1.1 What’s in the Package
1-2
Introduction
Chapter 1
1.1 What’s in the Package
The Print Server contains the following:
• Network Interface Card (NIC)
• Quick Guide
• CD-ROM
– User’s Manual
– Utility Software
IP Discovery Program
IP Peer-to-Peer Printing Program
IPX/IP Management Access Program (MAP)
IPX Peer-to-Peer Printing Program
AppleTalk NIManage Utility
UNIX TCP/IP Utility
– MIB Definition
The CD-ROM also contains the ASN.1 coded SNMP MIB for the NIC.
This MIB can be loaded into a standard SNMP console to provide
SNMP access to all NIC parameters. The MIB can be found on the CD-
ROM in NIC MIB Definition.
BOOTP programs for Windows (to assist entering IP parameters in a
Windows environment) are also included on the CD-ROM.
The CD-ROM may contain a ReadMe file containing the latest
information about installation and operation. Check for these files
before going any further with installation.
Instructions and software to perform flash downloads are provided
with any update or upgrade package and are not included in this
manual.
