Operating Instruction DVD Recorder DMR-E95H

ManualsBrandsPanasonic ManualsDVD RecorderDMR-E95H

Table Of Contents

Summary of content (64 pages)

PAGE 1
PAGE 2
Getting started Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions listed below. Keep these operating instructions handy for future reference. 1) 2) 3) 4) 5) 6) 7) 8) 9) RQT7392 2 Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings.
PAGE 3
7392en.book 3 ページ２００４年４月２７日火曜日午後５時３０分 Table of contents Transfer (Dubbing) IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . .2 Useful features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 The remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Control reference guide . . . . . . . . . . . . . . . . . . . . . . . . . . .5 STEP 1 Connection . . . . . . . . .
PAGE 4
7392en.book 4 ページ２００４年４月２７日火曜日午後５時３０分 Accessories Getting started Please check and identify the supplied accessories. Use numbers indicated in parentheses when asking for replacement parts. To order accessories, refer to “Accessory Purchases” on page 61. ∏ ∏ ∏ 1 Remote control (EUR7721KL0) 1 AC power supply cord (K2CB2CB00006) 1 75 ≠ coaxial cable (VJA1125) ≥For use with this unit only. Do not use it with other equipment.
PAGE 5
7392en.book 5 ページ２００４年４月２７日火曜日午後５時３０分 Control reference guide Remote control TV POWER INPUT SELECT TV/VIDEO VOLUME CH Getting started DVD POWER Turn the unit on (➡ page 10) Television operations (➡ page 12) Input select (L1, L2, L3 or DV) (➡ page 41) HDD DVD SD/PC PAGE Select channels and title numbers, etc.
PAGE 6
7392en.book 6 ページ２００４年４月２７日火曜日午後５時３０分 STEP 1 Connection ∫ Examples of equipment you can connect to this unit’s terminals Amplifier Getting started Television From OUT1 or OUT2 terminals From AUDIO OUT terminals or DIGITAL AUDIO OUT terminal This unit To L2 or DV input terminals (front) (➡ page 41) To IN3 (L3) input terminals (rear) To IN1 (L1) input terminals (rear) Video cassette recorder Camcorder Cable TV box Do not place the unit on amplifiers or equipment that may become hot.
PAGE 7
≥The equipment connections described are examples. ≥Before connection, turn off all equipment and read the appropriate operating instructions. ≥Peripheral equipment and optional cables sold separately unless otherwise indicated. Connecting a television and VCR Getting started A to X are indexes for Spanish Quick Reference.
PAGE 8
7392en.book 8 ページ２００４年４月２７日火曜日午後５時３０分 STEP 1 Connection Connecting a cable TV box Getting started ≥You need to subscribe to a cable TV service to enjoy viewing their programming. ≥Consult your service provider regarding appropriate cable TV box. ≥If you receive your programming solely from a satellite service, the program guide in this unit will not receive program listings or channel information. Without this information, program-based recordings cannot be made.
PAGE 9
Connecting an amplifier or system component ∫ To enjoy multi-channel surround sound on DVD-Video Amplifier’s rear panel Connect an amplifier with a built-in decoder displaying these logo marks using an optical digital audio cable and change the settings in “Digital Audio Output” (➡ page 49). AUDIO IN R L ≥You cannot use DTS Digital Surround decoders not suited to DVD. ≥Even if using this connection, output will be only 2 channels when playing DVD-Audio.
PAGE 10
STEP 2 Setting up the TV Guide On ScreenTM system Getting started Preparation ≥Turn on the television and select the appropriate video input to suit the connections to this unit. ≥When using the cable TV box, check the following. –Make sure the IR Blaster is connected and positioned properly (➡ page 8). –Make sure the cable TV box is turned on. 1 Press [Í DVD POWER]. 2 Following the on-screen messages, input the operating environment for your television.
