NPort W2004 User’s Manual Initial IP Configuration
3-3
Telnet Console
1. From the Windows desktop, click on Start and then select Run
2. Type telnet 192.168.126.254 (default IP address) in the Open text input box, and then click
on OK.
When the Telnet window opens, if you are prompted to input the Console password, input the
password and then press Enter .Note that this page will only appear if the NPort W2004 is
password protected.
----------------------------------
Host Name : NPW2004_20
Model Name : NPort W004-US
LAN MAC Address : 00:90:e8:93:04:36
WLAN MAC Address : N/A
Serial No : 20
Firmware Version : 0.0.1.1_beta6
----------------------------------
<< Main Menu >>
(1) Time Settings
(2) Network Settings
(3) Serial Port Settings
(4) System Management
(q) Quit
3. Type 2 to select Network settings, and then press Enter.
----------------------------------
Host Name : NPW2004_20
Model Name : NPort W004-US
LAN MAC Address : 00:90:e8:93:04:36
WLAN MAC Address : N/A
Serial No : 20
Firmware Version : 0.0.1.1_beta6
----------------------------------
<< Main Menu >>
(1) Time Settings
(2) Network Settings
(3) Serial Port Settings
(4) System Management
(q) Quit
Key in your selection: 2
4. Type 2 to select Ethernet Configuration and then press Enter.
