FILTER 5 6 7 EXT INT ~ ON OFF G VBS Y B C Y/B Y/B VBS Y/C C/R VOUT2 C/R VOUT4 MODE RATE R 8 VBS/G VBS/G ! H/C SYNC Y/B Y/B VD C/R C/R 9 @ ON RS-232C 0 - 1 OFF POWER 1 POWER switch (Power) Used to turn on/off the MVP power. 2 Reset button System reset button.
GENERAL SPECIFICATIONS 7 MODE switch 9 RS-232C connector Used to select the video output mode. For controlling MVP Output Mode Switch Contents 0 RGB video input terminal (Optional) Output Mode Switch Frequency Output No. *2 Mode Mode VBS,Y/C 0 1 NTSC Standard Speed/ Double Speed *1 Standard Speed RGB Trunk Piece Mitigation Mode OFF Double Speed 2 3 4 RESERVED 5 6 - NTSC video input terminal 7 VBS,Y/C 8 9 Optional RGB input terminal. G .....................
GENERAL SPECIFICATIONS (4) Adjustment Control Unit (RU-V107) Option 84 DÎ ADJUSTMENT CONTROL UNIT RU-V107 0 ADJ IN 1 2 3 4 5 6 7 8 9 A D B E C F ADJ R ON/OFF G ADJ ON/OFF 187 POWER ADJ B ON/OFF INPUT SEL MAIN MENU 2 /– +/3 DISP CALL ADJ OUT Cable length : 5m 29 (Fig.2-7) Accessories AA dry battery (IEC R6P) ..................................................................................... 2 Cable (5m) .....................................................................
CHAPTER 3. ASSEMBLY INSTALLATION AND ASSEMBLY INSTALLATION AND 1. INSTALLATION CONDITIONS (1) Weight-tolerant The ground must be flat and horizontal. It should be able to bear the weight of the system. For wooden floors, if the part receiving the weight of the system lies at the center between the reinforcement beams below the floor, the floor may become deformed or may curve inwards. In such cases, lay a more than 12 mm thick board below the system to distribute the weight of the system on the floor.
INSTALLATION AND ASSEMBLY (6) Installation work for mounting on rack ¶ Blocking the front and back will cause heat to accumulate, which may result in malfunctions. ¶ Use a rack which can bear the weight of the system. ¶ Take measures to ensure that the system does not turn over. Always have experienced technicians or your dealer implement these measures. (7) Temperature and Humidity Conditions ¶ Closely observe the following conditions on the temperature and humidity of the location of installation.
INSTALLATION AND ASSEMBLY (9) Angle of view and appropriate view range Vertical Visible Angle (Fig.3-1) Horizontal Visible Angle (Fig.
INSTALLATION AND ASSEMBLY (10) Lighting ¶ Although reflection by external light as seen on CRTs will not occur with this projection screen, reflection may result when strong light such as spot light is directed at the screen. Therefore, make sure that the screens are not exposed to direct spotlight. ¶ For certain installation location conditions, a glass sheet may have to be attached to the screen surface. In this case, as there will be reflection by external light, consider the installation position, etc.
INSTALLATION AND ASSEMBLY (12) Power Supply 1 Power supply voltage The guaranteed voltage of this system is ±10% of the rated voltage. But if the impedance of the power wires is high, the voltage waveform will become distorted and show the same symptoms as when voltage drops abnormally. As the following must be noted even if the voltage is within the allowable range, check the power wiring again. ¶ The voltage drop from the switchboard to this system is great.
INSTALLATION AND ASSEMBLY (13) Cables Used Use a coaxial cable for the external input cable. Normally use a 3C-2V for less than 15m long. Use 5C-2V for greater lengths. Adjust the length of the cables. The distance between the transmission system and MPJ should be as short as possible. When the distance is great, consider the thickness of the cable and electrical compensation carefully. The limit is as shown when using the cables to connect the transmission final output terminal and the system.
INSTALLATION AND ASSEMBLY 2. INSTALLATION AND ASSEMBLY (1) Confirmation 1 Decide the position for installing the system according to the installation conditions in Chapter 3. Check Items [1] Dimensions of installing position, space at the back, distance to the ceiling [2] Floor flatness, strength, roughness [3] Position of power supply [4] Installing location Need for protection for the floor, walls, etc. (support covers, sheets, cover boards, etc.
INSTALLATION AND ASSEMBLY 3 Unpacking [1] Remove the top and side (the longer side) wood frames one by one. [2] Remove the upper cover and side cover. [3] Remove the unit from the frames. [4] Remove the upper pad and mirror mat. [5] Remove side pad, and top pad covering the unit. Remove the tapes for transportation protection. (Six in each unit) [6] While paying attention to the top and bottom of the unit, place the unit upright together with the under carton. (This should be done by more than 3 persons.