PAGE 11
２００４年４月２７日火曜日午後５時３０分 If you are using a cable TV box, set the following: ≥Cable TV box connection channel (Ch2/Ch3/Ch4/L3) –If you are connecting the cable TV box to this unit’s IN3 (L3) terminal, select “L3”. –If you are connecting the cable TV box to this unit’s RF terminal, select “Ch2”, “Ch3” or “Ch4”, according to the cable TV box setting. ≥Cable TV box brand (Move down with [4] for more brands. Select “Not Listed” if you cannot find your cable TV box on the list.
PAGE 12
7392en.book 12 ページ２００４年４月２７日火曜日午後５時３０分 STEP 3 Set up to match your television and remote control Getting started DVD POWER Television operation TV POWER VOLUME CH INPUT SELECT TV/VIDEO DVD HDD TV operation buttons SD/PC While pressing [Í POWER TV], enter the code with the numbered buttons. PAGE 2 1 Numbered buttons 3 CH 4 5 7 8 6 e.g., 01: [0] ➡ [1] Manufacturer and Code No. AUDIO 9 VCR Plus+ CM SKIP CANCEL 0 SKIP STOP SLOW/SEARCH PAUSE PLAY/x1.
PAGE 13
7392en.book 13 ページ２００４年４月２７日火曜日午後５時３０分 Change the remote control code on the main unit and the remote control (the two must match) if you place other Panasonic products close together. Use “1”, the factory set code, under normal circumstances. 1 2 3 4 Press [SETUP]. Press [3, 4] to select “Set Up” and press [1]. Press [3, 4] to select “Remote Control Code” and press [ENTER]. Press [3, 4] to select the code (1, 2, or 3) and press [ENTER].
PAGE 14
HDD, disc and card information HDD and discs you can use for recording and play Getting started Type Logo Instructions Temporary storage Hard disk drive (HDD) ≥160 GB Indicated in these instructions with [HDD] – ≥You can record up to 284 hours [in EP (8H) mode] (➡ page 17, Recording modes and approximate recording times). ≥You can view the title being recorded from the beginning (Chasing playback, Time Slip) (➡ page 18). ≥You can record digital broadcasts that allow “One time only recording”.
PAGE 15
7392en.book 15 ページ２００４年４月２７日火曜日午後５時３０分 Cards useable on this unit Instructions SD Memory Card MultiMediaCard You can insert directly into the SD card slot. [SD] SD Memory Card MultiMediaCard CompactFlash SmartMedia MEMORYSTICK xD-Picture Card Microdrive ≥You can play and transfer (dub) still pictures taken on a digital camera etc. (➡ page 28, 42). ≥You can set the DPOF (Digital Print Order Format) for automatic printing on your home printer or at a photo developing store (➡ page 36, 53).
PAGE 16
7392en.book 16 ページ２００４年４月２７日火曜日午後５時３０分 Recording television programs 2 HDD, DVD indicator 1∫ 1 5 1 OPEN/CLOSE SD CARD PC CARD REC EJECT POWER TIME SLIP HDD DVD SD PC TIME SLIP Recording Time Slip indicator TIME SLIP DVD POWER /x1.3 The HDD or DVD indicator lights up on the unit. 2 CH If you selected the DVD drive Press [< OPEN/CLOSE] on the main unit to open the tray and insert a disc. 3 ≥Press the button again to close the tray. Insert label-up.
PAGE 17
２００４年４月２７日火曜日午後５時３０分 ∫ To specify a time to stop recording—One Touch Recording During recording Selecting audio to record [HDD] [RAM] Press [AUDIO]. Press [¥ REC] to select the recording time. Each time you press the button: 0:30 "# 1:00 "# 1:30 "# 2:00 "# 3:00 "# 4:00 ^"""""""""""" Counter (cancel) ,"""""""""""} ≥This does not work during timer recordings (➡ page 19) or while using Flexible Recording (➡ page 18). To stop recording partway Press [∫]. [.
