xiii Introduction This guide provides information about setting up and configuring MC3000 mobile computers and accessories. Screens and windows pictured in this guide are samples and may differ from actual screens. Documentation Set The documentation set for the MC3000 is divided into guides that provide information for specific user needs. • • • • • Microsoft Application Guide - describes how to use Microsoft developed applications.
xiv MC3000 Integrator Guide Configurations This guide covers the following configurations: MC3000-R - color or monochrome display, 32MB/64MB or 64MB/64MB memory, laser scanner in rotating turret, Windows CE .NET 5.0 Core or Windows CE .NET 5.0 Professional Operating System. MC3090-G - 802.11b/g/a radio, color or monochrome display, 32MB/64MB or 64MB/64MB memory, laser scanner or imager, Windows CE .NET 5.0 Core or Windows CE .NET 5.0 Professional Operating system, optional Bluetooth radio. MC3090-K - 802.
xv Notational Conventions The following conventions are used in this document: • • • • • The term “mobile computer” refers to the Symbol MC3000. Italics are used to highlight the following: • Chapters and sections in this and related documents • Dialog box, window and screen names • Drop-down list and list box names • Check box and radio button names • Icons on a screen. Bold text is used to highlight the following: • Key names on a keypad • Button names on a screen.
xvi MC3000 Integrator Guide Service Information If an equipment problem occurs, contact the appropriate regional Symbol Support Center. See page xvi for contact information. Before calling, have the model number, serial number and several bar code symbols at hand. Call the Support Center from a phone near the scanning equipment so that the service person can try to talk through the problem.
xvii Finland/Suomi Oy Symbol Technologies Kaupintie 8 A 6 FIN-00440 Helsinki, Finland 9 5407 580 (Inside Finland) +358 9 5407 580 (Outside Finland) France Symbol Technologies France Centre d'Affaire d'Antony 3 Rue de la Renaissance 92184 Antony Cedex, France 01-40-96-52-21 (Inside France) +33-1-40-96-52-50 (Outside France) Germany/Deutschland Symbol Technologies GmbH Waldstrasse 66 D-63128 Dietzenbach, Germany 6074-49020 (Inside Germany) +49-6074-49020 (Outside Germany) Italy/Italia Symbol Technologies
xviii MC3000 Integrator Guide Sweden/Sverige “Letter” address: Symbol Technologies AB Box 1354 S-171 26 SOLNA Sweden Visit/shipping address: Symbol Technologies AB Solna Strandväg 78 S-171 54 SOLNA Sweden Switchboard: 08 445 29 00 (domestic) Call Center: +46 8 445 29 29 (international) Support E-Mail: Sweden.Support@se.symbol.com If the Symbol product was purchased from a Symbol Business Partner, contact that Business Partner for service.
Getting Started Chapter Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 Unpacking the Mobile Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 MC3000 Integrator Guide
Getting Started 1-3 Introduction This chapter describes the mobile computer’s physical characteristics, how to install and charge the batteries, how to remove and replace the Strap/Door Assembly and how to start the mobile computer for the first time. Unpacking the Mobile Computer Carefully remove all protective material from around the mobile computer and save the shipping container for later storage and shipping.
1-4 MC3000 Integrator Guide Table 1-1. MC3000 Accessories (Continued) Accessory Description Stylus Performs pen and mouse functions. Plastic Holster Provides a clip on holder for the mobile computer. Fabric Holster Provides a soft, clip on holder and a shoulder strap for the mobile computer. Symbol Mobility Developer Kit for C A development tool used to create native C and C++ applications for all Symbol mobile computers running the Microsoft Windows CE operating system.
Getting Started 1-5 Parts There are three versions of the MC3000 mobile computers, the MC3000 1D/2D Imager (MC3000-K or MC3090-K), the MC3000 Laser with Rotating Scan Turret (MC3000-R or MC3090-R) and the MC3090 Gun (MC3090-G). For more information on the Rotating Scan Turret, see Figure 1-3 on page 1-6.
1-6 MC3000 Integrator Guide Headset Jack (optional) Scan Window Scan Window Strap/Door Assembly Screws Headset Jack (optional) Stylus Strap/Door Assembly Stylus Holder Latches MC3000-K MC3000-R Figure 1-2. MC3000 Imager (MC3000-K) and MC3000 Laser (MC3000-R) Mobile Computers (back view) Rotating Scan Turret The MC3000-R mobile computer features a Rotating Scan Turret with three position stops. This feature offers greater scanning flexiblilty.
Getting Started 1-7 Beeper Scan LED Indicators (red/green) Charge LED Indicator (amber) Indicator LED Bar Display Scan Button Keypad Power Scan LED Indicator (red/green) Trigger Figure 1-4. MC3090-G Mobile Computer Mobile Computer Startup To start using the mobile computer: • • • Install the main battery. Charge the main battery and the backup battery. Start the mobile computer. Install Main Battery If the main battery is charged, the mobile computer can be used immediately.
1-8 MC3000 Integrator Guide 3. Insert the battery into the slot, bottom first and press the battery gently into the slot. The battery clip locks the battery into place. 4. With the latches in the open position, replace the Strap/Door Assembly, top first and press to close. 5. Rotate the latches (to the lock position) to lock the Strap/Door Assembly in place. Latches Hand Strap Battery Clip Battery Slot Battery Strap/Door Assembly Figure 1-5.
Getting Started 1-9 Latches Hand Strap Strap/Door Assembly Battery Strap/Door Assembly Figure 1-6.
1-10 MC3000 Integrator Guide Battery Charging Use the mobile computer cradles, cables and spare battery chargers to charge the mobile computer main battery. The main battery can be charged before insertion into the mobile computer or after it is installed. There are two main batteries for the MC3000, the Standard Battery and the Extended Life Battery. Either battery can be used, but the Extended Life Battery requires a different Strap/Door Assembly.
Getting Started 1-11 Table 1-2. Mobile Computer LED Charge Indicators LED Off Indication Mobile computer not placed correctly in the cradle; cable not connected correctly; charger is not powered. Fast Blinking Amber Error in charging; check placement of the mobile computer. Slow Blinking Amber Mobile computer is charging. Solid Amber Charging complete.
1-12 MC3000 Integrator Guide Starting the Mobile Computer When the mobile computer is powered on for the first time, it initializes. The Symbol Splash screen appears for a short period of time, followed by the Calibration screen. Figure 1-7. Symbol Splash Screen After the calibration procedure is performed the factory default settings launch the Demo window. Application specific shells may provide application specific windows instead of the Demo window.
Getting Started 1-13 Demo Window The Demo window is the factory default menu. On initial power up (or on a warm or cold boot) the Demo window appears. These sample/demo applications are intended to be used by application developers as application development examples. These applications were not developed to support end users. Refer to the Symbol Application Guide for information about the Demo window applications. Figure 1-9.
1-14 MC3000 Integrator Guide Resetting the Mobile Computer If the mobile computer stops responding to input, reset it. There are two reset functions, warm boot and cold boot. A warm boot restarts the mobile computer by closing all running programs. All data that is not saved is lost. A cold boot also restarts the mobile computer, but erases all stored records and entries from RAM. In addition it returns formats, preferences and other settings to the factory default settings. Perform a warm boot first.
Getting Started 1-15 Waking the Mobile Computer The wakeup conditions are configurable and the current factory default settings are subject to change/update. The mobile computer wakeup configuration is set in the registry file. Table 1-3 lists the default wakeup conditions settings. Table 1-3. Default Wakeup Conditions Status Power Off Description Conditions for wakeup When the mobile computer goes into 1. Power button is pressed. suspend mode by pressing Power, 2. AC power added or removed.
1-16 MC3000 Integrator Guide Main Battery Removal Before removing the main battery, press the red Power button to turn off the screen and set the mobile computer to suspend mode. To remove the main battery: 1. Rotate the latches to the open position. Do not lift up on the Latches when removing the Strap/Door Assembly. Lift up on the Hand Strap only. 2. Lift the Hand Strap to lift the Strap/Door Assembly off, bottom first. 3. Release battery: a.
Getting Started 1-17 Latches Strap/Door Assembly Battery Pull Tab Battery Battery with Pull Tab Battery without Pull Tab Figure 1-11.
