S2600GZ and S2600GL

Intel® Server Board S2600GZ/GL TPS Appendix B: Integrated BMC Sensor Tables
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Readi
ng Type
Event Offset Triggers
Contrib. To
System Status
Assert/
De-
assert
Readable
Value/Of
fsets
Event
Data
Rearm
Stand-
by
IO Module Presence
(IO Mod Presence)
0Eh
Platform-
specific
Module/Boar
d
15h
Digital
Discrete
08h
01 – Inserted/Present OK
As
and
De
– Trig Offset M X
SAS Module Presence
(SAS Mod Presence)
0Fh
Platform-
specific
Module/Boar
d
15h
Digital
Discrete
08h
01 – Inserted/Present OK
As
and
De
– Trig Offset M X
BMC Firmware Health
(BMC FW Health)
10h All
Mgmt Health
28h
Sensor
Specific
6Fh
04 – Sensor Failure
Degraded
As - Trig Offset A X
System Airflow
(System Airflow)
11h All
Other Units
0Bh
Threshold
01h
– – – Analog – – –
Baseboard Temperature 1
(Platform Specific)
20h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Front Panel Temperature
(Front Panel Temp)
21h All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
SSB Temperature
(SSB Temp)
22h
All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Baseboard Temperature 2
(Platform Specific)
23h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Baseboard Temperature 3
(Platform Specific)
24h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Baseboard Temperature 4
(Platform Specific)
25h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Revision 2.4 201
