Evox Rifa Leaded Film Capacitors
article table
MMK
Capaci- Box Max dimen- Max
tance code sions in mm dU/dt
µF B H L V/µs Article code
Capaci- Box Max dimen- Max
tance code sions in mm dU/dt
µF B H L V/µs Article code
250 VDC/160 VA
LEAD SPACING 15 MM
0.33 B04 5.5 10.5 18.0 12 MMK15 334K250B04L4 BULK
0.39 B04 5.5 10.5 18.0 12 MMK15 394K250B04L4 BULK
0.47 B05 5.5 12.5 18.0 12 MMK15 474K250B05L4 BULK
0.56 B10 6.5 12.5 18.0 12 MMK15 564K250B10L4 BULK
0.68 B10 6.5 12.5 18.0 12 MMK15 684K250B10L4 BULK
0.82 B06 7.5 14.5 18.0 12 MMK15 824K250B06L4 BULK
1.0 B06 7.5 14.5 18.0 12 MMK15 105K250B06L4 BULK
1.2 B12 8.0 15.0 18.0 12 MMK15 125K250B12L4 BULK
1.5 B14 9.5 17.5 18.0 12 MMK15 155K250B14L4 BULK
1.8 B14 9.5 17.5 18.0 12 MMK15 185K250B14L4 BULK
LEAD SPACING 22.5 MM
0.47 D13 6.5 14.5 26.0 8 MMK22.5 474K250D13L4 TRAY
0.56 D13 6.5 14.5 26.0 8 MMK22.5 564K250D13L4 TRAY
0.68 D13 6.5 14.5 26.0 8 MMK22.5 684K250D13L4 TRAY
0.82 D13 6.5 14.5 26.0 8 MMK22.5 824K250D13L4 TRAY
1.0 D13 6.5 14.5 26.0 8 MMK22.5 105K250D13L4 TRAY
1.2 D17 7.0 16.5 26.0 8 MMK22.5 125K250D17L4 TRAY
1.5 D14 8.0 16.0 26.0 8 MMK22.5 155K250D14L4 TRAY
1.8 D15 9.0 18.5 26.0 8 MMK22.5 185K250D15L4 TRAY
2.0 D15 9.0 18.5 26.0 8 MMK22.5 205K250D15L4 TRAY
2.2 D15 9.0 18.5 26.0 8 MMK22.5 225K250D15L4 TRAY
2.7 D18 10.5 19.0 26.0 8 MMK22.5 275K250D18L4 TRAY
3.3 D16 11.0 21.5 26.0 8 MMK22.5 335K250D16L4 TRAY
3.9 D20 13.5 23.0 26.0 8 MMK22.5 395K250D20L4 TRAY
4.7 D19 15.5 24.5 26.0 8 MMK22.5 475K250D19L4 TRAY
5.6 D19 15.5 24.5 26.0 8 MMK22.5 565K250D19L4 TRAY
LEAD SPACING 27.5 MM
1.5 F11 10.5 20.5 31.5 5 MMK27.5 155K250F11L4 TRAY
1.8 F11 10.5 20.5 31.5 5 MMK27.5 185K250F11L4 TRAY
2.0 F11 10.5 20.5 31.5 5 MMK27.5 205K250F11L4 TRAY
2.2 F11 10.5 20.5 31.5 5 MMK27.5 225K250F11L4 TRAY
2.5 F11 10.5 20.5 31.5 5 MMK27.5 255K250F11L4 TRAY
2.7 F11 10.5 20.5 31.5 5 MMK27.5 275K250F11L4 TRAY
3.3 F11 10.5 20.5 31.5 5 MMK27.5 335K250F11L4 TRAY
3.3 F17 21.0 12.5 31.5 5 MMK27.5 335K250F17L4 TRAY
3.9 F12 11.5 22.5 31.5 5 MMK27.5 395K250F12L4 TRAY
4.7 F03 13.5 23.0 31.5 5 MMK27.5 475K250F03L4 TRAY
5.6 F13 14.5 24.5 31.5 5 MMK27.5 565K250F13L4 TRAY
6.8 F14 17.5 28.0 31.5 5 MMK27.5 685K250F14L4 TRAY
8.2 F14 17.5 28.0 31.5 5 MMK27.5 825K250F14L4 TRAY
8.2 F19 27.5 16.0 31.5 5 MMK27.5 825K250F19L4 TRAY
10 F16 21.0 30.0 31.5 5 MMK27.5 106K250F16L4 TRAY
10 F18 31.0 19.0 31.5 5 MMK27.5 106K250F18L4 TRAY
LEAD SPACING 37.5 MM
4.7 R05 13.0 24.0 41.0 3 MMK37.5 475K250R05L4 TRAY
5.6 R05 13.0 24.0 41.0 3 MMK37.5 565K250R05L4 TRAY
6.8 R05 13.0 24.0 41.0 3 MMK37.5 685K250R05L4 TRAY
8.2 R04 15.0 26.0 41.0 3 MMK37.5 825K250R04L4 TRAY
10 R04 15.0 26.0 41.0 3 MMK37.5 106K250R04L4 TRAY
12 R02 16.5 32.0 41.0 3 MMK37.5 126K250R02L4 TRAY
15 R02 16.5 32.0 41.0 3 MMK37.5 156K250R02L4 TRAY
18 R03 19.0 36.0 41.0 3 MMK37.5 186K250R03L4 TRAY
22 R06 21.0 38.0 41.0 3 MMK37.5 226K250R06L4 TRAY
27 R08 28.0 43.0 41.0 3 MMK37.5 276K250R08L4 TRAY
33 R08 28.0 43.0 41.0 3 MMK37.5 336K250R08L4 TRAY
