Data Sheet

DATA SHEET
0012345
ÖLFLEX
®
500 P
valid from :
20.07.2009
Originator: R. Krämer / TE-K
approved: H. Schillinger / TE-K
Document: DB0012345EN page 1 of 1
All deviations from this specification are subject to explicit consent of U.I.LAPP GmbH. All rights reserved acc. to DIN 34.
No.: 0019/0408
Application
ÖLFLEX
®
500 P cables are highly flexible oil-resistant connecting cables with an insulation of Polyurethane and
an outer sheath of Polyurethane for flexible use and fixed installation under increased mechanical load condi-
tions. They are designed for use in dry, damp and wet conditions. Outdoor use: They may only be installed con-
sidering the temperature range.
Continuous busy movements, compulsory guidance respectively usage on cable drums or pulleys or under a
strain of more than 15 N / mm² are not allowed. At room temperature they are widely resistant to certain oils and
resistant to acids. The outer sheath of Polyurethane is resistant to high mechanical load, particularly to abrasion
and scouring, cut resistant, microbe-proof and hydrolysis resistant.
All materials used for these cables are halogen-free.
Design
Design based on HD 21.5 S3 resp. VDE 0281-5
Conductor superfine wire strands of bare copper
acc. to IEC 60228 resp. VDE 0295, Class 6
Core insulation Polyurethane compound
Core identification coloured acc. to HD 308 S2 resp. VDE 0293-308
Outer sheath Polyurethane compound TMPU in acc. to HD 22.10 S2 resp. VDE 0282-10
colour: Orange
MUD resistant acc. to IEC 61892-4 Annex D
Electrical properties at 20 °C
Nominal voltage 300 / 500 V
Test voltage 3000 V AC
Mechanical and thermal properties
Min. bending radius occasional flexing: 15 x cable diameter
fixed installation: 4 x cable diameter
Temperature range occasional flexing: -40 °C up to +80 °C max. conductor temperature
fixed installation: -50 °C up to +80 °C max. conductor temperature
Flammability flame retardant in acc. to IEC 60332-1-2 resp. VDE 0482-332-1-2
Oil resistance acc. to IEC 60811-2-1 resp. VDE 0473 part 811-2-1
Tests acc. to IEC 60811 resp. VDE 0473 and VDE 0472
EC directive This cable is conform to ECD 2006/95/EC (Low Voltage Directive).
