Subsystem Profile Templates
A–14 HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
Storage Map Template 7 for the Model 4350R Disk
Enclosure
Use this template for a subsystem with a three-shelf Model 4350R disk enclosure
(single-bus). You can have up to three Model 4350R disk enclosures per controller
shelf.
Model 4350R Disk Enclosure Shelf 6 (single-bus)
Bay 1 2 3 4 5 6 7 8 9 10
SCSI
ID
00 01 02 03 04 05 08 10 11 12
DISK
ID
Disk60000
Disk60100
Disk60200
Disk60300
Disk60400
Disk60500
Disk60800
Disk61000
Disk61100
Disk61200
Model 4350R Disk Enclosure Shelf 5 (single-bus)
Bay 1 2 3 4 5 6 7 8 9 10
SCSI
ID
00 01 02 03 04 05 08 10 11 12
DISK
ID
Disk50000
Disk50100
Disk50200
Disk50300
Disk50400
Disk50500
Disk50800
Disk51000
Disk51100
Disk51200