PAGE 18
Recording television programs Refer to the control reference on page 16. [HDD] [RAM] [HDD] [RAM] [DVD-R] Playing while you are recording Recording You can change the drive and play while recording on this unit. Also, while recording to the HDD or to DVD-RAM you can view the title being recorded from the beginning as well as play a recorded title.
PAGE 19
RQT7392 19
PAGE 20
Timer recording ≥To enter the channel Press [3, 4] to select “Channel” and press the numbered buttons. –To select the input channel (L1/L2/L3/DV) Press [DUBBING] (Blue). Recording ≥To change the recording mode Press [3, 4] to select “Quality” and press [DUBBING] (Blue). Each time you press the button: ≥To change the recording drive Press [3, 4] to select “Destination” and press [DUBBING] (Blue). Each time you press the button: HDD ,-.
PAGE 21
Recording Entering PlusCode® RQT7392 21
PAGE 22
7392en.book 22 ページ２００４年４月２７日火曜日午後５時３０分 Timer recording ∫ To change the recording frequency DVD POWER Í DVD POWER Press [CHAPTER] (Green). TV POWER DVD HDD ∫ To change the time, recording mode and recording drive VOLUME CH INPUT SELECT TV/VIDEO Press [ENTER]. (➡ page 19, To change the setting, step 4) SD/PC PAGE Numbered buttons 1 2 3 4 5 6 7 8 9 PAGE X CH W CH ∫ To delete the program Press [DUBBING] (Blue).
PAGE 23
Utilizing TV Guide On ScreenTM system ∫ Customizing the channel line-up Press [TV GUIDE]. LISTINGS 8:00PM SORT 8:30PM Last Channel 87 NWGB 8:00 8:30 FAVORITES RECORD INFO. To hide the channel Press [CHAPTER] (Green) to select “OFF”. R pTV Recording SCHEDULE TODAY 1 Press [3] several times to select “LISTINGS”. 2 Press [2, 1] to select “SETUP” and press [4]. 3 Press [3, 4] to select “Change channel display” and press [ENTER]. 4 Press [3, 4] to select the channel.
PAGE 24
Playing recorded video contents/Playing play-only discs 3 2 HDD, DVD indicator 1∫ 3 OPEN/CLOSE SD CARD PC CARD REC EJECT POWER TIME SLIP HDD DVD SD PC DRIVE SELECT TIME SLIP /x1.3 CH TIME SLIP X CH W DVD POWER INPUT SELECT TV/VIDEO Playing back 45 TV POWER CH DVD HDD VOLUME SD/PC 1 Press [1] (PLAY). [HDD] [RAM] [DVD-R] Play starts from the most recently recorded title. [DVD-A] [DVD-V] [VCD] [CD] Play starts from the beginning of the disc.
PAGE 25
Operations during play Press [∫]. Pause Press [;]. Press again to restart play. Press [6] or [5]. Search Skip ≥On the main unit, press and hold [D] or [E]. ≥The speed increases up to 5 steps. ≥Press [1] (PLAY) to restart play. ≥Audio is heard during first level search forward. You can turn off the sound during search (➡ page 48, “Search Audio & PLAY k1.3”). Audio is heard during all levels of search. [DVD-A] (excluding moving picture parts) [CD] Playing back Stop The stopped position is memorized.
PAGE 26
7392en.book 26 ページ２００４年４月２７日火曜日午後５時３０分 Playing recorded video contents/Playing play-only discs Refer to the control reference on page 24. Editing operations during play Playing back Erase 1 Press [ERASE]. 2 Press [2, 1] to select “Erase” and press [ENTER]. [HDD] [RAM] [DVD-R] ≥A title cannot be restored once it is erased. Make certain before proceeding. ≥You cannot erase while recording or transferring (dubbing). Create chapters Press [CHAPTER].