INSTALLATION AND ASSEMBLY [8] Top mirror pad B Top mirror pad A Bottom mirror pad A Mirror corner pad Bottom mirror pad B Engine side pad F Engine side pad Engine pad A MVP pad Engine pad B (Fig.
INSTALLATION AND ASSEMBLY 4 Projection Screen * Projection screen is double-packaged to maintain its performance. After removing the middle cover protecting its screen, make sure the screen does not get scratched or dirty. [1] Remove the top cover. [2] Remove the band securing the middle cover and remove the middle cover. [3] Gently peel off the black tape pasted at the four sides of the screen. * Be careful not to damage the lenticular sheet.
INSTALLATION AND ASSEMBLY (3) Carrying the Units After Opening Packaging 1 Screen To carry the screen unit after opening the packaging, hold them by the parts shown in the figure, and lift and move them. (Lifted by one or two persons) Hold the parts indicated by (Fig. 3-5) ¶ Never drag the system along the floor when moving the units. ¶ The lenticular sheet damages very easily as it is very thin. Therefore move it gently and do not apply excessive shock or vibration to it.
INSTALLATION AND ASSEMBLY 3. PRECAUTIONS FOR TRANSPORTATION Do not stack the units on their sides or backs when transporting them. Always place them upright. If they are stacked on their sides or backs, vibration and shock may cause damage or fire hazards. 7 Precautions on transportation of unit ¶ Because it damages easily when dropped, exposed to shock or vibrations, be careful not to place heavy objects on the unit nor drop it in transportations.
INSTALLATION AND ASSEMBLY ¶ When transporting or storing the units in the packaged state, always face them up. ¶ The number of units that can be stacked in storage is 16. ¶ As the screen is at the top, be careful not to step, and place heavy objects on this top side, nor hit it with sharp objects. ¶ Do not mistake the top and bottom of the screen unit. The side with the longer screw projecting out (side with transportation screw) is the top and the side with the 8 mm hole is the bottom.
INSTALLATION AND ASSEMBLY 4. ASSEMBLING THE SYSTEM (1) Assembling the system [1] Before moving the system to where it is to be installed, insert three Mickey bolts into the main unit. [2] Secure the shield and the shield S to unit L with the scrivet (six parts). [3] Move units R and L to the place where the system is to be installed. Move the units closely together, adjust so that the levels of their frames are equal using the floor leveler, and adjust the guide pins in front and back to the holes.
INSTALLATION AND ASSEMBLY (2) Inserting the Option Board (MVP) [1] [2] [3] [4] [5] [6] [7] Remove the rear cover C (R) and rear cover C (L). (Six screws for each) Remove the UL cover A. (Six screws) Remove the UL cover C. (Two screws) Disconnect the MVP power cord. Disconnect the connector and remove the power supply. (Three screws) Remove the four screws in front of the MVP. Tilt the MVP slightly, and pull it out.
INSTALLATION AND ASSEMBLY [8] Remove the bonnet. (Fig. 3-8) 10 screws [9] Remove the rear cover. (Fig. 3-9) 9 screws Loosen the six screws (ABA-283). [10] Push in the optional board completely inside the second rail from the right. (Fig. 3-10) [11] Attach the rear cover. (Fig. 3-11) 11 screws Tighten the six screws (ABA-283) [12] Attach the bonnet. (Fig. 3-12) 10 screws (Fig.3-10) (Fig.3-8) (Fig.3-11) (Fig.
INSTALLATION AND ASSEMBLY (3) Linking cable (Cord with 6P mini DIN) Connection Accessories ¶Coaxial cable Black 130 260 Orange A B C D E F ¶Linked cable 6P mini DIN cord Connect as shown in Fig. 3-13 using the cable provided. After connecting, secure with a cable clamp. (Fig. 3-14). (Note) When connecting the RS-232C communication connector and remote control unit from the leftmost (as seen from the back), connect IN and OUT linking cables (cords with 6P mini DIN) the other way around. (Fig.
Examples of System LDP 1 (1) Enlarged display only LDP LDP 2 C.VIDEO To MVP input LDP 3 LDP 4 RM-V1000NU/ RM-V1000NA SW or selector, etc. INSTALLATION AND ASSEMBLY C.VIDEO To MVP input RM-V1000NU/ RM-V1000NA (2) Multi display To C. VIDEO MPJ input LDP 1 5 5 To C. VIDEO MPJ input To C. VIDEO MPJ input LDP 4 5 To C. VIDEO MVP input 5 LDP 3 Matrix SW LDP 2 To C.