1-18 MC3000 Integrator Guide Strap/Door Assembly Removal and Replacement The Strap/Door Assembly consists of a hand strap and the battery door. There are two versions of this assembly, one for the Standard Battery and one for the Extended Life Battery. Before removing the Strap/Door Assembly, press the red Power button to turn off the screen and set the mobile computer to suspend mode. To remove the Strap/Door Assembly: 1. Rotate the latches to the open position.
Getting Started 1-19 Strap/Door Assembly Removal and Replacement (MC3090-G) The Strap/Door Assembly consists of a hand strap and the battery door. Before removing the Strap/Door Assembly, press the red Power button to turn off the screen and set the mobile computer to suspend mode. To remove the Strap/Door Assembly: 1. Slip the button through the loop. 2. Remove loop section from handle. 3. Rotate the latches to the open position. Do not lift up on the latches when removing the Strap/Door Assembly.
1-20 MC3000 Integrator Guide File System Directory Structure The mobile computer directory structure displays all of the file folders. The pre-installed folders are in flash file system memory and optional removable storage devices (SD storage cards). Figure 1-14. Mobile Computer Directory Structure • • • • Application and Platform folders are located in flash file system memory. The Windows, Program Files, profiles, and My Documents folders are composites, RAM based folders generated from ROM.
Accessories Chapter Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3 Cradles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3 Spare Battery Chargers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-2 MC3000 Integrator Guide Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14 Spare Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-15 LED Charge Indications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-15 Cables . .
Accessories 2-3 Introduction The MC3000 accessories provide a variety of product support capabilities. Accessories include cradles, cables, spare battery chargers and SD cards. Cradles • • • Single Slot Serial/USB cradle charges the mobile computer main battery and/or a spare battery. It also synchronizes the mobile computer with a host computer through either a serial or a USB connection. Four Slot Charge Only cradle charges up to four mobile computers.
2-4 MC3000 Integrator Guide Single Slot Serial/USB Cradle This section describes how to set up and use the Single Slot Serial/USB cradle. For cradle setup, see Figure 2-2. For communications setup procedures, see USB Connection Setup on page 2-32 and/or Serial Communication Setup on page 2-30. The Single Slot Serial/USB cradle: • • • • • Provides 5.4VDC power for operating the mobile computer, charging the battery and charging a spare battery.
Accessories 2-5 Battery Charging The Single Slot Serial/USB cradle can charge the mobile computer main battery and a spare battery simultaneously. To charge the mobile computer: 1. Connect the Single Slot Serial/USB cradle to a Symbol approved power source. 2. Slide the mobile computer into the mobile computer slot. The amber Charge LED Indicator indicates the mobile computer battery charging status.
2-6 MC3000 Integrator Guide LED Charge Indications The Single Slot Serial/USB cradle uses the amber Charge LED Indicator to indicate MC3000 battery charging status and the Spare Battery Charging LED to indicate spare battery charging status. See Table 2-1 for charging status indications. Table 2-1. LED Charging Status Indicators LED Indication Mobile Computer Charging (LED on mobile computer) Off Mobile computer not placed correctly in the cradle; cable not connected correctly; charger is not powered.
Accessories 2-7 Four Slot Charge Only Cradle The Four Slot Charge Only cradle: • • Provides 5.4VDC power for operating the mobile computer and charging the battery. Simultaneously charges up to four mobile computers. Use only a Symbol approved power supply output rated 12 VDC and minimum 9 A. Use of an alternative power supply will void the product warranty and may cause product damage. See the MC3000 User Guide for the power supply regulatory compliance statement.
2-8 MC3000 Integrator Guide Battery Charging The Four Slot Charge Only cradle can charge up to four mobile computers simultaneously. To charge the mobile computer: 1. Connect the Four Slot Charge Only cradle to a Symbol approved power source. 2. Slide the mobile computer into the mobile computer slot. Charge LED Indicator (amber) Scan/Charge Indicator LED Bar Mobile Computer Slot Power LED Figure 2-4. Four Slot Charge Only Cradle 3.
Accessories 2-9 Four Slot Ethernet Cradle This section describes how to set up and use a Four Slot Ethernet cradle with the mobile computer. The Four Slot Ethernet cradle: • • Provides 5.4 VDC power for operating the mobile computer. Connects the mobile computer (up to four) to an Ethernet network. You cannot ActiveSync using the Four Slot Ethernet cradle. To ActiveSync with a host computer, use the SIngle Slot Serial/USB cradle.
2-10 MC3000 Integrator Guide Double-tap the LAN icon to open the LANNDS1 window. This window display the TCP/IP information for the mobile computer. LAN Icon Figure 2-6.
Accessories 2-11 Charging and Communication Insert the mobile computer into a slot to begin charging and initiate communication. Charge LED Indicator (amber) Scan/Charge Indicator LED Bar Mobile Computer Slot Speed LED Link LED Figure 2-7. Four Slot Ethernet Cradle LED Charge Indications The charge LED shows the status of the battery charging in the mobile computer. The Standard Battery usually charges in less than four hours and the Extended Life Battery usually charges in less than six hours.
2-12 MC3000 Integrator Guide Daisychaining Ethernet Cradles To connect several cradles to an Ethernet network, up to four (recommended maximum) Ethernet cradles may be daisychained. The Speed LED and the Link LED on the Ethernet port 2 function in the same way as the Speed LED and the Link LED on the front of the cradle. To daisychain cradles: 1. Connect the first Ethernet cradle to power and to the Ethernet Switch as shown on Figure 2-5 on page 2-9. 2. Connect power to the second Ethernet cradle. 3.
Accessories 2-13 Wall Mount Bracket Use the optional Wall Mount Bracket to mount a four slot cradle directly to a wall. To attach the Wall Mount Bracket: 1. Use the Wall Mount Bracket as a template and mark the locations of the four mounting screws. Use fasteners appropriate for the type of wall and the Wall Mount Bracket, mounting slots. The Wall Mount Bracket, mounting slots are designed for a fastener with a #8 pan head. 2. Mount the fasteners to the wall.
2-14 MC3000 Integrator Guide 6. Align the Wall Mount Bracket mounting tabs with the mounting slots in the back of the four slot cradle. Slip the two mounting tabs into mounting slots. 7. Swing the four slot cradle down onto the mounting bracket and align the mounting screws so that they fit into the screw slots. Wall Mount Bracket Screw Slots Power Supply Well Figure 2-11. Wall Mount Bracket 8. Tighten the mounting screws to secure the four slot cradle to the Wall Mount Bracket. Figure 2-12.
Accessories 2-15 Four Slot Spare Battery Charger The Four Slot Spare Battery Charger simultaneously charges up to four spare batteries. Use only a Symbol approved power supply output rated 12 VDC and minimum 3.3 A. Use of an alternative power supply will void the product warranty and may cause product damage. See the MC3000 User Guide for the power supply regulatory compliance statement. Setup Connect the Four Slot Spare Battery Charger to a Symbol approved power source.
2-16 MC3000 Integrator Guide Spare Battery Charging To charge up to four MC3000 spare batteries: 1. Insert the spare battery into the spare battery charging slot, bottom first. 2. Pivot the top of the battery down onto the contact pins. Power Supply 2 1 Battery Clip Spare Battery Charging Slot Spare Batteries Spare Battery Charging LEDs (4) Figure 2-14. Four Slot Spare Battery Charger 3. Gently press down on the battery to ensure proper contact.
Accessories 2-17 Cables This section describes how to setup and use the cables. The cables are available with a variety of connection capabilities. The following MC3000 Communication/Charge cables are available: • • Serial (RS232) Charge cable (9-pin D female with power input receptacle) USB Client Charge cable (standard-A connector and a barrel receptacle for power). Use only a Symbol approved power supply output rated 5.4 VDC and minimum 3 A.
2-18 MC3000 Integrator Guide Setup The MC3000 Communication/Charge cables can connect with a serial/USB device, such as a printer or host computer, through its serial or USB port. Serial (RS232) Cable Power Input Connector Top View MC3000 Connector USB Host Cable Mini-B Connector Power Input Barrel Connector USB Client Cable Standard-A Connector Figure 2-16.
Accessories 2-19 Universal Battery Charger (UBC) Adapter The UBC Adapter can be used with a power supply as a standalone spare battery charger or it can be used with the four station UBC2000 to simultaneously charge up to four spare batteries. For additional information on the UBC 2000, refer to the UBC 2000 Quick Reference Guide, p/n 70-33188-xx. Use only a Symbol approved power supply output rated 15 VDC and minimum 1.5 A.
