ICU Compact TM MANUAL / HANDBOEK / ANLEITUNG / MANUEL / MANUALE
Package Contents / Inhoud Verpakking / Inhalt Verpackung / Contenu de l‘emballage / Contenuto della confezione ICU Compact 1x or 1x 1x 1x 1x Pole / Paal / Säule / Pôle / Polo 1x 1x 1x 1x 1x Anti-theft M4 x 12 4x M10 4x M10 Types / Varianten / Varianten / Variantes / Varianti Fixed Cable Plug & Charge Fixed Cable RFID RFID 1x
Outside / Buiten / Außen / Extérieur / Esterno 1 2 4 3 5 7 6 8 H x W x D: 330 x 200 x 120 mm
Inside / Binnenzijde / Innen / Intérieur / Interno 10 11 12 13 14 16 15
Installation / Installatie / Installation / Installation / Installazione
Operating / Operating / Betrieb / Opération / Operazione Plug & Charge – Authorisation without charging card Start 1 2 3 Stop 1 2 3 or Charging station with RFID card Start 1 2 4 3 3 sec. Stop 2 1 3 sec.
Contact / Contact / Kontakt / Contact / Contatto Alfen ICU B.V. Splijtbakweg 15 1333 HC Almere The Netherlands Postbus 1042 1300 BA Almere Tel: +31 36 54 93 400 E-mail: info@icu-charging-stations.com Website: www.icu-charging-stations.
Subject to modifications and amendments. Alfen ICU B.V. | Splijtbakweg 15 Almere NL | Tel: +31 36 - 549 34 00 E-mail: info@icu-charging-stations.com | www.icu-charging-stations.
Table of content 1. Safety and operation instructions 2 1.1 Aim of the manual and target group 2 1.2 General safety 2 2. Product 3 2.1 The charging station 3 2.2 LED-status display 3 2.3 Technical specifications 4 3. Mounting and connecting 6 3.1 Installation and connection 6 3.2 Requirements for assembly and installation 6 3.3 Mechanical installation 7 3.4 Electrical installation 8 4. Commissioning the charging station 9 4.1 Safety instructions before operating 9 4.
EN ENGLISH Safety and operation instructions 1. Safety and operation instructions 1.1 Aim of the manual and target group The ICU Compact charging station is intended exclusively for charging of electric vehicles without the need for a separate grid connection (house connection box). Follow the instructions to ensure proper operation of the charging station. The installation, commissioning and maintenance may only be performed by a qualified electrician (Alfen ICU certified partner).
EN The charging station (indside) 10 Screws front cover 11 Screws wall mounting 12 Connection kWh-meter 13 SIM Card Slot 14 Terminal block for tethered cable 15 Terminal block for power cable 16 UTP (Ethernet) Connection ENGLISH Product Identification Label The identification label ( 8 ) specifies, for example, the model, production date and serial number. It can be found on the side of the charging station.
EN ENGLISH Product 2.3 Technical specifications Input/power supply Power supply Min. 5 x 4 mm² (16 A) / 5 x 6 mm² (32 A) Rated voltage 230 V / 400 V Mains connection 25 A 1-phase 230 V 50 Hz (3.7 kW version); 25 A 3-phase 400 V 50 Hz (11 kW version); 40 A 3-phase 400 V 50 Hz (22 kW version) Rated frequency 50 Hz Back-up fuse 20 A - 80 A (required on site) Connecting terminals M20 terminal block, for cable sizes from 12.5 mm - 20.5 mm, Cable-clamps max.
EN ENGLISH Product Charge control/status indicators Charge controller 1 x IB503 and 1 x communication module Communication with vehicle Mode 3, Renault Z.E. Ready Operating status indicator 4 x RBG LED Card reader RFID (NFC) Mifare 13.56 Mhz, DESFire, integrated (optional) Internet / Network ability GPRS (900/1800Mhz), SIM lock free or TCP/IP (at least CAT5 Ethernet) Communication protocol OCPP 1.
EN ENGLISH Mounting and connecting 3. Mounting and connecting 3.1 Installation and connection Read these instructions before installing the charging station carefully. Alfen ICU B.V. are not liable for any consequential damages that occur due to the use of this manual. NOTICE The installation must be performed by qualified personnel that have read this manual and operate in accordance with the guidelines IEC 60364. Otherwise it may result in injury or dangerous situations when dealing with electricity.
EN When selecting the installation site the following conditions must be assessed: • Installation not in potentially explosive atmospheres • Installation not in flood-prone areas • Compliance with local technical connection requirements and safety rules • The mounting surface should have a flat and sufficiently firm ground • Humidity maximum 95% (non-condensing) • Ambient temperature of -25 °C to 40 °C • Average temperature within 24 hours < 35 °C • As a installation height: a distance of 50 to 150 cm is r
EN ENGLISH Installation of the charging station Preparation of the charging station The front cover of the charging station must be opened before installing. Proceed as follows: The front cover is firmly attached to the charging unit and is secured with two screws at the top and bottom. 1. Place the device on its back 2. Remove the metal cover strips on the top and bottom 3. Loosen the four screws with an Allen key 4. Keep the screws in a safe place; they will be required later 5.
EN Commissioning the charging station ENGLISH 4. Commissioning the charging station 4.1 Safety instructions before operating Follow the below safety instructions before putting your charger into operation: 1. Make sure that the charging station is securely connected to the house supply line as specified in this manual 2. Make sure that the supply line in the house distribution is separately protected by an appropriate circuit breaker (B-characteristic) 3.
EN ENGLISH Connectivity 5. Connectivity 5.1 Back End Systems You are in possession of an intelligent ICU charging station that can communicate with a back end system through an internet connection. Back end systems allow you for example to view the energy consumption of individual users, remotely control charging or monitor the charging station for service purposes. If you signed a contract with a back end supplier or with Alfen ICU B.V.
ENGLISH EN 11