ADJUSTMENTS (5) Equipment Required for Adjustments The following are required for the adjustments performed during the set-up of MPJ.
ADJUSTMENTS (2) TV System The TV system determines the control of the whole unit (convergence, OSD display select, video system select, deflection) according to the signal input. Set it according to the signal input. When TV SYSTEM is set to AUTO ¶ The mode is automatically set to NTSC or PAL according to the input signal (NTSC/PAL). When the TV SYSTEM is set to NTSC ¶ The mode is set to NTSC regardless of the input signal.
ADJUSTMENTS (6) Giving IDs IDs are used to differentiate the MPJs. When the units are given IDs, by connecting the ABL link cable, commands can be transmitted by specifying the ID, and it is possible to operate only MPJ corresponding to that ID by remote control operations. (Note) The following IDs are provided at shipment.
ADJUSTMENTS Using the Remote Control> [1] Press the key to set the whole screen into the adjustment mode. [2] The main menu will be displayed. Press the 1 key. ADJ IN Select “1. ID SET/CLEAR/SELECT” [3] Check that the ID display at the top left of the screen is “– –” and press the 1 key. Select “1.ID SET”. If an ID has already been given, press the 0 key, select “0. ID CLEAR” of the main menu, return to “[1] Enter the adjustment mode.” and give the ID. 0 to 9 , A to F keys, and input the ID.
ADJUSTMENTS 3. SCREEN ADJUSTMENTS (1) Adjustment Flowchart The following shows the order for performing the adjustments generally required in the setup of this system. For details, see the descriptions on the next page and later. 1 Give ID ↓ 2 Adjust the size of each screen ↓ 3 Adjust the convergence of each screen ↓ 4 Adjust the joining of the screens (Adjust the MVP. Refer to “Appendix (MVP Manual)” in Chapter 7 (page 103).
ADJUSTMENTS (2) Convergence Adjustment Flowchart 1 (P. 44) 2 (P. 44) Find the center of the screen Input the adjustment signal 3 Using only green, adjust the (P. 44) center of V STATIC GH STATIC 4 Adjust the size of V SIZE V␣ LIN (P. 45) H␣ SIZE GH LIN Is the Horizontal size standard (93%)? NO 8 YES (P. 59) Adjust H BLK-L and H␣ BLK-R 5 Adjust joining of peripheral screens (P. 46) in green point convergence mode 6 Adjust linearity of green point conver(P.
ADJUSTMENTS (3) Convergence Adjustment Contents 1 Measurement of screen center The & numbers correspond to the numbers in the flow-chart. The center can be found easily by pasting threads in the spaces of the protection panels at the screen frame. 2 Adjustment signal input For adjusting size ..................................................... Frame size picture(EX.LD Test disc GGT1072, FRAME No. 5941),Monoscope, etc. For screen joining, linearity, color adjustment. .....
ADJUSTMENTS 4 V SIZE, V LIN, H SIZE Adjustment Observe here 1 V SIZE adjustment Set to only green, observe the top part of the screen , and adjust the data amount in the vertical direction using V SIZE . Do not observe the bottom part of the screen. 2 H SIZE adjustment Set to only green, observe the right side of the screen , and adjust the data amount in the horizontal direction using H SIZE . Do not observe the left side of the screen.
ADJUSTMENTS Movement of screen by point convergence adjustment OSD display Movement of screen Observe here Use especially when adjusting the horizontal size of the left side of the screen␣ . In addition, there are nine other area adjustments. It is a convenience to adjust deviation of circumference screens.
ADJUSTMENTS 48
ADJUSTMENTS 49
ADJUSTMENTS In adjustment step 5 , observe the external part of the screen, adjust the 16 adjusting points there, taking note of linearity in the peripheral area such as joining with other screens, crosshatch, etc. (Ignore the distortion inside the screen.) In adjustment step 6 , adjust the inside of the screen and produce linearity. The following are examples of adjusting points in point convergence adjustments and their movements on the screen.
ADJUSTMENTS Displayed OSD Movement on screen 51
ADJUSTMENTS 52
ADJUSTMENTS 53
ADJUSTMENTS 54
ADJUSTMENTS 55
ADJUSTMENTS Note If only one point is moved greatly in the point convergence mode, it may not move in areas smaller than the desired adjusting area. In this case, adjust while moving the other points slowly.
ADJUSTMENTS 8 H BLK L and H BLK R Adjustments H BLK L and H BLK R adjustments are performed to obtain the optimum convergence adjustment wave form when the display range changes due to changes in the H SIZE. Video signal Display range Convergence adjustment wave form Color deviation Video signal Display range after size changed No color deviation Convergence adjustment wave form Convergence adjustment wave form Adjustment by H BLK L When size is increased with H BLK L and H BLK R not adjusted.