2-20 MC3000 Integrator Guide 2. Pivot the top of the battery down onto the contact pins. 2 1 Battery Battery Clip UBC Adapter Spare Battery Charging Slot Figure 2-18. UBC Adapter Battery Insertion 3. Gently press down on the battery to ensure proper contact. The Standard Battery usually charges in less than four hours and the Extended Life Battery usually charges in less than six hours. See Table 2-3 for charging status indications. 4.
Accessories 2-21 Secure Device Card The Secure Device (SD) card provides secondary non-volatile storage (the flash memory is slower than RAM). The SD card holder is located under the battery. Follow proper Electro-Static Discharge (ESD) precautions to avoid damaging the SD card. Proper ESD precautions include, but are not limited to, working on an ESD mat and ensuring that the operator is properly grounded. Do not use the SD card slot for any other accessories.
2-22 MC3000 Integrator Guide Copy Files onto the SD Card The SD card can be used to store files or programs used by the mobile computer. Files may be copied using an available file browser, or using ActiveSync. InkWiz is a provided tool that is being used as an example of how to access data on the SD card. 1. From the Series 3000 Demo window, double-tap the Files icon. The InkWiz Example window appears. Figure 2-21. InkWiz Window 2.
Accessories 2-23 5. Tap the Edit - Paste to paste the file into the Storage Card partition. The Storage Card partition now shows that the MSIMGSIZ.DAT file is in the Storage Card partition. Figure 2-23. InkWiz, Paste File Delete a File From The SD Card InkWiz is a provided tool that can be used to delete data from the SD card. 1. 2. 3. 4. Tap the MSIMGSIZ.DAT file to highlight. Tap File - Del to delete the file from the Storage Card partition. The Question window appears.
2-24 MC3000 Integrator Guide Format an SD Card Use the Storage Manager to format the SD card. 1. Tap Start - Settings -Control Panel to access the Windows Control Panel. Figure 2-25. Windows Control Panel 2. Double tap the Storage Manager icon to access the Storage Properties Window. Do not select any other partitions for formatting. The DSK3: SD/MMC Card selection is the only entry that can be formatted. Formatting the other partitions may render the mobile computer unusable. Figure 2-26.
Accessories 2-25 5. If the SD card does not have an existing partition, tap New. The Create New Partition dialog box appears. If a partition exists, proceed to step 7. Figure 2-27. Create New Partition Window 6. In the Name: text box enter a partition name, and tap OK. The Storage Properties window appears. Figure 2-28. Storage Properties Window 7. The Storage Properties window displays the new partition name in the Partitions: box.
2-26 MC3000 Integrator Guide 9. Tap Properties, the Partition Properties window appears. Figure 2-29. Partition Properties 10. Tap Format, the Format window appears. Figure 2-30. Format Windows 11. The default settings for the Format window are to perform a Quick Format. To perform a full format tap the Quick Format check box to uncheck. 12. Tap Start, the Format confirmation window appears. Figure 2-31.
Accessories 2-27 13. Tap Yes, the Format in progress window appears. Figure 2-32. Format In Progress Window 14. The Format in progress window completion bar indicates the status of the format. When the format is complete the Format complete window appears with a Format Complete message. Figure 2-33. Format Complete Window 15. Tap OK, the Partition Properties window appears. . Figure 2-34.
2-28 MC3000 Integrator Guide 16. Tap OK, the Storage Properties window appears. Figure 2-35. Storage Properties Window 17. Tap OK, to exit the Storage Manager.
Accessories 2-29 Serial/USB Communication This section provides information on installing the appropriate serial/USB communication software and setting up the appropriate accessory to enable serial/USB communication between the mobile computer and the host device. The mobile computer is capable of communicating with a number of hosts, including development computers, serial devices, printers, etc.
2-30 MC3000 Integrator Guide Serial Communication Setup The serial communication setup is used to set up to communicate between the host and the mobile computer using either a Single Slot Serial/USB cradle or using one of the serial MC3000 Communication/Charge cables. For serial communication using the Single Slot Serial/USB cradle, connect only the serial cable, do not connect both the serial cable and the USB cable.
Accessories 2-31 7. In the ActiveSync window, select File - Connection Settings, the Connection Settings window appears. 8. Select the appropriate COM port for the host computer. Figure 2-38. Serial Connection Setting 9. Tap OK to save any changes made. Every mobile computer should have a unique device name. Never try to synchronize more than one mobile computer to the same name. 10. Connect the device to the host computer.
2-32 MC3000 Integrator Guide USB Connection Setup The USB communication setup is used to set up to communicate between the host and the mobile computer using either a Single Slot Serial/USB cradle or using one of the serial MC3000 Communication/Charge cables. For serial communication using the Single Slot Serial/USB cradle, connect only the USB cable, do not connect both the USB cable and the serial cable.
Accessories 2-33 8. In the ActiveSync window, select File - Connection Settings, the Connection Settings window appears. 9. Confirm that the Allow USB check box is selected. Figure 2-41. USB Connection Setting 10. Tap OK to save any changes made. Every mobile computer should have a unique device name. Never try to synchronize more than one mobile computer to the same name. 11. Connect the device to the host computer.
2-34 MC3000 Integrator Guide
ActiveSync Chapter Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 Mobile Computer Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 Installing ActiveSync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-2 MC3000 Integrator Guide
ActiveSync 3-3 Introduction To communicate with various host devices, install Microsoft ActiveSync (version 3.7 or higher) on the host computer. Use ActiveSync to synchronize information on the mobile computer with information on the host computer. Changes made on the mobile computer or host computer appear in both places after synchronization. ActiveSync software: • • • • • • Allows mobile computer-compatible host applications to be run on the mobile computer.
3-4 MC3000 Integrator Guide Microsoft recommends installing ActiveSync on the host computer before connecting the mobile computer. Before setting up a partnership between the mobile computer and host computer. See the Chapter 2, Accessories for a list of the accessories that can be used. Setting Up an ActiveSync Connection on the Host Computer 1. Select Start - Programs - Microsoft ActiveSync on the host computer. The Microsoft ActiveSync window appears. Figure 3-2.
ActiveSync 3-5 Setting up a Partnership After ActiveSync installation is complete, the ActiveSync Setup Wizard sets up a partnership to synchronize information between the mobile computer and host computer and customize synchronization settings. To set up a partnership: 1. Connect the mobile computer to the host computer using an accessory described in Chapter 2, Accessories. 2.
3-6 MC3000 Integrator Guide 5. Click the Standard partnership radio button and then select Next. The New Partnership/Specify how to synchronize data window appears. Figure 3-6. How To Sync Window 6. Click the Synchronize with this desktop computer radio button and select Next. The New Partnership/Select Number of Partnerships window appears. Figure 3-7.
ActiveSync 3-7 7. Click the Yes, I want to synchronize with only this computer radio button and then select Next. The New Partnership/Select Synchronization Settings window appears. Figure 3-8. Select Synchronization Settings Window 8. To synchronize a particular type of information, select its check box. To stop synchronization of that information, clear its check box. 9. Click Next. The New Partnership/Setup Complete window appears. Figure 3-9.
3-8 MC3000 Integrator Guide 10. Select Finish. The Connected window appears confirming the connection between the mobile computer and the host. Figure 3-10. ActiveSync Connected Window During the first synchronization, information stored on the host computer is copied to the mobile computer. When the copy is complete and all data is synchronized, the mobile computer can be disconnected from the host computer. The first ActiveSync operation must be performed with a local, direct connection.
Software Installation on Development PC Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4- 3 Required System Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3 DCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-2 MC3000 Integrator Guide
Software Installation on Development PC 4-3 Introduction To develop applications to run on the mobile computer, use one or both of the following: • • • Symbol Mobility Developer Kit (SMDK) for C Platform Software Developer Kit (Platform SDK) for MC3000 Device Configuration Package (DCP) for MC3000. The SMDK for C is a development tool used to create native C and C++ applications for all Symbol mobile computers. It includes documentation, header files (.H), and library files (.