PAGE 27
Using menus to play MP3 1 Press [1] while a track is highlighted to display the tree screen. 2 Press [3, 4, 2, 1] to select a group and press [ENTER]. Playing back While the file list is displayed The file list for the group appears. To return to the file list Press [RETURN]. [CD] (MP3 discs only) This unit plays MP3 files recorded on CD-R/RW designed for audio recording that are finalized (➡ page 53) on a computer. Files are treated as tracks and folders are treated as groups. 1 Press [TOP MENU].
PAGE 28
Playing still pictures Only insert or remove the SD/PC card after turning the unit off. When the card indicator (“SD” or “PC”) on the unit’s display is flashing, the card is being read from or written to. Do not turn off the unit or remove the card. Such action may result in malfunction or loss of the card’s contents. Playing back ∫ SD card slot ∫ PC card slot Regarding still pictures (JPEG, TIFF) ≥Compatible formats:DCF§ compliant (Content recorded on a digital camera etc.
PAGE 29
[HDD] [RAM] [SD] [PC] 1 Press [HDD], [DVD] or [SD/PC] to select the drive. ≥Each time you press [SD/PC]: SD card drive ,". PC card drive ≥On the main unit, press [DRIVE SELECT] several times. The indicator lights up on the unit. HDD DVD SD PC Press [DIRECT NAVIGATOR]. Playing back 2 e.g., SD card drive 3 4 ∫ To show the picture properties [HDD] [RAM] Press [STATUS] twice. Press [3, 4, 2, 1] to select “PICTURE” tab and press [ENTER].
PAGE 30
7392en.book 30 ページ２００４年４月２７日火曜日午後５時３０分 Using on-screen menus and Status messages Disc menu–Setting the disc content DVD POWER TV POWER Sound track§ DVD HDD VOLUME CH INPUT SELECT TV/VIDEO [HDD] [RAM] [DVD-R] The disc’s audio attributes appear. [DVD-A] [DVD-V] Select the audio and language (➡ below, Audio attribute, Language).
PAGE 31
7392en.book 31 ページ２００４年４月２７日火曜日午後５時３０分 Play menu–Change the play sequence Audio menu–Change the sound effect This function works only when the elapsed play time is displayed. ≥All [VCD] [CD] (excluding MP3 discs) ≥Chapter [HDD] [RAM] [DVD-R] [DVD-V] ≥Group [DVD-A] [CD] (MP3 discs only) ≥PL (Play list) [HDD] [RAM] ≥Title [HDD] [RAM] [DVD-R] [DVD-V] ≥Track [DVD-A] [VCD] [CD] Select “OFF” to cancel. V.S.S.
PAGE 32
7392en.book 32 ページ２００４年４月２７日火曜日午後５時３０分 Editing titles/chapters DVD POWER Editing titles/chapters and playing chapters TV POWER INPUT SELECT TV/VIDEO VOLUME CH DVD HDD SD/PC HDD, DVD 1 2 PAGE 1 2 3 4 5 6 7 8 CH AUDIO 9 VCR Plus+ CM SKIP CANCEL 0 SKIP :9 Preparation ≥Press [HDD] or [DVD] to select the drive. ≥Release protection (➡ page 44). [RAM] STOP SLOW/SEARCH PAUSE 3 ; PLAY/x1.3 Editing DIRECT NAVIGATOR Press [3, 4, 2, 1] to select “VIDEO” tab and press [ENTER].
PAGE 33
Title operations Erase§ [HDD] [RAM] [DVD-R] Press [2, 1] to select “Erase” and press [ENTER]. ≥Once erased, the recorded contents are lost and cannot be restored. Make certain before proceeding. ≥The available recording time on DVD-R does not increase when you erase titles. Information (e.g., time and date) is shown. Properties Properties Dinosaur No. 01 Start 10:00 AM Date 6/20/2002 Wed Rec time 2:15 (SP) CH 4 [HDD] [RAM] [DVD-R] Enter Name [HDD] [RAM] [DVD-R] You can give names to recorded titles.