ADJESTMENTS H BLK R Adjustment RGB Output all three colors R, G, B, observe the ␣ right␣ side␣ of␣ the␣ screen , and adjust with H␣ BLK␣ R so that the color stops deviating. Observe here RGB BGR When H BLK R adjustment is not properly performed H BLK L adjustment RGB Output all three colors R, G, B, observe the left␣ side␣ of␣ the␣ screen , and adjust with H BLK L so that the color stops deviating.
ADJUSTMENTS Confirming the Optimum H BLK L, H BLK R Values Optimum H BLK R value OSD display Movement on screen B A When point A is lowered by point convergence, point B should not move. Confirming the Optimum H BLK L Value C D When point C is lowered by point convergence, point D should not move. (Note) Convergence can be adjusted even if the optimum values are slightly different from the above optimum values during adjustments.
ADJUSTMENTS 5 Rough Adjustments (1) Black level adjustment Signal:White 10% Adjust R LOW, G LOW, and B LOW to the point where the CRT starts lighting up. (2) HI LIGHT adjustment Signal:White 50% Adjust R HI, G HI, and B HI so that the CRT becomes white. First, adjust so that the brightness of R, G, and B becomes the same, and while maintaining that brightness, balance R, G, and B, and adjust so that the CRT becomes white.
ADJESTMENTS 6 LINEAR WHITE adjustment When white peak signals such as WINDOW are input, due to the characteristics of the Blue CRT, there is a tendency for the peak to become yellow compared to other colors. The linear white adjustment is performed to correct this tendency. Blue becomes weak when data is set to UP and strong when set to DOWN. If Linear White is added excessively, the ABL voltage becomes unbalanced and the medium luminance of blue may be erased, etc.
ADJUSTMENTS 9 Adjustment Using Moving Images The adjustment using images adjusts the overall joining of the screens by loading discs used by users (for actual performance) and discs always used for adjustments. View the overall screen and adjust the screen with the greatest difference to the other screens. The specific method is;at first, focus on the brightness, make the brightness the same, and correct the differences in R, G, and B.
ADJESTMENTS [4] (GET W/B DATA)-White balance adjustment data is output. Format : Output in the following order.
ADJUSTMENTS [6] (GET STATUS)-Various setting states are output. 1STX (02H) 2Version of microcomputer software (5 BYTE) Example)V1.00:Indicates VERSION 1.00. 3Input function state (3 BYTE)-Output in command name. Example)IN1:Indicates VIDEO input. 4MULTI state (3 BYTE)-Output in command name. Example)MLY:Indicates MULTI=ON. 5COLOR MODE state (3 BYTE)-Output in command name. Example)CM1:Indicates COLOR MODE=1. 6COMBINATION state (3 BYTE)-Output in command name. Example)CMY:Indicates COMBINATION=ON.
ADJUSTMENTS 3 Adjustment Examples [1] Setting the ID 1) Enter the adjustment mode by ADJ IN key. 2) The main menu will be displayed. Press the 1 key to select [1. ID SET/CLEAR/SELECT]. 1 key to select [1. ID SET]. 3) Check that the ID display at the top left of the screen is [– –]. Press the When an ID has already been provided, delete the ID as follows and perform from step 1). a) Press the key to set the adjustment mode. The main menu will be displayed. ADJ IN b) Press the 1 key and select [1.
ADJUSTMENTS [3] Adjusting the H SIZE 1) Enter the adjustment mode. 2) Press the 3 3) Press the 5 key to select [3. DEFLECTION ADJ]. key to select [H SIZE]. Then use the 2 / – and +/3 keys to adjust the H SIZE. The following can be adjusted using similar methods. 0 key : V STATIC 7 key : H BLK-L 2 key : V SIZE 8 key : H BLK-R 3 key : V MID SIZE 9 key : V MID LINEARITY 5 key : H SIZE B key : H PIN 6 key : V LINEARITY D key : GH LINEARITY (is the same as GH LINEARITY in “4.
ADJUSTMENTS [5] Adjusting the red point convergence 1) Enter the adjustment mode. 5 2) Press the key to select [5. POINT CONVER ADJ]. ADJ 3) Press the R ON/OFF key so that only the blue of the screen is erased. The following can be selected in the same way. G ADJ ON/OFF ADJ B ON/OFF : Green adjustment : Blue adjustment. 8 keys to move the OSD display to the point to be adjusted on 4) Use the and 2 , 4 , 6 2 /– the screen, and use the , , and +/3 keys to adjust the convergence of that point.