4-4 MC3000 Integrator Guide Components Table 4-1 lists the MC3000 DCP components and their locations. Table 4-1. DCP for MC3000 Components and Locations Component Description Directory Location Files that make up the flash partitions Used to configure the mobile computer. \Program Files\Symbol Device Configuration Packages\MC3000\v1.0\Flash Folders Hex image - default location Loads onto the mobile computer for configuration. \Program Files\Symbol Device Configuration Packages\MC3000\v1.
Software Installation on Development PC 4-5 6. Locate the .exe file on the development computer, double-click the executable file and follow the install screen prompts. 7. Once installed, access the components of the SMDK for C from the Symbol Mobility Developer Kit for C program group of the Windows Start menu. 8. The sample applications provide examples of how to interface with the Symbol API functions. To build a sample application, open the Samples folder from the Windows Start menu.
4-6 MC3000 Integrator Guide Components The sample applications provide examples of how to interface with the Symbol API functions. To build a sample application, open the Samples folder from the Windows Start menu. Open the folder for the desired sample and then open the project file. The project file has an extension of VCP. Microsoft Visual C++ v4.0 automatically launches. Select WinCE as the Active WCE Configuration. Select Win32 (WCE ARMV4) Debug as the active configuration.
Software Installation on Mobile Computer Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3 ActiveSync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3 Copying Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-2 MC3000 Integrator Guide
Software Installation on Mobile Computer 5-3 Introduction With the appropriate accessory, software, and connection, the mobile computer can share information with the host computer. This chapter provides information about installing software and files on the mobile computer. Download/software installations can be performed using: • • • • ActiveSync Initial Program Loader (IPL) AirBEAM SD card. ActiveSync Use ActiveSync to copy files and/or programs from a host computer to the mobile computer.
5-4 MC3000 Integrator Guide 4. Select Explore. Figure 5-2. ActiveSync Explorer 5. Double-click the folder to expand the folder contents. Figure 5-3. Application Folder Contents 6. Use Explorer to locate the host computer directory that contains the file to download. Tap that directory in the left pane to display its contents in the right pane. 7. Drag the desired file(s) from the host computer to the desired mobile device folder.
Software Installation on Mobile Computer 5-5 1. Download the program to the host computer (or insert the CD or disk that contains the program into the host computer). The program may consist of a single *.xip file, *.exe file, a *.zip file, or a Setup.exe file. 2. Read any installation instructions, ReadMe files, or documentation that comes with the program. Many programs provide special installation instructions. 3.
5-6 MC3000 Integrator Guide
Creating/Loading Hex Images Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3 Starting Terminal Configuration Manager. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4 Defining Script Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6-2 MC3000 Integrator Guide
Creating/Loading Hex Images 6-3 Introduction Terminal Configuration Manager (TCM) is an application used to customize flash file system partitions for the mobile computer. The most common use is to create an application partition hex file that contains the customer's application. TCM can also be used to load hex files to the flash memory of the mobile computer. The program resident on the mobile computer that receives the hex file and burns it to the flash memory is called Initial Program Loader (IPL).
6-4 MC3000 Integrator Guide Starting Terminal Configuration Manager Click the Start - Programs - Symbol - Symbol Device Configuration Packages - MC3000 C42V1.0 to start TCM. The TCM window appears displaying two child windows: Script1 and File Explorer. The Script1 window contains a newly created script and the File Explorer window contains a file explorer view used for selecting files to be placed in the script. Figure 6-1. TCM Script 1 Window Table 6-1 lists the TCM window components. Table 6-1.
Creating/Loading Hex Images Table 6-1. TCM Components (Continued) Icon Component Function Small icons button View the current script items as small icons. List button View the current script items as a list. Details button View the current script items with more details. About button Display version information for TCM. Properties button View/change the current script properties. Build button Build the current script into a set of hex files.
6-6 MC3000 Integrator Guide Defining Script Properties Before a script is created, the script properties must be defined. This defines the type of mobile computer, flash type, number of disks being created and the memory configuration of each disk partition. To define the script properties: 1. Select the Script window to make it active. 2. Click the Properties button. The Script Properties window - Partition Data tab appears. Figure 6-2. Script Properties Window - Partition Data Tab 3. 4. 5. 6. 7. 8.
Creating/Loading Hex Images 6-7 Creating the Script for the Hex Image On start-up, TCM displays the TCM window with the Script1 window and File Explorer window pointing to the following directory: \Program Files\Symbol Device Configuration Packages\MC3000C42a\v0.1\TCMScripts\ \Program Files\Symbol Device Configuration Packages\MC3000C42b\v0.1\TCMScripts\ The Script1 window directory pane displays two partitions: Platform and Application.
6-8 MC3000 Integrator Guide Building the Image Once the script is created, the hex image defined by the script can be built. As part of the build, TCM performs a check on the script which verifies that all files referenced in the script exist. This check is important for previously created scripts to ensure that files referenced in the script are still in the designated locations.
Creating/Loading Hex Images 6-9 Sending the Hex Image Once the hex file is built, it can be downloaded to the mobile computer. To load the hex files on to the mobile computer: 1. For downloads using either a serial or a USB connection, connect the mobile computer to the development computer using the Single Slot Serial/USB cradle or MC3000 Communication/Charge cables. 2. Press and hold a yellow Scan button and the Power button simultaneously until the mobile computer resets into IPL. 3.
6-10 MC3000 Integrator Guide Table 6-2. IPL Menu Partitions Partition Name Description Platform Contains the files in the Platform folder. Application Contains the files in the Application folder. Config Block Contains information to correctly configure the operating system for the mobile computer. This information is loaded by the manufacturer. Note: Ensure that an incorrect config block is not loaded into the mobile computer.
Creating/Loading Hex Images 6-11 5. IPL displays the Select Transport menu which lists the available methods of downloading the file. Select Transport USB Lighthouse 0 - Serial Previous Top Figure 6-7. Select Transport Menu 6. Use the up and down scroll keys to select either the Lighthouse 0 - Serial transport method or the USB transport method, then press ENT. 7. If the Lighthouse 0 - Serial transport method is selected, the Select Baud Rate menu appears.
6-12 MC3000 Integrator Guide 10. If USB was selected in the Select Transport menu, the Waiting for Download message appears. Downloading . . . . Auto Select via USB USB standard waiting for input . . . . Figure 6-9. Waiting for Download 11. On the development computer, click Load on the TCM toolbar. The Load Terminal window - Serial tab appears. Figure 6-10. Load Terminal Window - Serial and Ethernet Tabs 12. For serial or USB port connections, click the Serial tab and select the Image Files To Load.
Creating/Loading Hex Images 17. When complete, Device Status displays Result was: Success!, or in the case of an error, the cause of the error. Downloading: “Partition Name” via “Device Parameters” Result was: Success! Press any key to continue Figure 6-11. Downloading Complete Screen 18. On completion, press ENT to return to the IPL menu to select the next partition to download. 19. To exit IPL, select the System Reset item from the IPL menu.
6-14 MC3000 Integrator Guide TCM Error Messages TCM validates the cells in the partition table when the Execute button is clicked. Cells highlighted in red contain an error. Partition loading is disabled until all errors are corrected. Table 6-3. TCM Error Messages Error Description/Solution Failed to build images: flash file system DLL not loaded! TCM could not load the DLL required to build images for the targeting flash file system. Reinstall TCM or recover the DLL.
Creating/Loading Hex Images 6-15 IPL Error Detection While receiving data, IPL performs many checks on the data to ensure that the data is received correctly. If an error is detected, IPL immediately aborts the download, and reports the error on an error screen. Error screens may vary depending on the action being performed.
6-16 MC3000 Integrator Guide Table 6-4. IPL Errors (Continued) Error Text Error Number Probable Cause Insufficient data available to complete record -21 A Symbol HEX file download was attempted but the HEX file is invalid. Ensure the file is in Symbol HEX file format. Invalid Symbol HEX file -23 A Symbol HEX file download was attempted but the HEX file is invalid. Ensure the file is in Symbol HEX file format.
Creating/Loading Hex Images 6-17 Creating a Splash Screen The source bitmap files used to create the default splash screens for the mobile computer are supplied with the DCP for MC3000 These files can be modified using any of the standard windows image editors, allowing customization for particular customers. To create a custom splash screen, perform the following steps: 1. For mobile computers with monochrome screens, open the Splashmono.bmp file supplied with the DCP for MC3000 using an image editor. 2.
