For Model No.
This manual contains important safety precautions and information of correct use. Please be sure to read this manual carefully before use so as to avoid any accidents. Do not place the product in hot, wet or dusty environment, especially during summer, do not leave the product inside a car with all windows closed. Avoid dropping, impacting or shaking the product violently, otherwise it may cause damages or malfunctions. Select a proper volume to avoid ear problem when using earphones.
Specification Hardware Software 7.85” LCD Touch screen (1024x768 pixel) Capacitive multi-touch (5 touch) point function CPU : ARM cortex A9 family processor RAM : DDR3 1GB (3D accelerator possible for 3D games) Wi-Fi (IEEE802.11 b/g/n) for internet connection USB host for OTG function G-sensor Micro SD card slot recognizing up to 32GB Built-in speaker & Built-in MIC 5V DC power adapter Compatible with keyboard mouse Dimension : 200 x 136 x 7.9mm Android 4.1.
Nomenclature Micro SD Earphone HDMI USB Poewr Reset Camera Camera Important Notice - If the device is freezing or stuck, press the reset button(a small hole) or long press power button for 7seonds. - When the performance is slow after using some applications, it is recommended to close running application in setting menu. Caution - For charging, be sure to use the power adapter(DC5V) that is provided in the package, otherwise, the device may be damaged and does not work.
1.
3 Standby mode(Screen off mode) / Unlock the screen Page 5
4 System settings On the desktop, press menu button and select system settings.
Press system settings 1. Wireless & networks 2. Sound Set up each setting as you like. Wi-Fi settings - Press Wi-Fi settings, then the device will automatically search the available Wi-Fi signals. Select the network you want to connect with.
3. Display 4. Storage Set up each setting as you like. Check device memory and microSD card status. Unmount SD card – Unmount the SD card for safe removal.
5. Battery 6. Apps Check battery usage status. Manage downloaded or running applications. Downloaded All installed application are listing.
Keep pressing an application to manage. Press Uninstall to uninstall the selected application. Page 10 Running services View and control currently running services.
7. Location access Access to my location – Let apps that have asked your permission use your location information Wi-Fi & mobile network location – Let apps use Google’s location service to estimate your location faster. Anonymous location data will be collected and sent to Google.
8. Security Screen lock – Protect your device from unauthorized use by creating a personal screen unlock pattern. Make passwords visible – Show password as you type. Unknown sources - If you want to allow installation of non-Market Applications, Press Unknown sources and presses OK.
9. Language & input Language – Choose your preferable language. Keyboard & input method – Change keyboard & keyboard settings. On Language & input settings, if you need other languages besides English on keyboard, press the relevant keyboard and enter the chosen Keyboard settings, select Keyboards, press the language you need.
10. Date & time Set date & time and format 11. Developer options Set options for application development 12.
How to connect/disconnect the device to/from the computer On main desktop, connect the device with the PC, drag notification bar on the desktop Page 15
Press “USB connected”, select “Turn on USB storage”. The device is recognized at Explorer of the computer. Now you can use it as an external storage.
How to install Applications(.apk file) into the device Method 1. 1. Connect the device with internet. See above [1.Wireless & networks] in order to connect internet. 2. Run “Opera mobile” and search the applications you want to install. 3. Follow the instruction on the screen for installation. Method 2. 3. Connect the device with your computer. See above [How to connect/disconnect the device with/from the computer.
HDMI connection with TV Turn on the device and TV Connect the device to the TV using HDMI cable. Note HDMI cable is optional, it may not come in the package, depending on countries.
How to make desktop icons Press the Page 19 icon of desktop and the pop-up displays.
Shortcuts Long press your desired APK icon and put it on the desktop. Widgets Long press your desired wiget icon and put it on the desktop. Wallpaper Long press the desktop, press Wallpapers and select one of categories of wallpaper. Select one you desire and press Set wallpaper.
Change Input Method If your device was installed with other more input method, long press setting icon of keyboard, and the pop-up displays. Select the installed keyboard, then the keyboard will appear with your desired language you installed.
Specification OS CPU SDRAM Display Multi-touch screen IO PORTS Speaker G-sensor Camera Wi-Fi Power Battery Dimension Charging time Page 22 Audio port USB port DC port HDMI port Micro SD OTG port Button by charger Android 4.1.1 ARM cortex A9 Family processor DDR3 1GB (3D accelerator possible for 4D games) 7.85" LCD Capacitive touch panel Yes : 5 point multi-touch 4 / 8 / 16GB 3.5ø earphones 1 x 5pin micro USB port (support USB host and OTG) 5V, 2A YES Micro SD card Same with USB port Power, Reset 1.
Page 23
For more information please check our website www.mpmaneurope.