ADJUSTMENTS [8] To return the convergence and white balance adjustment data to that at shipment: 1) Set the adjustment mode. key. 2) Press the 7 Select [7. MEMORY READ/COPY]. 3) Select the number from the SUB MENU. 1 key : The convergence and deflection adjustment data will return to that at shipment. key : The white balance adjustment data will return to that at shipment. 2 [9] To copy the convergence adjustment data between memories: 1) Set the adjustment mode. key. 2) Press the 7 Select [7.
ADJUSTMENTS 4 Precautions Upon Use (Adjustment Control Unit) • Always release the adjustment mode with ADJ OUT button and turn off the power with the POWER button after adjustments and settings. All adjusted values and settings will be memorized. • The remote control adjustment mode will automatically be exited in the following. 1. When no operations are performed for about 180 seconds. 2. When the rear panel switch is pressed 3. When the power is turned off 4.
OPERATIONS • MAINTENANCE 7 Replacement of MPJ Replacing the Top MPJ [1] Remove rear cover A (four screws) and rear cover B (eight screws). (Fig. 5-1) [2] Remove the mirror stay A (four screws) and remove the mirror. (Fig. 5-2) Handle the mirror with extreme care. [3] Remove the engine support stay B (four screws) (Fig. 5-3) and remove the MPJ stopper (four screws) (Fig. 54) [4] Remove the styling of the wire connecting the mini signal section and lower the MPJ by more than 2 persons. 94 (Fig.5-1) (Fig.
OPERATIONS • MAINTENANCE Replacing the Bottom MPU [1] Remove the rear cover B (eight screws) and rear cover C (six screws). (Fig. 5-5) [2] Remove the mirror stay A (four screws) and engine support stay B (six screws) (Fig. 5-6) and remove the MPJ stopper (four screws) (Fig. 5-7). [3] Remove the styling of the wire connecting the mini signal section and lower the MPJ by more than 2 persons. Removing the Mini Signal Section [1] Remove the bonnet (three screws). (Fig.
OPERATIONS • MAINTENANCE 7 Replacement of MVP [1] [2] [3] [4] [5] [6] [7] Remove rear covers C (R) and (L). (6 screws) Remove the UL cover A. (6 screws) Remove the UL cover C. (2 screws) Disconnect the MVP power cord. Disconnect the connectors and remove the power supply. (3 screws) Remove the four screws in front of the MVP. Tilt the MVP slightly, and pull it out.
OPERATIONS • MAINTENANCE 7 Replacing the Screen [1] Remove the panels at the top and right side of the screen unit to be replaced. (Remove 12 screws. ) The panels are made of polycarbonate. Adhesive double coated tapes are pasted to the frames. To remove the panel, pull it out carefully in the horizontal direction as much as possible and it will not deform. [2] Peel off the black vinyl tape at the edges. The top and right sides of the screen will become free.
OPERATIONS • MAINTENANCE 3. PRECAUTIONS FOR ASSEMBLING AND MAINTENANCE ¶ Periodically clean the vent nets of the fan of MPJ to prevent it from clogging. ¶ In assemblies and maintenance, the service person must move in the cabinet. The following are precautions for this procedure. [1] Do not place load on the screen. (In the procedure, always place weight on the cabinet.) [2] Be careful not to hit your head when moving the unit. [3] Do not touch the lens.
PRECAUTIONS 2. NOT MALFUNCTION ¶ In some cases, the screen from appear bluish when seen from the left and slightly reddish when seen from the right. This phenomenon called color shift is inevitable due to the structure of the projection system in which the R G, B tubes are lined up and light is projected from the rear. ¶ When bright images are displayed in the dark, the light reflected on the lens will shine in the darkness slightly.
CHAPTER 7. APPENDIX (MVP manual) APPENDIX (MVP manual) CONTENTS INTRODUCTION ........................................................................................................104 CONNECTION WITH MVP EXTERNAL COMPUTER ............................................... 105 TERMINATING THE PERSONALCOMPUTER ..........................................................106 OPERATION MODE ...................................................................................................
APPENDIX (MVP manual) RMD-V3020 COMMAND REFERENCE ..................................................................... 122 Outline of RMD-V3020 ........................................................................................................................... 122 VS Board Command Rules .................................................................................................................... 123 Tracking Adjustment [TRK command] ............................................................
APPENDIX (MVP manual) CONNECTION WITH MVP EXTERNAL COMPUTER • Refer to Chapter 4.(P.69) “External Control by MPJ RS-232C” for how to adjust the MPJ. ¶ Use a RS-232C straight cable. ¶ Refer to the following diagram for connections. ¶ MVP RS-232C Settings Baud rate Bit number Parity Stop bit : 2400, 4800 , 9600, 19200 : 7, 8 : NON , ODD, EVEN :1 ,2 : Setting at shipment This setting can be changed using the DIP switches on the panel. Refer to “Chapter 2.(P.14) MVP panel 8 Baud rate switch”.