6-18 MC3000 Integrator Guide Flash Storage In addition to the RAM-based storage standard on Windows CE mobile computers, the mobile computer is also equipped with a nonvolatile Flash-based storage area which can store data (partitions) that can not be corrupted by a cold boot. This Flash area is divided into two categories: Flash File System (FFS) Partitions and Non-FFS Partitions. FFS Partitions The mobile computer includes two FFS partitions.
Creating/Loading Hex Images 6-19 Making modifications to registry values for drivers loaded before RegMerge is not recommended. However, these values may require modification during software development. Since these early loading drivers read these keys before RegMerge gets a chance to change them, the mobile computer must be cold booted. The warm boot does not re-initialize the registry and the early loading driver reads the new registry values.
6-20 MC3000 Integrator Guide IPL IPL allows the user to upgrade the mobile computer with software updates and/or feature enhancements. Partition Update vs. File Update There are two types of updates supported by the mobile computer: partitions and files. The file system used by the mobile computer is the same as the file system used on a desktop computer. A file is a unit of data that can be accessed using a file name and a location in the file system.
Wireless Applications Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7- 3 Signal Strength Icon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3 Find WLANs Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7-2 MC3000 Integrator Guide Manage Profiles Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-23 Changing Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-24 Editing a Profile . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wireless Applications 7-3 Introduction Wireless LANs allow mobile computers to communicate wirelessly and to send captured data to a host device in real time. Before a mobile computer can be used on a Spectrum24 WLAN, the facility must be set up with the required hardware to run the wireless LAN and the mobile computer must be properly configured. Refer to the documentation that came with the Access Points (APs) for instructions on setting up the hardware.
7-4 MC3000 Integrator Guide Find WLANs Application Use the Find WLANs application to discover available networks in the vicinity of the user and mobile computer. To open the Find WLANs application, tap the Signal Strength icon - Find WLANs. The Find WLANs window displays. Figure 7-2. Find WLAN Window Find WLAN display is limited to 32 items (ESSIDs or MAC addresses). A combination of up to 32 ESSIDs/APs may be displayed.
Wireless Applications 7-5 Tap-and-hold on a WLAN network to launch a context sensitive menu. The menu provides two options: Connect and Refresh. Select Refresh to refresh the WLAN list. Wireless profiles may also be created from one of the listed networks by selecting a network from the list and then selecting Connect. Selecting Connect displays the Profile Editor Wizard. The wizard is initialized to set the values for the selected network.
7-6 MC3000 Integrator Guide Operating Mode Use the Operating Mode dialog box to select the operating mode (Infrastructure or Ad-Hoc) and the country location. Figure 7-4. Operating Mode Dialog Box Table 7-5. Operating Mode Fields Field Description Operating Mode Infrastructure: Select Infrastructure to enable the mobile computer to transmit and receive data with an AP. Infrastructure is the mobile computer default mode.
Wireless Applications 7-7 Ad-Hoc Use the Ad-Hoc dialog box to select the necessary information to control Ad-Hoc mode. This dialog box does not display if Infrastructure mode is selected. To Select Ad-Hoc mode: 1. Select a channel number from the Channel drop-down list. The default is Channel 1 (2412 MHz). Figure 7-5. Ad-Hoc Settings Dialog Box 2. Tap Next. The Authentication dialog box displays. Authentication Use the Authentication dialog box to configure authentication.
7-8 MC3000 Integrator Guide Tunneled Authentication Use the Tunneled Authentication dialog box to select the tunneled authentication options. There are different selections available for PEAP or TTLS authentication. To select a tunneled authentication type Figure 7-7. Tunneled Auth Dialog Box 1. Tap a tunneled authentication type from the drop-down list. 2. Select the User Certificate check box if a certificate is required.
Wireless Applications 7-9 Table 7-8 lists the TTLS tunneled authentication options. Table 7-8. TTLS Tunneled Authentication Options TTLS Tunneled Authentication Description CHAP Challenge Handshake Authentication Protocol (CHAP) is one of the two main authentication protocols used to verify the user name and password for PPP Internet connections. CHAP is more secure than PAP because it performs a three way handshake during the initial link establishment between the home and remote machines.
7-10 MC3000 Integrator Guide User Certificate Selection If the User Certificate check box on the Tunneled Authentication dialog box is checked or if TLS is the selected authentication type, then the Installed User Certificates dialog box displays. The user is required to select a certificate before proceeding. Select a certificate from the drop-down list of currently installed certificates. When a certificate is selected its name appears in the drop-down list.
Wireless Applications 7-11 1. Tap the down arrow on the drop-down list to display the list of currently installed certificates. 2. Tap a certificate to select and its name appears in the drop-down list. 3. Tap the Install Certificate button to install a certificate. Figure 7-10. Installed Server Certs Dialog Box A dialog is displayed that lists the currently loaded certificate files.
7-12 MC3000 Integrator Guide A confirmation dialog displays verifying the installation. If the information in this dialog is correct, tap the Yes button, If the information in this dialog is not correct tap the No button. The wizard returns to the Installed Server Certs dialog box. Credential Cache Options If any of the password based authentication types are chosen, then different credential caching options may be specified.
Wireless Applications • • • • EAP TLS PEAP LEAP TTLS. If the At Time check box is selected the TIme Cache Options dialog box displays. Figure 7-14. Time Cache Options Dialog Box 1. 2. 3. 4. 5. Tap the Interval radio button to check credentials at a set time interval. Enter the value in minutes, in the Min box. Tap Next to continue. Tap the At (hh:mm) radio button to check credentials at a set time. Tap Next. The At Time dialog box appears. Figure 7-15. At Time Dialog Box 6.
7-14 MC3000 Integrator Guide The user name and password can be entered (but is not required) when the profile is created. When a profile authenticates with credentials that were entered in the profile, caching rules do not apply. Caching rules only apply on credentials that are entered through the login dialog box. Figure 7-16. Username Dialog Box Password Use the Password dialog box to enter a password.
Wireless Applications Figure 7-18. Advanced Identity Dialog Box Tap Next, the Encryption dialog box displays.
7-16 MC3000 Integrator Guide Encryption Use the Encryption dialog box to select an encryption type. The Encryption dialog box only allows encryption types that can be used with the currently selected authentication type. See Table 7-11 for the encryption types available with each authentication type. Figure 7-19. Encryption Dialog Box Table 7-10. Encryption Options Encryption Description Open Use the Open option as the default setting when no data packet encryption is needed over the network.
Wireless Applications 7-17 Table 7-11. Encryption / Authentication Matrix Encryption Authentication TTLS Open WEP TKIP No Yes Yes Key Entry Page If either 40-Bit WEP or 128-Bit WEP is selected the wizard proceeds to the key entry dialog box unless the Use Passkey check box was selected in the Encryption Dialog Box (see Figure 7-19 on page 7-16). To enter the key information: 1. Enter the 40-bit or 128-bit keys into the fields. 2. Tap Next. Figure 7-20. 40-Bit WEP Keys Dialog Box Figure 7-21.
7-18 MC3000 Integrator Guide When a user selects None as an authentication and TKIP as an encryption, the user is forced to enter a passkey. The user cannot enter a passkey if the encryption is TKIP and the authentication is anything other than None. Figure 7-22. Passkey Dialog Box Tap Next. The IP Mode dialog box displays. IP Mode Use the IP Mode dialog box to configure network address parameters: IP address, subnet, gateway, DNS and WINS. Figure 7-23. IP Config Tab (DHCP) Table 7-12.
Wireless Applications 7-19 IP Address Entry Use the IP Address Entry dialog box to enter the IP address and subnet information. Figure 7-24. Static IP Address Entry Dialog Box Table 7-13. Static IP Address Entry Fields Field Description IP Address The Internet is a collection of networks with users that communicate with each other.
7-20 MC3000 Integrator Guide Table 7-14. IP Config Advanced Address Entry Fields Field Description G/W The default Gateway is a device that is used to forward IP packets to and from a remote destination. DNS The Domain Name System (DNS) is a distributed Internet directory service. DNS is used mostly to translate domain names and IP addresses. It is also used to control Internet email delivery. Most Internet service requires DNS to operate properly.
Wireless Applications 7-21 Figure 7-27. Transmit Power Dialog Box (Ad-Hoc Mode) Table 7-16. Power Transmit Options (Ad-Hoc Mode) Field Description Full Select Maximum power to set the mobile computer to the highest transmission power level. Select Maximum power when operating in highly reflective environments and areas where other devices could be operating nearby. Additionally, use the maximum power level when attempting to communicate with devices at the outer edge of a coverage area.
