Use and Care Manual
1. Cut and remove wire/cable tie from smaller end cap
located opposite handle and electrical cord.
2. Remove end cap by gently prying off tube with a
screwdriver or similar tool.
3. Notice white electrical cord protruding from shock.
Gently push 2.5” of this cord back through shock.
4. Carefully remove shock by pulling it straight out of
outer tube. Use caution as lamp may remain attached
to shock. If so, carefully pull lamp loose.
5. Remove lamp from tube and dispose of properly.
If old lamp is not broken, there is a vacuum inside and
breaking the lamp can be dangerous. A spent lamp
contains low levels of mercury, the disposal require-
ments of which vary by state. See www.lamprecycle.
org. Clean inside of outer tube if necessary.
6. Insert new lamp so bottom lamp pin inserts fully into
base of shock.
7. Insert shock into outer tube so top lamp pins insert
fully into receptacles of shock.
8. Gently pull white electrical cord through shock to
remove slack.
9. Replace end cap, making certain cap is fully seated
in groove of tube. Secure with 150-lb minimum cable/
wire tie.
10. Visually inspect light to ensure lamp is fully engaged
prior to testing.
White Cord
Shock
Outer Tube
Lamp
End Cap
30RL_MO3
Relamp This End
Single Lamp Fluorescent Work Light
Since 1956
RELAMPING INSTRUCTIONS
Warranty
Jameson products carry a warranty against any defect in material and workmanship for a period of one year from date of shipment unless failure is due to
misuse or improper application. Jameson shall in no event be responsible or liable for modications, alterations, misapplications or repairs made to its products
by purchaser or others. This warranty is limited to repair or replacement of the product and does not include reimbursement for shipping or other expenses
incurred. Jameson disclaims any other express or implied warranty.
WWW.JAMESONLLC.COM
Clover, SC
Disconnect From Power Source
Before Relamping
Wear Hand and Eye Protection
Pins
