Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-5
PICTURE UNITS
PPC1260 PPC1860 PPC2260 PPC2460 PPC2660 PPC3060 PPC3260 PPC3460
PPC1266 PPC1866 PPC2266 PPC2466 PPC2666 PPC3066 PPC3266 PPC3466
PPC1272 PPC1872 PPC2272 PPC2472 PPC2672 PPC3072 PPC3272 PPC3472
PPC1278 PPC1878 PPC2278 PPC2478 PPC2678 PPC3078 PPC3278 PPC3478
PPC1284 PPC1884 PPC2284 PPC2484 PPC2684 PPC3084 PPC3284 PPC3484
60”(1524)
61 3/4”(1568) 59 1/2”(1511) 55 7/8”(1419)
66”(1676)
67 3/4”(1721) 65 1/2”(1664) 61 7/8”(1572)
72”(1829)
73 3/4”(1873) 71 1/2”(1816) 67 7/8”(1724)
78”(1981)
79 3/4”(2026) 77 1/2”(1969) 73 7/8”(1876)
84”(2134)
85 3/4”(2178) 83 1/2”(2121) 79 7/8”(2029)
35 35 35 35 35 35 35 35
35 35 35 35 35 35 35 35
35 35 35 35 35 35 35 35
35 35 35 35 35 35 35 35
35 35 35 35 35 35 35 35
12”(305)
13 3/4”(349)
11 1/2”(292)
77/8”(200)DAYLIGHT OPENING
FRAME SIZE
ROUGH OPENING
UNIT SIZE
18”(457)
19 3/4”(502)
17 1/2”(445)
13 7/8”(352)
22”(559)
23 3/4”(603)
21 1/2”(546)
17 7/8”(454)
24”(610)
25 3/4”(654)
23 1/2”(597)
19 7/8”(505)
26”(660)
27 3/4”(705)
25 1/2”(648)
21 7/8”(556)
30”(762)
31 3/4”(806)
29 1/2”(749)
25 7/8”(657)
32”(813)
33 3/4”(857)
31 1/2”(800)
27 7/8”(708)
34”(864)
35 3/4”(908)
33 1/2”(851)
29 7/8”(759)
Fixed, Radius and Geometric Windows
Premium Vinyl
SCALE: 1
/
4” = 1’