7-22 MC3000 Integrator Guide Power consumption is also related to the transmit power settings. Table 7-17. Battery Usage Options Field Description CAM Continuous Aware Mode (CAM) provides the best network performance, but yields the shortest battery life. Fast Power Save Fast Power Save performs in the middle of CAM and MAX Power Save with respect to network performance and battery life. Default.
Wireless Applications 7-23 Table 7-18. Profile Icons Profile is currently in use and describes an ad-hoc profile using encryption. Profile is not valid in the device current operating regulatory domain. The profiles are listed in priority order for use by the automatic roaming feature. Change the order by moving profiles up or down. Edit existing profiles by selecting one in the list and then tap-and-hold to display the menu.
7-24 MC3000 Integrator Guide Export a Profile To export a profile to a registry file, select a profile from the list and select Export from the pop-up menu. The save As dialog box displays with the Application folder and a default name of WCS_PROFILE{profile GUID}.reg (Globally Unique Identifier). Figure 7-30. Save As Dialog Box If required, change the Name field and tap OK. A confirmation dialog box appears after the export is complete.
Wireless Applications 7-25 Wireless Status Application The Wireless Status application window displays the current wireless connection status and information about the wireless connection. To open the Wireless Status window, tap the Signal Strength icon - Wireless Status. The Wireless Status window displays. Figure 7-31. Wireless Status Window The Wireless Status window contains the following options. Tap the option to display the option window.
7-26 MC3000 Integrator Guide Signal Strength Window The Signal Strength window provides information about the connection status of the current wireless profile that includes signal quality, missed beacons and transmit retry statistics. The BSSID address (shown as “AP MAC Address) displays the AP currently associated with the connection. If Ad-Hoc mode is in use, the AP MAC Address shows the BSSID of the Ad-Hoc network. All information in this window updates every 2 seconds.
Wireless Applications Table 7-19. Signal Strength Status Field Description Signal Level The AP signal level in decibels per milliwatt (dBm). Noise Level The background interference (noise) level in decibels per milliwatt (dBm). SNR The access point/mobile computer Signal to Noise Ratio (SNR) of signal strength to noise (interference) in decibels per milliwatt (dBm). Roaming Count Displays the number of APs that the mobile computer has connect to while roaming.
7-28 MC3000 Integrator Guide Current Profile Window The Current Profile window displays basic information about the current profile and connection settings. This window updates every two seconds. To open the Current Profile window, tap Current Profile in the Wireless Status window. The Current Profile window displays. Figure 7-33. Current Profile Window Table 7-20.
Wireless Applications 7-29 IPv4 Status Window The IPv4 Status window displays the current IP address, subnet and other IP related information assigned to the mobile computer. It also allows the address to be renewed if it the profile is currently using DHCP to obtain the IP information. When the user tap Renew a full DHCP discover initiates. The IPv4 Status window should update automatically when the IP address changes. To open the IPv4 Status window, tap IPv4 Status in the Wireless Status window.
7-30 MC3000 Integrator Guide Wireless Log Window The Wireless Log window displays a log of important recent activity, such as authentication, association, DHCP renewal completion, in time order. Users can choose to save the log to a file or to clear the log (within this instance of the application only). There is also an auto scroll feature to automatically scroll down when new items are added to the log. To open the Wireless Log window, tap Wireless Log in the Wireless Status window.
Wireless Applications 7-31 Versions Window The Versions window displays software, firmware and hardware version numbers. This window only updates each time it is displayed. There is no need to update constantly. The content of the window is determined at runtime, along with the actual hardware and software to display in the list. Executable paths of the software components on the list are defined in registry, so that the application can retrieve version information from the executable.
7-32 MC3000 Integrator Guide Wireless Diagnostics Application The Wireless Diagnostics application window provides links to perform ICMP Ping, Trace Routing and Known APs. To open the Wireless Diagnostics window, tap the Signal Strength icon - Wireless Diagnostics. The Wireless Diagnostics window displays. Figure 7-37. Wireless Diagnostics Window The Wireless Diagnostics window contains the following options. Tap the option to display the option window.
Wireless Applications 7-33 ICMP Ping Window The ICMP Ping window allows a user to test a connection at the network layer (part of the IP protocol), between the mobile computer and an AP. Ping tests only stop when the user taps the Stop Test button, closes the Wireless Diagnostics application, or if the mobile computer switches between infrastructure and ad-hoc modes. To open the ICMP Ping window, tap the ICMP Ping in the Wireless Diagnostics window. The ICMP Ping window displays. Figure 7-38.
7-34 MC3000 Integrator Guide Trace Route Window Trace Route traces a packet from a computer to a host, showing how many hops the packet requires to reach the host and how long each hop takes. The Trace Route utility identifies where the longest delays are occurring. The Trace Route window allows a user to test a connection at the network layer (part of the IP protocol), between the mobile computer and any place on the network.
Wireless Applications 7-35 Known APs Window The Known APs window displays the APs in range using the same ESSID as the mobile computer. This window only available when in the Infrastructure mode. To open the Known APs window, tap Known APs in the Wireless Diagnostics window. The Known APs window displays. Figure 7-40. Known APs Window The icon next to the AP indicates: The AP is the currently associated access point, and it is set to mandatory.
7-36 MC3000 Integrator Guide Options Use the wireless Option dialog box to select various operation settings. The options are saved when Save is tapped. If the user taps X before saving and an option was changed, a dialog box displays asking the user to close without saving the changes. The options are: • • • • • • Operating Mode Filtering Regulatory Band Selection System Options Change Password Export.
Wireless Applications 7-37 Regulatory Options Use the Regulatory settings to configure the country the mobile computer is in. Due to regulatory requirements (within a country) a mobile computer is only allowed to use certain channels. Figure 7-42. Regulatory Options Dialog Box Table 7-23. Regulatory Options Field Description Settings Select the country of use from the drop-down list.
7-38 MC3000 Integrator Guide System Options Use the system options to set miscellaneous system setting. Figure 7-44. System Options Dialog Box Table 7-25. Band Selection Options Field Description Profile Roaming Select the Profile Roaming check box to configure the mobile computer to roam to the next available WLAN profile when it moves out of range of the current WLAN profile. Enable IP Mgmt Select Enable IP Mgmt check box to enable the Wireless Companion Services to handle IP Address management.
Wireless Applications 7-39 Change Password Dialog Box Use the Change Password dialog box to require a password before any profile can be edited. This allows system administrators to pre-configure profiles and not allow a user to change the network settings. The user could also use this feature to protect their settings from a guest user. By default, the password is not set. Figure 7-45. Change Password Window 1.
7-40 MC3000 Integrator Guide 1. Tap Export Options. The Save As dialog box displays. Figure 7-47. Export Options Save As Dialog Box 2. The default folder is \Application\FusionApps\Certs\. 3. In the Name field, enter a file name. 4. Tap OK.
Wireless Applications 7-41 To export all profiles: 1. Tap Export All Profiles. The Save As dialog box displays. Figure 7-48. Export All Profiles Save AS Dialog Box 2. Navigate to the desired folder. 3. In the Name field, enter a file name. 4. Tap OK. When Export All Profiles is selected the current profile is also saved. This information is used to determine which profile to connect with after a warm boot or cold boot.
7-42 MC3000 Integrator Guide Registry Settings Some of the parameters can be modified through a registry key. The registry path is: HKLM\SOFTWARE\Symbol Technologies, Inc.\Configuration Editor Table 7-26. Registry Parameter Settings Key Type Default Description CertificateDirectory REG_SZ \\Windows The default directory to find certificates. EncryptionMask REG_DWORD 0x0000001F Defines the encryption types that are currently supported.
Wireless Applications 7-43 Login, Log Off Application When the user launches the login, log off application, the mobile computer may be in two states; the user may already be logged onto the mobile computer (having already entering credentials through the login box) or the user is not logged on. Each of these states have a separate set of use cases and a different look to the dialog box. To send the credentials though WCS API tap OK.
7-44 MC3000 Integrator Guide No User Logged In To access user profiles, when no user is logged in, launch the login dialog box and login. The dialog displays differently if it is: • • • • Launched by WCS, when the service is connecting to a new profile that needs credentials Launched by WCS, when the service is trying to verify the credentials due to credential caching rules Launched by a user, when a user is logged in Launched by a user, when no user is logged in.
