Preparing the Host System
3–4 HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
Figure 3–1: Dual-Bus Enterprise Storage RAID Array Storage System
1 SCSI Bus 1 Cable 2 SCSI Bus 2 Cable
3 SCSI Bus 3 Cable 4 SCSI Bus 4 Cable
5 SCSI Bus 5 Cable 6 SCSI Bus 6 Cable
7 AC Power Inputs 8 Fibre Channel Ports
1
3
2
5
6
4
7
8
CXO7383A