PAGE 34
Creating, editing and playing play lists 2 Prs [ 3, 4, 2, 1] to select “PLAY LIST” and press [ENTER]. 3 Prs [ 3, 4, 2, 1] to select “Create” and press [ENTER]. Prs [ 2, 1] to select the source title and press [4]. Editing 4 ≥Press [ENTER] to slect all the chapt in ttle, then skip to step 6. [HDD] [RAM] 5 Prs [ 2, 1] to select the chaptr you want to add to a play list and press [ENTER].
PAGE 35
２００４年４月２７日火曜日午後５時３０分 Editing and playing play lists/chapters 1 2 3 Play list operations Press [FUNCTIONS]. Erase§ Press [3, 4, 2, 1] to select “PLAY LIST” and press [ENTER]. Press [3, 4, 2, 1] to select the play list. Play list information (e.g., time and date) is shown. -- 10/27 Mon 0:30 Create -- -- No. Chapters -- SUB MENU Next Select ≥To show other pages/Multiple editing (➡ page 32) 4 Press [SUB MENU], then [3, 4] to select the operation and press [ENTER].
PAGE 36
Editing still pictures 2 DVD POWER TV POWER INPUT SELECT TV/VIDEO DVD HDD VOLUME CH SD/PC PAGE 1 2 3 4 5 6 HDD, DVD, SD/PC 3 AUDIO 7 8 4 9 VCR Plus+ CM SKIP 0 SKIP STOP SLOW/SEARCH PAUSE Press [3, 4, 2, 1] to select “PICTURE” tab and press [ENTER]. Press [3, 4, 2, 1] to select the still picture. ≥To show other pages/Multiple editing (➡ page 32) ≥To select the still pictures in another folder (➡ page 29) CH CANCEL [HDD] [RAM] PLAY/x1.
PAGE 37
7392en.book 37 ページ２００４年４月２７日火曜日午後５時３０分 Transferring (dubbing) titles or play lists [HDD] [RAM] [DVD-R] You can select from a variety of methods to transfer (dub) on this unit. ∫ Transferring (dubbing) direction You can transfer (dub) your favorite titles and play lists to an archive disc. ≥Transferring (dubbing) a play list will create a title. When you want to re-edit finalized content on a DVD-R, etc.
PAGE 38
7392en.book 38 ページ２００４年４月２７日火曜日午後５時３０分 Transferring (dubbing) titles or play lists DVD POWER Transferring (dubbing) using the transferring (dubbing) list TV POWER INPUT SELECT TV/VIDEO DVD HDD [HDD] ,-. [RAM] [HDD] > [DVD-R] You can order titles and play lists for transfer (dubbing) as desired as well as select the speed and picture quality.
PAGE 39
２００４年４月２７日火曜日午後５時３０分 3 Press [3, 4, 2, 1] to select the titles or play lists and press [ENTER]. ≥To select a multiple number of items together, press [;] to add the check mark and press [ENTER] (➡ below, Multiple editing).
PAGE 40
Transferring (dubbing) titles or play lists Refer to the control reference on page 38. Transferring (dubbing) a finalized DVD-R [DVD-V] > [HDD] While playing a disc, the content being played is transferred (dubbed) to the HDD according to the set time. ≥Operations and on screen displays during transfer (dubbing) are also recorded. ≥Almost all DVD-Video on sale have been treated to prevent illegal copying, and cannot be transferred (dubbed).
PAGE 41
Recording from a video cassette recorder DVD POWER 3 4 TV POWER INPUT SELECT TV/VIDEO VOLUME CH DVD SD/PC HDD, DVD To skip unwanted parts Press [;] to pause recording. (Press again to restart recording.) PAGE 1 2 3 4 5 6 7 8 9 Press [¥ REC]. Recording starts. INPUT SELECT HDD Start play on the other equipment. CH To stop recording Press [∫].