AirBEAM Smart Chapter Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3 AirBEAM Package Builder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3 AirBEAM Smart Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8-2 MC3000 Integrator Guide
AirBEAM Smart 8-3 Introduction The AirBEAM Smart product allows specially designed software packages to be transferred between a host server and Symbol wireless handheld devices. Before transfer, AirBEAM Smart checks and compares package version, so that only updated packages are loaded. AirBEAM Smart resides on radio-equipped client devices and allows them to request, download and install software, as well as to upload files and status data.
8-4 MC3000 Integrator Guide Configuring the AirBEAM Smart Client 1. Select Start - Programs - AirBEAM Client. The AirBEAM CE window appears. 2. Tap File - Configure. The AirBEAM configuration window appears. Figure 8-1. AirBEAM Smart Configuration Window The configuration window is used to view and edit AirBEAM Smart Client configurations. This dialog box has six tabs that can be modified - Packages(1), Packages(2), Server, Misc(1), Misc(2) and Misc(3).
AirBEAM Smart 8-5 Server Tab This tab is used to specify the configurations of the server to which the client connects during the package synchronization process. Table 8-3. Server Tab Field Description IP Address The IP Address of the server. It may be a host name or a dot notation format. Directory The directory on the server that contains the AirBEAM Smart package definition files.
8-6 MC3000 Integrator Guide Table 8-4. Misc (1) Tab (Continued) Field WNMS Description This checkbox specifies whether the AirBEAM Smart Client uploads a WNMS information file at the end of each version synchronization. Misc(2) Tab This tab is used to configure various miscellaneous features. Table 8-5. Misc (2) Tab Field Auto-retry Description This field is used to specify whether the AirBEAM Smart Client automatically retries if there is a failure during the synchronization process.
AirBEAM Smart 8-7 Table 8-6. Misc (3) Tab (Continued) Field Description Use DHCP bootfile This check box control specifies whether the AirBEAM Smart Client uses the DHCP response option 67 to specify the Package and Package 1 parameters. If enabled, special RF network registry settings are required to force the DHCP server to return the "Bootfile name" field (option 67).
8-8 MC3000 Integrator Guide • The AirBEAM staging utility provides a simple single dialog user interface that is used to quickly start the software installation process.
Rapid Deployment Client Chapter Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3 Rapid Deployment Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3 Scanning RD Bar Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9-2 MC3000 Integrator Guide
Rapid Deployment Client 9-3 Introduction The Rapid Deployment (RD) Client facilitates software downloads to a mobile device from a Mobility Services Platform (MSP) Console FTP server. The MSP Console is a web-based interface to the wireless infrastructure monitoring and management tools provided by the MSP Lite or MSP Enterprise server. When software packages are transferred to the FTP server, mobile devices on the wireless network can download the packages to the mobile device.
9-4 MC3000 Integrator Guide Table 9-1. Rapid Deployment Window Text Box/Button Description Please scan all of the bar codes... This text box displays the status of a scanned bar code. - Waiting indicates the device is ready to scan a bar code. - OK indicates the device successfully scanned a bar code. (The Indicator LED bar on the mobile computer turns green and a beep sounds). If there are no bar codes left to scan, the Rapid Deployment Configuring window displays, see Figure 9-3.
Rapid Deployment Client 9-5 Scanning RD Bar Codes When the mobile computer scans and successfully decodes a single or multiple RD bar codes, the data encoded in the bar code can: • • Reset the device connection profile. A connection profile is a set of Mobile Companion parameters that the device uses to access the wireless network. Initiate downloads of one or more software packages from an FTP server to the mobile device. Currently, RD only recognizes AirBEAM software packages.
9-6 MC3000 Integrator Guide If the mobile computer cannot connect to the server, it continues to retry until the user cancels (exits) the application. If failure to connect to the server persists, see the MSP Administrator. 5. When configuration is complete: a. The designated package(s) are downloaded from the FTP server. b. A new WLAN profile is created on the mobile computer from the data encoded in the bar code(s) scanned.
Maintenance & Troubleshooting Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10- 3 Maintaining the Mobile Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10-2 MC3000 Integrator Guide
Maintenance & Troubleshooting 10-3 Introduction This chapter includes instructions on cleaning and storing the mobile computer, and provides troubleshooting solutions for potential problems during mobile computer operation. Maintaining the Mobile Computer For trouble-free service, observe the following tips when using the mobile computer: • • • • • • Do not scratch the screen of the mobile computer.
10-4 MC3000 Integrator Guide Troubleshooting Mobile Computer Table 10-1. Troubleshooting the Mobile Computer Problem Mobile computer does not turn on. Battery did not charge. Cause Solution Main battery not charged. Charge or replace the main battery in the mobile computer. Main battery not installed properly. Ensure the battery is installed properly. For more information see, Install Main Battery on page 1-7. System crash. Perform a warm boot.
Maintenance & Troubleshooting 10-5 Table 10-1. Troubleshooting the Mobile Computer (Continued) Problem The mobile computer does not accept scan input. Cause Solution Scanning application is not loaded. Verify that the mobile computer is loaded with a scanning application. Unreadable bar code. Ensure the symbol is not defaced. Distance between scan window and bar code is incorrect. Ensure the mobile computer is within proper scanning range. Mobile computer is not programmed for the bar code type.
10-6 MC3000 Integrator Guide Single Slot Serial/USB Cradle Table 10-2. Troubleshooting the Single Slot Serial/USB Cradle Problem Cause Solution Mobile computer amber Charge Cradle is not receiving power. LED Indicator does not light when mobile computer inserted. Mobile computer is not correctly seated. Ensure the power cable is connected securely to both the cradle and to AC power. Spare Battery Charging LED does not light when spare battery is inserted. Spare battery is not correctly seated.
Maintenance & Troubleshooting 10-7 Four Slot Charge Only Cradle Table 10-3. Troubleshooting the Four Slot Charge Only Cradle Problem Cause Solution Mobile computer amber Charge LED Indicator does not light when mobile computer inserted. Cradle is not receiving power. Ensure the power cable is connected securely to both the cradle and to AC power. Mobile computer is not correctly seated. Remove and re-insert the mobile computer into the cradle, ensuring it is correctly seated.
10-8 MC3000 Integrator Guide Four Slot Spare Battery Charger Table 10-5. Troubleshooting the Four Slot Spare Battery Charger Problem Cause Solution Spare Battery Charging LED does not light when spare battery is inserted. Spare battery is not correctly seated. Remove and re-insert the spare battery into the charging slot, ensuring it is correctly seated. Battery not charging. Charger is not receiving power. Ensure the power cable is connected securely to both the charger and to AC power.
Maintenance & Troubleshooting 10-9 Cables Table 10-7. Troubleshooting the Cables Problem Cause Mobile computer amber Charge Cable is not receiving power. LED Indicator does not light Mobile computer is not seated when mobile computer correctly in the cable. attached. Solution Ensure the power cable is connected securely to both the cable and to AC power. Remove and re-insert the mobile computer into the MC3000 connector, ensuring it is correctly seated.
10-10 MC3000 Integrator Guide
Technical Specifications Appendix Contents Mobile Computer And Accessory Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mobile Computer Pin-Outs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Laser Decode Ranges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Imager Decode Ranges . . . . . .
A-2 MC3000 Integrator Guide
Technical Specifications A-3 Mobile Computer And Accessory Technical Specifications Table A-1 summarizes the mobile computer technical specifications and intended operating environments. Table A-2 summarizes the accessory technical specifications and the intended operating environments. Table A-1.
A-4 MC3000 Integrator Guide Table A-1. Mobile Computer Technical Specifications (Continued) Processor/Memory Intel® XScale™ PXA 312MHz with 32MB RAM/64MB Flash or Intel® XScale™ PXA 520MHz with 64MB RAM/64MB Flash Interface RS232, 115.2 kbps max, and USB WLAN Symbol Spectrum 24, 802.11a, 802.11b, 802.
Technical Specifications A-5 Mobile Computer Pin-Outs P16 P1 Figure A-1. MC3000 Connector Table A-3. MC3000 Pin-Outs PIN Number Signal Name Function 1 GND Ground/Return 2 CRADLE_IN* When grounded, the mobile computer detects it is in the cradle.
