Specification Sheet
Powered Liner with Baffles.
Your Design, Our Power!
Features
Lighting: Lighting uses 50 Watt Halogen Spots (PAR20). SD4-12—Two 75 Watt Incandescent (Bulbs NOT Included)
Heat Sensor: Fire Safety Thermostat with Automatic turn ON when temp. reaches 130 degrees.
Filters: Stainless Steel Baffle Filters.
*Flange: Trim pieces available for an additional charge.
Custom: Custom sizes available. Call with exact dimensions for pricing and delivery time.
Optional Remote Controls: Remote control wiring available.
Specifications
Power: Flame Retardant Centrifugal Blowers. 535 to 1320 CFM.
Stainless: Complete Stainless Steel
Construction for Durability and Fire Safety.
Distance Codes: Check local city, county and cooking appliance specifications. UL tested at 36” above cooking surface.
Installation: Simple, Stress Free, One Piece Installation with “Automatic Seal Vent Collar”.
Warranty
Warranty: 7 Year, In-Home—Parts & Labor. (Best in the Industry!)
No “Performance” Warranty when used above BBQ Style Grills, may not be satisfactory in all situations. Call to discuss.
MODELS
POWER
CFM
MOTOR
TYPE
CONTROLS SONES
LOW - HI
DEPTH
Front to Back
DUCT
LIGHTING SIZES
C2000PSB 635 Dual Blowers Variable 1.5 - 4.6 22 1/8” Single 7” Front Panel 30”, 36”, 42”, 48”
C2000PSB-8 765 Dual Blowers Variable 1.5 - 4.6 22 1/8” Single 8” Front Panel 30”, 36”, 42”, 48”
C2000PSB-K 975 Dual Blowers Variable 1.5 - 4.6 22 1/8” Single 10” Front Panel 30”, 36”, 42”, 48”
C2000PS1-TWB 1100 Twin Blowers Variable 1.5 - 4.6 22 1/8” Two 7” Front Panel 36” to 60”
C2000PS1-TWB-8 1320 Twin Blowers Variable 1.5 - 4.6 22 1/8” Two 8” Front Panel 36” to 60”
C2000BP1B 535 Single Blower Variable 1.5 - 4.6 18 1/8” Single 7” Offset Front Panel 30”, 36”, 42”
C2000BPB 625 Dual Blower Variable 1.5 - 4.6 18 1/8” Single 7” Front Panel 30”, 36”, 42”, 48”
C2000BPB-8 750 Dual Blower Variable 1.5 - 4.6 18 1/8” Single 8” Front Panel 30”, 36”, 42”, 48”
C2000BPB-K 935 Dual Blower Variable 1.5 - 4.6 18 1/8” Single 10” Front Panel 30”, 36”, 42”, 48”
C2000BP1-TWB 1065 Twin Blower Variable 1.5 - 4.6 18 1/8” Two 7” Front Panel 36” to 60”
C2000BP1-TWB-8 1275 Twin Blower Variable 1.5 - 4.6 18 1/8” Two 8” Front Panel 36” to 60”
*Flange—Custom fit your liner with standard 3/4” flanges. Other sizes available. Call for a quote.
Employee Owned
American Made
Since 1961
www.imperialhoods.com
