Modulation Page
As with all other engines and Drumsynths, the Modulation page contains one parameter: Veloc-
ity.
Element Description
SCALE Section
Velocity Adjusts the velocity response of the drum. Available values range from
-100.0 % to 100.0 % (default value). At zero (mid course), the drum is played
at full velocity, no matter how hard you hit the keys (or pads). From that mid
position, by turning the knob to the right you increase the positive velocity re-
sponse and make the drum more and more sensitive to the velocities at which
you hit the keys/pads. From the mid position, turning the knob to the left as
the inverse effect: the harder you hit the key/pad, the softer the resulting drum
sound will be.
10.2.5 Kick – Snappy
The Snappy kick is an acoustic bass drum emulation that provides control over the mic oscilla-
tion before the hit via the Snap control. It’s capable of a mid-range bass drum sound that can
be tweaked via the extended punch parameters.
The parameters described below are presented as they appear in the Control area (Arrange
view). The same parameters are available in the Plug-in panel within the Plug-in Strip (Mix
view). See ↑9.4, The Plug-in Strip for more information on this.
Element Description
MAIN Section
Engine Selects the engine used in the Kick Plug-in. If you change this setting, please
refer to ↑10.2, The Kicks.
Tune Adjusts the pitch of the drum played by the middle C, measured in MIDI note
numbers and cents. Available values range from 36.00 to 60.00. The default
value is 48.00. For more details see ↑10.1.5, Pitch Range, Tuning, and MIDI
Notes.
Decay Adjusts the duration of the sound’s tail, measured as a percentage. Available
values range from 0.0 to 100.0 % (default: 50.0 %).
Using the Drumsynths
The Kicks
MASCHINE STUDIO - Manual - 450