A-6 MC3000 Integrator Guide Laser Decode Ranges The decode ranges provide the decode ranges for barcodes of specified densities. Figure A-4 shows the laser decode ranges and Table A-5 on page A-7 lists the scan ranges for the selected bar code densities. The minimum element width (or “symbol density”) is the width in mils of the narrowest element (bar or space) in the symbol. The maximum usable length of a symbol at any given range is shown below.
Technical Specifications A-7 Table A-5. Symbol Density/ Bar Code Type/W-N Ratio MC3000-R Laser Decode Ranges Bar Code Content/ Contrast (Note 1) Ranges Near Far 5.0 mil Code 39; 2.5:1 ABCDEFGH+ 80% MRD 2.0 in 5.08 cm 4.9 in 12.45 cm 7.5 mil Code 39; 2.5:1 ABCDEF 80% MRD 1.6 in 4.06 cm 7.9 in 20.07 cm 10 mil Code 39; 2.5:1 012345678905 80% MRD 1.2 in 3.05 cm 10.8 in 67.95cm UPC A 123 80% MRD 1.3 in 3.30 cm (Note 2) 12.7 in 32.26 cm 20 mil Code 39; 2.2:1 123 25% MRD 1.4 in 3.
A-8 MC3000 Integrator Guide Imager Decode Ranges The decode ranges provide the decode distances for barcodes of specified densities. Figure A-6 shows the imager decode ranges and Table A-7 on page A-9 lists the scan ranges for the selected bar code densities. The minimum element width (or “symbol density”) is the width in mils of the narrowest element (bar or space) in the symbol. The maximum usable length of a symbol at any given range is shown below.
Technical Specifications A-9 Table A-7. Symbol Density/ Bar Code Type/W-N Ratio MC3000-K Imager Decode Ranges Bar Code Content/ Contrast (Note 1) Ranges Near Far 5.0 mil Code 39; 2.5:1 ABCDEFGH+ 80% MRD 4.5 in 11.43 cm 6.5 in 16.51cm 7.5 mil Code 39; 2.5:1 ABCDEF 80% MRD 3.3 in 8.38 cm 10.7 in 27.18 cm UPC A 012345678905 80% MRD 2.5 in 6.35 cm 14.2 in 36.07cm 20 mil Code 39; 2.2:1 123 80% MRD 2.8 in 7.11 cm (Note 2) 18.9 in 48.01 cm PDF417 6.67 mil Code 39; 2.2:1 123 25% MRD 5.
A-10 MC3000 Integrator Guide
Glossary 802.11/802.11abg A radio protocol that may be used by the Symbol radio card. Access Point Access Point (AP) refers to Symbol’s Ethernet Access Point. It is a piece of communications equipment that manages communications between the host computer system and one or more wireless terminals. An AP connects to a wired Ethernet LAN and acts as a bridge between the Ethernet wired network and IEEE 802.11 interoperable radioequipped mobile units, such as a mobile computer.
GL-2 MC3000 Integrator Guide AirBEAM® Smart Client AirBEAM® Smart Client is part of Symbol’s AirBEAM® suite, which also includes AirBEAM® Safe and AirBEAM® Manager. The AirBEAM® Smart Client system uses the network accessible host server to store software files that are to be downloaded to the mobile computers. The AirBEAM® Smart Client provides the mobile computers with the “smarts” to request software from the host.
Glossary GL-3 Byte On an addressable boundary, eight adjacent binary digits (0 and 1) combined in a pattern to represent a specific character or numeric value. Bits are numbered from the right, 0 through 7, with bit 0 the low-order bit. One byte in memory is used to store one ASCII character. boot or boot-up The process a computer goes through when it starts. During boot-up, the computer can run self-diagnostic tests and configure hardware and software. CDRH Center for Devices and Radiological Health.
GL-4 MC3000 Integrator Guide COM port Communication port; ports are identified by number, e.g., COM1, COM2. Continuous Code A bar code or symbol in which all spaces within the symbol are parts of characters. There are no intercharacter gaps in a continuous code. The absence of gaps allows for greater information density. Cradle A cradle is used for charging the terminal battery and for communicating with a host computer, and provides a storage place for the terminal when not in use.
Glossary GL-5 Flash Memory Flash memory is responsible for storing the system firmware and is non-volatile. If the system power is interrupted the data is not be lost. Gateway Address An IP address for a network gateway or router. A mobile computer may be part of a subnet as specified by its IP address and Netmask. It can send packets directly to any node on the same subnet. If the destination node is on a different subnet, then the terminal sends the packet to the gateway first.
GL-6 MC3000 Integrator Guide Interleaved 2 of 5 A binary bar code symbology representing character pairs in groups of five bars and five interleaved spaces. Interleaving provides for greater information density. The location of wide elements (bar/spaces) within each group determines which characters are encoded. This continuous code type uses no intercharacter spaces. Only numeric (0 to 9) and START/STOP characters may be encoded. Internet Protocol Address See IP. IP Internet Protocol.
Glossary GL-7 Mobile Computer In this text, mobile computer refers to the Symbol wireless portable computer. It can be set up to run as a standalone device, or it can be set up to communicate with a network, using wireless radio technology. Nominal The exact (or ideal) intended value for a specified parameter. Tolerances are specified as positive and negative deviations from this value. Nominal Size Standard size for a bar code symbol. Most UPC/EAN codes are used over a range of magnifications (e.g.
GL-8 MC3000 Integrator Guide Scanning Mode The scanner is energized, programmed and ready to read a bar code. Scanning Sequence A method of programming or configuring parameters for a bar code reading system by scanning bar code menus. SDK Software Development Kit Self-Checking Code A symbology that uses a checking algorithm to detect encoding errors within the characters of a bar code symbol.
Glossary GL-9 Symbol Length Length of symbol measured from the beginning of the quiet zone (margin) adjacent to the start character to the end of the quiet zone (margin) adjacent to a stop character. Symbology The structural rules and conventions for representing data within a particular bar code type (e.g. UPC/EAN, Code 39, PDF417, etc.). Tolerance Allowable deviation from the nominal bar or space width. UPC Universal Product Code. A relatively complex numeric symbology.
GL-10 MC3000 Integrator Guide
Index Numerics 802.11 ESSID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-5 A accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3 four slot charge only cradle . . . . . . . . . . . 2-3, 2-7 battery charging . . . . . . . . . . . . . . . . . . . .2-8 LED indicators . . . . . . . . . . . . . . . . . . . . .2-8 setup . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7 troubleshooting . . . . . . . . . . . . . . . . . . .10-7 four slot Ethernet cradle . . . .
IN-2 MC3000 Integrator Guide LEAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-7 none . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-7 PEAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-7 automatic synchronization, AirBEAM . . . . . . . . . . . .8-7 B backup battery charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-10 backup battery specification . . . . . . . . . . . . . . . . . . A-3 battery charging . . . . . . . . . . .
Index IN-3 F fabric holster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 file explorer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4 file system directory structure . . . . . . . . . . . . . . . . 1-20 file update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20 flash file system . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18 downloading partitions . . . . . . . . . . . . . . . . . 6-19 non-FFS partitions . . . . . . . . . . . . . .
IN-4 MC3000 Integrator Guide non-FFS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-19 IPL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-19 splash screen . . . . . . . . . . . . . . . . . . . . .6-19 partnerships . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5 parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5, 1-6, 1-7 PEAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-7 performing a cold boot . . . . . . .
Index IN-5 saving script . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7 starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4 technical specifications . . . . . . . . . . . . . . . . . . . . . . A-3 temperature battery charging . . . . . . . . . . . . . . . . . . . . A-3, A-4 operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3 storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3 Terminal Configuration Manager, see TCM TKIP (WPA) . . .
IN-6 MC3000 Integrator Guide
Tell Us What You Think... We’d like to know what you think about this Manual. Please take a moment to fill out this questionnaire and fax this form to: (631) 738-3318, or mail to: Symbol Technologies, Inc. One Symbol Plaza M/S B-4 Holtsville, NY 11742-1300 Attention: Technical Publications Manager IMPORTANT: If you need product support, please call the appropriate customer support number provided. Unfortunately, we cannot provide customer support at the fax number above.
Symbol Technologies, Inc. One Symbol Plaza Holtsville, New York 11742-1300 http://www.symbol.