APPENDIX (MVP manual) OPERATION MODE 1. Normal mode : This mode is set when the power and reset switches are pressed. This makes the panel switch effective and sets the performance mode according to the switch settings. 2. Operation mode : Mode which enables MVP from the external computer. This mode is set when the ! command is transmitted after connecting the computer. The normal mode can be set according to the command used.
APPENDIX (MVP manual) 5. Adjustment Mode ¶ NTSC Input Board Adjustment Mode: Mode in which the adjustment commands of the NTSC input board can be executed. (Adjustment items of the output board can be executed when desired) To end the adjustment mode, input AJN. Operation mode AJYB Enables the NTSC input board to be adjusted.
APPENDIX (MVP manual) VIDEO OUTPUT MODE OF MVP ¶ The video output formats set by the mode switches are as shown in the following table. (At shipment, the mode switch value is set to “8”.) Mode switch No. Bus format 0 1 2 3 4 5 6 7 8 9 A B C D E F Output format VBS, Y/C NTSC RGB Sync signal frequency Standard speed Trunk piece mitigation mode OFF Double speed Reserved VBS, Y/C NTSC RGB Standard speed ON Double speed Reserved ¶ Bus format ¶ Output format : NTSC ..............
APPENDIX (MVP manual) ADJUSTMENT FUNCTIONS MVP enables the input and output boards to be adjusted and set by connecting the external computer. The following are items which can be set. (1) MVP settings • For adjusting the picture frame (output image position) (Coarse adjustments:Refer to &P, &Q command, fine adjustment:&G command), and correcting the joinings of the magnified screen.
APPENDIX (MVP manual) PICTURE FRAME ADJUSTMENT PROCEDURE Adjust the MVP picture frame as follows. (1) Connect the RS-232C cable to the MVP panel. (Refer to (P.105) “Connection with MVP EXTERNAL COMPUTER”.) (2) Initialize the picture frame data in RAM. ex. &L0 (Refer to &L command.) (3) Set to the magnified screen to be adjusted. ex. M11B22 ) (@9 (Refer to the M command, @ command.) (4) Perform coarse adjustment of the picture frame. ex. &P21 ++–– (Refer to the &P command.
APPENDIX (MVP manual) To Set the System Back to 4-screen Magnification [@ command] Input: @h (h=8 or 9) Explanation: • For setting the system back to 4-screen magnification after convergence adjustment, etc. • Used also when the normal 4-screen magnification output cannot be obtained due to incorrect operations, etc. @8 ................... (Sets 4-screen magnification of the optional RGB input) @9 ...................
APPENDIX (MVP manual) To Perform Coarse Adjustments of the Picture Frame [&P2, &Q2 commands] Input: &P2d2h1h2h3, &Q2d2h1h2h3 Explanation: &P2 command: Horizontal direction &Q2 command: Vertical direction d2 : Screen position (1 to 2) h1h2h3 : crew start position data (&P2:000 to 1C5, &Q2:000 to 20A) Although the data is an absolute value, the relative value with the current data can also be specified.
APPENDIX (MVP manual) To Store the Picture Frame Data [&W command] Input : &W0, &W1 Explanation : &W0 : Sets the saved values to the settings at shipment. (Load data using the &L command.) &W1 : Saves the value adjusted. • The parameters saved by the &W command are as follows. • Picture frame data (Data changed by the &G command.) • Screen start position data (Data changed by the &P2 command and &Q2 command.
APPENDIX (MVP manual) To Switch the Image Input [IFF command] Input: IFFa Explanation: Switches to display by NTSC input 4-screen magnification or 4-screen magnification by the optional RGB input. a : Video input (A or B) A : Optional RGB input board B : NTSC input board Example) RGB Parsonal computer MVP LD VIDEO IFFA IFFB 1 2 3 45 6 7 8 9 A B C DE F G H I RGB Personal computer LD • Refer to the @ command (page 112) if the normal 4-screen magnification cannnot be set due to incorrect operations.
APPENDIX (MVP manual) To Indicate the Current MVP State [SYS command] Input: SYS Explanation: The current MVP state is shown when SYS is input. (Example) RMD-V3000 Series PROGRAM Ver. 1.00A ID 0 This is displayed continuously. MODE 8 DEMO 8 GEN LOCK INTERNAL MANUAL MODE L2 INPUT : V.SCAN BOARD Y/C L3 INPUT : NTSC BOARD STANDARD MODE VBS L4 INPUT : NO BOARD Y/C L5 INPUT : NO BOARD Y/C L6 OUTPUT : 4 OUT BOARD This is displayed countinuously.