PAGE 42
7392en.book 42 ページ２００４年４月２７日火曜日午後５時３０分 Transferring (dubbing) still pictures DVD HDD SD/PC ∫ To register on a folder by folder basis SD/PC 1 Press [3, 4] to select “Picture/Folder” and press [ENTER]. PAGE 1 2 3 4 5 6 CH Dubbing AUDIO 7 8 9 1 Dubbing direction VCR Plus+ CM SKIP CANCEL Create a dubbing list. Cancel all SD card > DVD 0 Picture Picture/Folder Space on destination: 4343MB Name No.
PAGE 43
7392en.book 43 ページ２００４年４月２７日火曜日午後５時３０分 FUNCTIONS window Transferring (dubbing) all the still pictures on a card—COPY ALL PICTURES DVD POWER INPUT SELECT TV/VIDEO [SD] or [PC] > [HDD] or [RAM] PAGE 2 3 4 5 6 7 8 CH AUDIO 0 SKIP SLOW/SEARCH STOP PAUSE PLAY/x1.
PAGE 44
7392en.book 44 ページ２００４年４月２７日火曜日午後５時３０分 HDD, disc and card setting DVD POWER TV POWER INPUT SELECT TV/VIDEO VOLUME CH DISC SETTING DVD-RAM DVD HDD HDD, DVD, SD/PC SD/PC PAGE 2 1 3 5 6 7 8 9 11 0 : 22 Free 5:38 (EP) Disc Name Disc Protection On Earse all titles CH 4 Titles Used Format disc AUDIO VCR Plus+ CM SKIP CANCEL The lock symbol appears closed when the disc is writeprotected. 0 SKIP STOP SLOW/SEARCH PAUSE PLAY/x1.
PAGE 45
２００４年４月２７日火曜日午後５時３０分 Erasing all the contents of a disc or card—Format 3 [HDD] [RAM] [SD] [PC] Preparation ≥Press [HDD], [DVD] or [SD/PC] to select the drive. ≥Release protection (➡ page 44). 1 While stopped Press [FUNCTIONS]. Press [3, 4, 2, 1] to select “DISC SETTING” or “CARD SETTING” and press [ENTER]. Press [3, 4] to select “Format” or “Format disc” and press [ENTER]. Press [2, 1] to select “Yes” and press [ENTER]. Press [2, 1] to select “Start” and press [ENTER].
PAGE 46
7392en.book 46 ページ２００４年４月２７日火曜日午後５時３０分 Entering text 1 DVD POWER INPUT SELECT TV/VIDEO VOLUME Title Select “Enter Name” in step 4 on page 32. SD/PC Play list Select “Enter Name” in step 4 on page 35. CH DVD HDD PAGE Numbered buttons ¢ CANCEL 1 2 3 4 5 6 7 8 Disc Select “Disc Name” in step 3 on page 44. CH AUDIO 9 Folder of still pictures Select “Folder Name” in step 4 on page 36. VCR Plus+ CM SKIP CANCEL 0 SKIP ; Show Enter Name screen.
PAGE 47
7392en.book 47 ページ２００４年４月２７日火曜日午後５時３０分 Changing the unit’s settings DVD POWER Í DVD POWER Common procedures TV POWER 1 VOLUME CH INPUT SELECT TV/VIDEO While stopped Press [SETUP]. DVD HDD SD/PC Tabs PAGE Numbered buttons 1 2 3 4 5 6 7 8 9 Menus Options CH SETUP TV GUIDE Setting AUDIO Antenna System VCR Plus+ CM SKIP CANCEL ¢ CANCEL SKIP STOP SLOW/SEARCH PAUSE 2 PLAY/x1.3 DIRECT NAVIGATOR Press [3, 4] to select the tab and press [1].
PAGE 48
7392en.book 48 ページ２００４年４月２７日火曜日午後５時３０分 Changing the unit’s settings Tabs Disc Continued Menus Options (Underlined items are the factory presets.) Ratings Set a ratings level to limit DVD-Video play. ≥8 No Limit: ≥1 to 7: Follow the on-screen instructions. Enter a 4-digit password with the numbered buttons when the password screen is shown. ≥Do not forget your password.
