Datasheet

2
NIC COMPONENTS CORP. www.niccomp.com www.lowESR.com www.RFpassives.com www.SMTmagnetics.com
®
Specifi cations are subject to change
NIC
P/N
INDUCTANCE
VALUE (nH)
INDUCTANCE
TOLERANCE
FREQUENCY
(MHz)
Q FACTOR
SRF
(MHz)
Minimum
Rated DC
Resistance
(ohms)
Rated DC
Current
(mA)
NIN-HK1N8_TRF 1.8 S, J, K 250 20@250MHz >6000 0.043 950
NIN-HK2N0_TRF 2.0 S, J, K
250 19@250MHz 7000 0.084 1040
NIN-HK2N2_TRF 2.2 S, J, K 250 22@250MHz >6000 0.058 820
NIN-HK3N0_TRF 3.0 S, K 250 24@250MHz >6000 0.063 790
NIN-HK3N3_TRF 3.3 S, J, K
250
24@250MHz >6000 0.063 790
NIN-HK3N6_TRF 2.6 S, J, K 250 24@250MHz >6000 0.063 790
NIN-HK3N9_TRF 3.9 S, J, K
250
24@250MHz >6000 0.063 790
NIN-HK4N3_TRF 4.3 S, J, K 250 22@250MHz >6000 0.070 750
NIN-HK4N7_TRF 4.7 S, J, K 250 20@250MHz >6000 0.120 570
NIN-HK5N1_TRF 5.1 J, K 250 23@250MHz >6000 0.100 620
NIN-HK5N6_TRF 5.6 J, K
250
25@250MHz >6000 0.078 710
NIN-HK6N2_TRF 6.2 J, K 250 25@250MHz >6000 0.078 710
NIN-HK6N8_TRF 6.8 J, K
250
24@250MHz 6000 0.105 610
NIN-HK7N5_TRF 7.5 G, J, K 250 25@250MHz 6000 0.120 570
NIN-HK8N2_TRF 8.2 G, J, K
250
25@250MHz 5500 0.110 590
NIN-HK9N1_TRF 9.1 G, J, K 250 25@250MHz 5500 0.110 590
NIN-HK100_TRF 10 G, J, K
250
24@250MHz 5500 0.150 510
NIN-HK110_TRF 11 G, J, K 250 26@250MHz 5500 0.120 570
NIN-HK120_TRF 12 G, J, K
250
26@250MHz 5500 0.120 570
NIN-HK130_TRF 13 G, J, K 250 24@250MHz 5000 0.180 460
NIN-HK150_TRF 15 G, J, K
250 24@250MHz 3300 0.204 560
NIN-HK160_TRF 16 G, J, K
250
25@250MHz 4500 0.280 370
NIN-HK200_TRF 20 G, J, K 250 26@250MHz 4000 0.240 400
NIN-HK220_TRF 22 G, J, K
250 24@250MHz 2800 0.360 400
NIN-HK240_TRF 24 G, J, K 250 25@250MHz 3500 0.360 330
NIN-HK270_TRF 27 G, J, K
250
25@250MHz 3500 0.380 320
NIN-HK300_TRF 30 G, J, K 250 25@250MHz 3300 0.380 320
NIN-HK330_TRF 33 G, J, K
250 24@250MHz
3200 0.550 260
NIN-HK360_TRF 36 G, J, K 250 25@250MHz 3100 0.600 250
NIN-HK390_TRF 39 G, J, K
250 25@250MHz
3000 0.600 250
NIN-HK430_TRF 43 G, J, K 250
25@250MHz
3000 0.680 240
NIN-HK470_TRF 47 G, J, K 250 25@250MHz 2900 0.950 200
NIN-HK510_TRF 51 G, J, K 250 25@250MHz 2850 0.950 200
NIN-HK560_TRF 56 G, J, K 250 25@250MHz 2800 1.050 190
NIN-HK620_TRF 62 G, J, K 250 25@250MHz 2600 1.050 190
NIN-HK680_TRF 68 G, J, K 250 25@250MHz 2500 1.350 170
NIN-HK750_TRF 75 G, J, K 250 24@250MHz 2400 1.750 140
NIN-HK820_TRF 82 G, J, K 250 25@250MHz 2300 1.900 140
NIN-HK910_TRF 91 G, J, K 250 25@250MHz 2100 1.950 140
NIN-HKR10_TRF 100 G, J, K 250 24@250MHz 1500 2.060 130
NIN-HKR12_TRF 120 G, J, K 250 25@250MHz 1000 2.060 130
NIN-HK SERIES K-SIZE (0402) STANDARD VALUES
Wirewound Chip Inductors
NIN-H Series
Note: Extended values, tolerances, and enhanced versions are available please contact NIC for more details.