APPENDIX (MVP manual) *6 : Display of remote and manual states REMOTE MODE : Remote state MANUAL MODE : Manual state *7 : Slot number *8 : Type of input board NTSC BOARD : NTSC input board V.SCAN BOARD : Optional RGB input board NO BOARD : No input board is incorporated *9 : NTSC input board state STANDARD MODE : When standard NTSC signal is input NO STANDARD MODE : When non-standard NTSC signal is input *10: Display of VBS/ Y/C select switch state VBS : Composite video signal input (Indicates V FIL.
APPENDIX (MVP manual) Bright Compensation [BRT command] Input: Explanation: BRTd Corrects the brightness of the NTSC input board. d : Compensation value 0 to F * BRTd : Displays the current value and moves to the sub command mode • To execute this command, it is necessary to set the adjustment mode by AJYB. (Refer to the AJYB command.) • The changed value will be memorized the last. (Example) BRT3 Sets the bright level to 3. * Sub command mode of BRT command The sub command mode is set by BRT .
APPENDIX (MVP manual) Tint Adjustment [TNT command] Input : TNTd1d2d3 Explanation: Corrects the tint of the NTSC input board. d 1 d2 d3 : Compensation value 0 to 255 TNT? : Help display TNT : Displays the current value and moves to the sub command mode • To execute this command, it is necessary to set the adjustment mode by AJYB. (Refer to the AJYB command.) • If data input is skipped, the sub command input mode is set after the data is displayed. The sub command mode is the same as with the COL command.
APPENDIX (MVP manual) To Set Internal Sync [INT command] Input : INT Explanation : • Forcibly sets internal sync. • This command is executed in the remote mode. It is ignored in the manual mode. (Refer to the RMT command.) To Set External Sync [EXT command] Input : EXT Explanation : • Forcibly sets external sync. However, if the GEN LOCK able signal is not input to the GEN LOCK IN (reference input) terminal, external sync will not be set. • This command is executed in the remote mode.
APPENDIX (MVP manual) To Set the Output to the NTSC Mode [NT command] To Set the Output to Standard RGB Mode [NTR command] To Set the Output to the Double-speed RGB Mode [NTD command] Input : NT , NTR , NTD Explanation : • NT : Sets the NTSC input mode. H : 15.734 kHz V : 59.94 Hz Composite video, Y/C output • NTR : Sets the standard speed RGB mode. H : 15.734 kHz V : 59.94 Hz • NTD : Sets the double-speed RGB mode. H : 31.469 kHz V : 59.94 Hz • This command is executed in the remote mode.
APPENDIX (MVP manual) RMD-V3020 COMMAND REFERENCE Outline of RMD-V3020 • Introduction The RMD-V3020 is an input board (hereafter referred to as VS board) which supports variable scanning for inputting images of computer (hereafter referred to as PC) to the MVP. Horizontal frequency : 24 kHz to 35 kHz Vertical frequency : 55 Hz to 72 Hz Dot clock : Up to 35 MHz Signal : Non-interlace signal (The HDTV, 15 kHz RGB signal will not be displayed because it is interlaced.
APPENDIX (Manual) VS Board Command Rules 0. Symbols aaa ddd xxx hh : Command consisting of 3 alphabet letters : Basic commands : Decimals between 0 to 255 consisting of 1 to 3 digits. Can start with 0. Exceptional commands : Depends on each command. : Special data. UP0 to UP9, UPF, DW0 to DW9, DWF, RES. : 2-character hexadecimals between 00 and FF. 1. Basic Commands • Executed commands aaa : Executes and ends. ARS, DSN, DSX, DSY, FZN, FZY • Displayed commands aaa : Displays and ends.
APPENDIX (MVP manual) 2. Exceptional Commands • Model data commands TBL : Displays the current model data table. TBLhh : Displays the hh model data table. M : Displays the current model number. Mhh : Sets the hh model number. Fhh : Sets the hh model number data to the initial value. When the hh model data does not exist, “**NO DATA**” is displayed. When hh contains characters other than 0 to 9, a to f, and A to F, “DATA ERROR” is set.
APPENDIX (Manual) Tracking Adjustment [TRK command] Input : TRKd1d2d3 Explanation: • d1d2d3 : Compensation data 0 to 254 • Eliminates lateral vibration of displayed characters, shaking, and noises. TRK adjustment • A vertical line pattern in which the black and white lines change every dot as shown below is the ideal for adjustments. Contrast Adjustment [CNT command] Input : CNTd1d2d3 Explanation: • d1d2d3 : Compensation data 0 to 254 • Use this command to adjust the contrast.