PAGE 49
7392en.book 49 ページ２００４年４月２７日 Tabs Continued 午後５時３０分 Menus Digital Audio Output Change the settings when you have connected equipment through this unit’s DIGITAL AUDIO OUT terminal (➡ page 9). ≥Press [ENTER] to show the following settings. Signals are converted to 48 kHz or 44.1 kHz. (Choose when the connected equipment cannot process signals with sampling frequency of 96 kHz or 88.2 kHz.) Signals are output as 96 kHz or 88.2 kHz.
PAGE 50
Channel/Clock settings when TV Guide On ScreenTM system is not used Refer to the control reference on page 47. Preparation: If the television program list has already been downloaded, return the unit to the factory preset condition using the steps indicated below. When the unit is on and stopped 1 Press and hold [X CH] and [W CH] on the main unit for about five seconds. The unit turns off. 2 Press [Í DVD POWER] to turn the unit on.
PAGE 51
Channel captions You can use the preset captions, or manually enter new ones yourself. The captions you enter are displayed when the channel is displayed and in the Direct Navigator screen. ≥You can set channel captions only after “Auto Channel Setting” is completed. 1 Press [SETUP].
PAGE 52
7392en.book 52 ページ２００４年４月２７日火曜日午後５時３０分 Specifications Recording system: DVD Video Recording format (DVD-RAM) DVD-Video format (DVD-R) Recordable discs: DVD-RAM : 12 cm (5q) 4.7 GB, 12 cm (5q) 9.4 GB, 8 cm (3q) 2.8 GB 12 cm (5q) 4.7 GB (Ver. 2.1/3k–SPEED DVD-RAM Revision 1.0) DVD-R : 12 cm (5q) 4.7 GB, 8cm (3q) 1.4 GB (for General Ver. 2.0) 12 cm (5z) 4.7 GB (for General Ver. 2.0/4k–SPEED DVD-R Revision 1.0) Recording time: ≥Maximum 8 hours (with 4.7 GB disc) XP: Approx. 1 hour SP: Approx.
PAGE 53
Glossary Bitstream This is the digital form of multi-channel audio data (e.g., 5.1 channel) before it is decoded into its various channels. CPRM (Content Protection for Recordable Media) CPRM is technology used to protect broadcasts that are allowed to be recorded only once. Such broadcasts can be recorded only with CPRM compatible recorders and discs. HDD (Hard disk drive) This is a mass data storage device used in computers, etc.
PAGE 54
7392en.book 54 ページ２００４年４月２７日火曜日午後５時３０分 Frequently asked questions Set up What equipment is necessary to play multi channel surround sound? Page ≥ DVD-Video: You can play DVD-Video multi channel surround by digitally connecting an amplifier equipped with a Dolby Digital and a DTS decoder. ≥DVD-Audio: This unit plays DVD-Audio in 2 channels. You cannot play multi channel surround sound. 9 — Are the headphones and speakers directly connected to the unit? ≥You cannot directly connect to the unit.
PAGE 55
Error messages On the television On the unit’s display ≥The program was copy-protected. ≥The HDD or disc may be full. ≥You inserted an incompatible disc (Discs recorded in PAL video, etc.). ≥The disc may be dirty or scratched. ≥You cannot format a Microdrive or mobile hard disk on this unit. ≥You tried to play a non-compatible image. ≥Turn the unit off and re-insert the card. ≥Create space by erasing any unnecessary titles.
PAGE 56
7392en.book 56 ページ２００４年４月２７日火曜日午後５時３０分 Troubleshooting guide Before requesting service, make the following checks. If you are in doubt about some of the check points, or if the remedies indicated in the chart do not solve the problem, refer to the “Customer Services Directory” on page 61. The following do not indicate a problem with this unit: ≥Regular disc rotating sounds. ≥Poor reception due to atmospheric conditions. ≥Image disturbance during search.
