3.2 Gain Setting
The high grade instrumentation provides software programmable gains or
switch selectable gain of 0.5 1, 5, 10, 50, 100, 500, 1000.
Software Setting : JP18 should be place on “R”
Switch Setting : JP18 should be place on “L”
Software Setting
(Remote control)
Switch Setting
(Local Control)
Gain
DO 6 DO 5 DO 4 SW1-3 SW1-2 SW1-1
0 0 0 ON ON ON 0.5
0 0 1 ON ON OFF 1
0 1 0 ON OFF ON 5
0 1 1 ON OFF OFF 10
1 0 0 OFF ON ON 50
1 0 1 OFF ON OFF 100
1 1 0 OFF OFF ON 500
1 1 1 OFF OFF OFF 1000