39 R08 28.0 43.0 41.0 3 MMK37.5 396K250R08L4 TRAY
400 VDC/200 VAC
LEAD SPACING 5 MM
0.0010 J01 2.5 6.5 7.2 50 MMK5 102K400J01L4 BULK
0.0012 J01 2.5 6.5 7.2 50 MMK5 122K400J01L4 BULK
0.0015 J01 2.5 6.5 7.2 50 MMK5 152K400J01L4 BULK
0.0018 J01 2.5 6.5 7.2 50 MMK5 182K400J01L4 BULK
0.0022 J01 2.5 6.5 7.2 50 MMK5 222K400J01L4 BULK
0.0027 J01 2.5 6.5 7.2 50 MMK5 272K400J01L4 BULK
0.0033 J01 2.5 6.5 7.2 50 MMK5 332K400J01L4 BULK
0.0039 J01 2.5 6.5 7.2 50 MMK5 392K400J01L4 BULK
0.0047 J01 2.5 6.5 7.2 50 MMK5 472K400J01L4 BULK
0.0056 J01 2.5 6.5 7.2 50 MMK5 562K400J01L4 BULK
0.0068 J01 2.5 6.5 7.2 50 MMK5 682K400J01L4 BULK
0.0082 J01 2.5 6.5 7.2 50 MMK5 822K400J01L4 BULK
0.010 J01 2.5 6.5 7.2 50 MMK5 103K400J01L4 BULK
0.012 J01 2.5 6.5 7.2 50 MMK5 123K400J01L4 BULK
0.015 J01 2.5 6.5 7.2 50 MMK5 153K400J01L4 BULK
0.018 J02 3.5 8.0 7.2 50 MMK5 183K400J02L4 BULK
0.022 J02 3.5 8.0 7.2 50 MMK5 223K400J02L4 BULK
0.027 J03 4.5 9.0 7.2 50 MMK5 273K400J03L4 BULK
0.033 J03 4.5 9.0 7.2 50 MMK5 333K400J03L4 BULK
0.039 J03 4.5 9.0 7.2 50 MMK5 393K400J03L4 BULK
0.047 J03 4.5 9.0 7.2 50 MMK5 473K400J03L4 BULK
0.056 J05 6.0 11.0 7.2 50 MMK5 563K400J05L4 BULK
0.068 J05 6.0 11.0 7.2 50 MMK5 683K400J05L4 BULK
0.082 J06 7.2 13.0 7.2 50 MMK5 823K400J06L4 BULK
0.10 J06 7.2 13.0 7.2 50 MMK5 104K400J06L4 BULK
0.12 J06 7.2 13.0 7.2 50 MMK5 124K400J06L4 BULK
LEAD SPACING 7.5 MM
0.0010 K00 2.5 6.0 10.0 40 MMK7.5 102K400K00L4 BULK
0.0012 K00 2.5 6.0 10.0 40 MMK7.5 122K400K00L4 BULK
0.0015 K00 2.5 6.0 10.0 40 MMK7.5 152K400K00L4 BULK
0.0018 K00 2.5 6.0 10.0 40 MMK7.5 182K400K00L4 BULK
0.0022 K00 2.5 6.0 10.0 40 MMK7.5 222K400K00L4 BULK
0.0027 K00 2.5 6.0 10.0 40 MMK7.5 272K400K00L4 BULK
0.0033 K00 2.5 6.0 10.0 40 MMK7.5 332K400K00L4 BULK
0.0039 K00 2.5 6.0 10.0 40 MMK7.5 392K400K00L4 BULK
0.0047 K00 2.5 6.0 10.0 40 MMK7.5 472K400K00L4 BULK
0.0056 K00 2.5 6.0 10.0 40 MMK7.5 562K400K00L4 BULK
0.0068 K00 2.5 6.0 10.0 40 MMK7.5 682K400K00L4 BULK
0.0082 K00 2.5 6.0 10.0 40 MMK7.5 822K400K00L4 BULK
0.010 K00 2.5 6.0 10.0 40 MMK7.5 103K400K00L4 BULK
0.012 K00 2.5 6.0 10.0 40 MMK7.5 123K400K00L4 BULK
0.015 K00 2.5 6.0 10.0 40 MMK7.5 153K400K00L4 BULK
0.018 K01 4.0 8.0 10.0 40 MMK7.5 183K400K01L4 BULK
0.022 K01 4.0 8.0 10.0 40 MMK7.5 223K400K01L4 BULK
0.027 K01 4.0 8.0 10.0 40 MMK7.5 273K400K01L4 BULK
0.033 K01 4.0 8.0 10.0 40 MMK7.5 333K400K01L4 BULK
0.039 K01 4.0 8.0 10.0 40 MMK7.5 393K400K01L4 BULK
0.047 K03 5.0 11.0 10.0 40 MMK7.5 473K400K03L4 BULK
0.056 K03 5.0 11.0 10.0 40 MMK7.5 563K400K03L4 BULK
0.068 K03 5.0 11.0 10.0 40 MMK7.5 683K400K03L4 BULK
0.082 K03 5.0 11.0 10.0 40 MMK7.5 823K400K03L4 BULK
0.10 K03 5.0 11.0 10.0 40 MMK7.5 104K400K03L4 BULK
0.12 K04 6.0 12.0 10.5 40 MMK7.5 124K400K04L4 BULK
0.15 K04 6.0 12.0 10.5 40 MMK7.5 154K400K04L4 BULK
LEAD SPACING 10 MM
0.0010 A01 4.0 9.0 13.0 30 MMK10 102K400A01L4 BULK
0.0012 A01 4.0 9.0 13.0 30 MMK10 122K400A01L4 BULK
0.0015 A01 4.0 9.0 13.0 30 MMK10 152K400A01L4 BULK
Updated since the latest printed catalogue