PAGE 57
7392en.book 57 ページ２００４年４月２７日火曜日午後５時３０分 Sound No sound. Low volume. Distorted sound. Cannot hear the desired audio type. Cannot switch audio. Page ≥Check the connections and settings. Check the input mode on the amplifier if you have connected one. ≥Press [AUDIO] to select the audio. ≥Turn off V.S.S. in the following cases. –When using discs that do not have surround sound effects such as Karaoke discs. –When playing MTS broadcast programs.
PAGE 58
7392en.book 58 ページ２００４年４月２７日火曜日午後５時３０分 Troubleshooting guide Recording/Timer recording/Transferring (dubbing) (Continued) Page Cannot transfer (dub) to a DVDR disc using the high speed mode. ≥When recording to the HDD, set “DVD-R High-Speed Recording” to “On” in the SETUP menu. 48 When transferring (dubbing), it takes a long time even when high speed mode is selected. ≥Use a disc that is compatible with high speed recording.
PAGE 59
7392en.book 59 ページ２００４年４月２７日火曜日午後５時３０分 Edit Page Cannot format. ≥The disc is dirty. Use a special cleaner and wipe clean. ≥You tried formatting a disc that is not compatible with this unit. 60 14 Cannot create chapters. — Cannot mark the start point or the end point during “Shorten” operation. ≥The unit writes the chapter division information to the disc when you turn it off or remove the disc. The information is not written if there is an interruption to the power before this.
PAGE 60
7392en.book 60 ページ２００４年４月２７日火曜日午後５時３０分 Maintenance/HDD, disc and card handling Unit care The precision parts in this unit are readily affected by the environment, especially temperature, humidity, and dust. Cigarette smoke also can cause malfunction or breakdown. To clean this unit, wipe with a soft, dry cloth. ≥Never use alcohol, paint thinner or benzine to clean this unit. ≥Before using chemically treated cloth, read the instructions that came with the cloth carefully.
PAGE 61
7392en.book 61 ページ２００４年４月２７日火曜日午後５時３０分 Limited Warranty Panasonic Consumer Electronics Company, Division of Matsushita Electric Corporation of America One Panasonic Way Secaucus, New Jersey 07094 Panasonic Sales Company, Division of Matsushita Electric of Puerto Rico, Inc., Ave. 65 de Infantería, Km. 9.
PAGE 62
7392en.book 62 ページ２００４年４月２７日火曜日午後５時３０分 Guía de referencia rápida en español Español Conexión de un televisor y videograbadora Conexión de un receptor de TV por cable Consulte la ilustración que aparece en la página 7 de la sección en idioma inglés. Consulte la ilustración que aparece en la página 8 de la sección en idioma inglés. ≥Las conexiones del equipo descritas son ejemplos. ≥Antes de hacer la conexión, apague todos los equipos y lea los manuales de instrucciones apropiados.
PAGE 63
２００４年４月２７日火曜日午後５時３０分 Preparación del sistema de guía de TV en pantalla Consulte la ilustración que aparece en la página 10 de la sección en idioma inglés. Después de enchufar la unidad en una toma de CA de casa y pulsar [Í DVD POWER] para encender la unidad por primera vez, ésta inicia la preparación del sistema de guía de TV en pantalla. En el sistema de guía de TV en pantalla sólo se muestra inglés. No se pueden mostrar otros idiomas.
PAGE 64
7392en.book 4 ページ２００４年４月２７日火曜日午後５時３０分 Index Angle. . . . . . . . . . . . . . . . . . . . . . . . . . . . Antenna system . . . . . . . . . . . . . . . . . . Audio Attribute . . . . . . . . . . . . . . . . . . . . . . Language. . . . . . . . . . . . . . . . . . . . . Playback . . . . . . . . . . . . . . . . . . . . . Receiving, recording . . . . . . . . . . . . 30 47 30 47 26 17 Change Thumbnail . . . . . . . . . . . . . . . . 33 Channel Adjusting, hiding . . . . . . . . . . . . . . . 23 Audio . . .
