4.1 Configuring NetWare 2.15 and 3.x
4-6
NetWare Configuration
Chapter 4
4. Select the queue you want and then assign a priority level from 1
to 10. It is recommended that you accept the default priority level.
Press . The queue appears on the list for the printer.
Press again to assign additional queues.
5. When you finish assigning queues, press and then save your
changes. Continue to press
to return to the Print Server
Configuration
menu. If you want to set Notify options, go to Sec-
tion. 4.1.6. If you are finished, continue to press and then
save your changes.
4.1.6 Set Up Notify Options for the Printer
(Optional)
To enable the print server to notify users or user groups if a problem
occurs with the printer, set up the Notify options. The print server
supports the enhanced NOTIFY options for printers, including
informing users when the printer:
• Is off-line, jammed, opened, or out of paper
• Requires a manual paper feed or a form change
• Has had an engine failure
1. Choose
Notify List for Printer on the Print Server Configuration
menu.
Enter
Insert
Esc
Esc
Esc
PageWorks.book Page 6 Tuesday, August 4, 1998 11:21 AM
