HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and Configuration Guide

Table Of Contents
Preparing the Host System
3–5HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
3–5
Figure 3–2: Single-Bus Enterprise Storage RAID Array Storage System
1 SCSI Bus 1 Cable 2 SCSI Bus 2 Cable
3 SCSI Bus 3 Cable 4 SCSI Bus 4 Cable
5 SCSI Bus 5 Cable 6 SCSI Bus 6 Cable
7 AC Power Inputs 8 Fibre Channel Ports
1
8
2
3
6
CXO7382A
4
5
7