APPENDIX (MVP manual) B, R Clamp Adjustment [BLV, RLV commands] Input : BLVd1d2d3, RLVd1d2d3 Explanation : • d1d2d3 : Compensation data 0 to 254 • BLV : Adjusts the B clamp level. RLV : Adjusts the R clamp level. • Use this command to adjust so that the white balance of the low light side of the images produced by the MVP matches that of the actual images of the computer. • Tracking may deviate in some cases when clamp level adjustment is performed after TRK adjustment.
APPENDIX (Manual) Horizontal, Vertical Blanking Window Position Adjustment [HWN, VWN commands] Input : HWNd1d2d3, VWNd1d2d3 Explanation : • d1d2d3 :Compensation data 0 to 254 • HWN :Adjusts the H blanking window position. VWN :Adjusts the V blanking window position. However, the picture inside the blanking window also moves.
APPENDIX (MVP manual) Full Dot Number Compensation [HFD command] Input : Explanation : • • • • HFDddd d1d2d3:Compensation data 0 to 254 Corrects the preset sampling clock. Vertical bit lines can be erased by executing the HFD command. The HFD and HPS data are correlated and have limited values. Bit lines Figure: Bit Lines which can be Erased by HFD Execution Freeze Frame Y:ON N:OFF [FZY, FZN commands] Input : Explanation : • • • FZY, FZN Continuously outputs the image the moment the FZY is executed.
APPENDIX (Manual) Vertical Compression Filter Conversion Rate Input [LCV command] Input : LCVd1d2d3d4 Explanation : • d1d2=00 to 15 (Add 0 before all numbers below 9) Vertical direction rate before conversion • d3d4=00 to 15 (Add 0 before all numbers below 9) Vertical direction rate after conversion Due to the use of a compression filter, the condition=is d1d2 > d3d4. Both LCV0000 and LCV0101 are not convertible.
APPENDIX (MVP manual) To Select Preset Model [M command] Input : Mh1h2 Explanation : • Refer to “VS Board Model Selection” described later for the VS board model selection. • Forcible locks the model data preset. Model data No. h1 h 2 0 0 Discriminates the model.
APPENDIX (Manual) Model Fresh [F command] Input : Fh1h2 Explanation : • Sets back to the model data preset at shipment. Model data No. h1 h2 0 0 Auto 0 1 VGA (640 x 480) 0 2 IBM-PC (EGA emulation) 0 3 Macintosh 13-inch monitor mode (Standard) 0 4 Macintosh 13-inch monitor mode (RasterOps type) 0 5 Macintosh 13-inch monitor mode (Power Mac) 0 6 FM-R50 0 7 IBM Think Pad 230C 0 8 X68000 0 9 NEC PC9801 (640 x 400 mode) 1 0 Unused area (Do not specify using the M command.
APPENDIX (Manual) The relative address and data are as follows. However, relative addresses 20 to 3F are the system reservation range. Relative ADDR 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F Data Contents Model data No. Horizontal frequency NNN.
APPENDIX (MVP manual) Vertical Frequency Input [VFQ command] Input : VFQd1d2d3.d4d5d6 Explanation : • Directly changes the horizontal frequency of the model data table used for the VS board currently. • Input the frequency using 6-digit decimal numbers. When data input is omitted, the vertical frequency on the current model data table is displayed. Although numbers outside the vertical specification range (55.0 kHz to 72.0 kHz) range of this board can be input, they cannot be used as preset data.
APPENDIX (Manual) MODE 99 The VS board contains preset data for autolocking 9 computer main models at shipment. However, looking at the recent PC market is taken into consideration, it is not possible to incorporate preset data in all models due to the diversification of manufacturers, models, and graphic mode, etc.
APPENDIX (MVP manual) VS BOARD MODEL SELECTION PC signal input Preset PC? (01 to 09) YES NO Locked in Mode 99? NO YES Output in Mode 99 The model may be outside the application range. Auto locked Check frequency, line number using FRQ command Frame, color adjustment Lock preset model data using M command. When using the Mode 99 data as it is. Description With the VS board, first the input PC frequency and full line number are measured.
APPENDIX (Manual) SELECTING THE SYNC SIGNAL When adjusting the VS board, care must be taken regarding the relation of the priority order of the sync signal. Order of selecting the sync signal The priority order for selecting the sync signal of the VS board is Separate sync > composite sync > Green on sync.
APPENDIX (MVP manual) CHECK SHEET 1. Preparations 1 2 3 4 Connect the power supply, and connect the cable for input signals and ABL link cable (control cable). Place the connected cables neatly. After completing the above 1 and 2, turn on the power and perform aging for one hour. Prepare the signals required for adjustments. 2. Before Starting Adjustments (Set Conditions) .............................P.
